GB
Principal parts of the machine
18
13. Horizontal spool pin
14. Bobbin winder
19
15. Handwheel
20
16. Power and light switch
17. Main plug socket
21
18. Bobbin thread guide
22
19. Upper thread guide
20. Face plate
21. Handle
22. Presser foot lever
23. Foot speed control
24. Power cord
23
24
4
