User's Guide
Removing USB Device
1. Double click the removable device icon on the right bottom side of the taskbar.
2. Select the socket from the list that you want to remove, and click stop button. The system
then disables the function of USB device.
3. Then you can remove the inserted USB device.

Using the External Monitor Port

Your computer has a 15 -pin Monitor port for supporting any external CRT or LCD color monitor. You need a display signal
cable (usually provided with the monitor). One end of the cable must have a 15-pin connector for the system.
To connect an external monitor:
1. Turn off your computer and make sure the monitor power switch is turned off.
The notebook computer must be powered off or suspended while the monitor is being connected. Although you can connect
the external Monitor without power off the computer and the external monitor, however, it is harmful to both devices and it
shortens the life of these devices.
2. Connect the connector cable of the monitor to the VGA port of your computer. Secure the cable connection with the
screws provided.
3. Connect the monitor power cable and plug it into a properly grounded wall outlet.
4. Turn on the power of the monitor.
5. Turn on your computer. Both the LCD panel and the monitor screen will show the display. Your computer is set at
default to run at simultaneous display mode.
Using the Notebook PC
4-19
