Bottom Side

Refer to the diagram below to identify the components on this side of the
Notebook PC.
®
1. Kensington Lock Port
®
Kensington lock port allows the Notebook PC to be secured using
Kensington® compatible Notebook PC security products. These security
products usually include a metal cable and lock that prevent the Notebook
PC to be removed from a fixed object. Some may also include a motion
detector to sound an alarm when moved.
2. Battery Pack
The battery pack is automatically charged when the Notebook PC is connected to an AC power source and maintains power
to the Notebook PC when AC power is not connected. This allows user when moving temporarily between locations. Battery
time varies by usage and by the specifications for this Notebook PC. The battery pack cannot be disassembled and must be
purchased as a single unit.
3.CPU Area
The CPU area contains pre-installed RAM, Heat sink, Fan. RAM (Random Access Memory) is where operating system,
application programs, and data in current use are kept so that they can be quickly reached. Visit an authorized service
center or retailer for more information on memory for your Notebook PC.
4.Hard Disk Drive Area
The hard disk drive is secured in an area. Hard Disk Drive (HDD) is a non-volatile data storage device. It stores data on a
magnetic surface layered onto hard disk platters. Visit an authorized service center or retailer for more information on hard
disk drive for your Notebook PC.
Knowing the Parts
2-7
