  • Page 1 CO-Series Service Manual...

  • Page 3: Table Of Contents

    CO-Series Service Manual TABLE OF CONTENTS Introduction ............2 CO-200/250-MD, All Models Except CO-Series Electronic Locks ....... 3 Keypad Only ..........31 CO-100-CY Keypad Only ....... 4 CO-200/250-993-R, All Models Except CO-100-CY Keypad Only ....... 5 Keypad Only ..........32 CO-100-MS Keypad Only .......

  • Page 4: Introduction

    CO-Series Service Manual INTRODUCTION This manual contains a complete listing of available parts and assemblies for CO-Series cylindrical, mortise, and exit trim locks manufactured by Schlage Lock Company. This edition lists components of CO-Series locks manufactured after November 2010. Exploded views of each lock function and trim assembly are provided with accompanying charts to identify parts for replacement purposes.

  • Page 5: Co-Series Electronic Locks

    CO-SERIES ELECTRONIC LOCKS The CO-Series is a new platform of standalone electronic locks that succeeds KC2, Pro, and Cobra. It is one of the first electronic locks to be UL 294 listed, and is also compatible with many different brands and types of exit devices and cylinders.

  • Page 6: Co-100-Cy Keypad Only

    CO-Series Service Manual CO-100-CY KEYPAD ONLY Exterior Part Part Number Description Number Number Description Number Classroom/Storeroom 23518392 7 *** Baseplate Subassembly, CY See pg. 39 Wiring Harness Office/Privacy 23518384 Latch Retractor 46928800 Escutcheon, Keypad Cylinder See pg. 48 Only, CY (with...

  • Page 7: Co-100-Cy Keypad Only

    CO-Series Service Manual CO-100-CY KEYPAD ONLY Interior Part Part Number Description Number Number Description Number 4AA Battery Holder Spring See pg. 41 4AA Battery Strap Rose, Inside 03-042-RHO 4AA Battery Holder & Cover Screws, Battery Strap (2) 4B-CM 23599228 4AA Battery Cover...

  • Page 8: Co-100-Ms Keypad Only

    CO-Series Service Manual CO-100-MS KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 5 *** Baseplate Subassembly, MS See pg. 39 Stand-Offs, MS/MD See pg. 41 ¹⁄₁₆ 46928818 Baseplate Stand-Offs See pg. 41 Lock Case, Narrow, 1 " wide ¹⁄₄...

  • Page 9: Co-100-Ms Keypad Only

    CO-Series Service Manual CO-100-MS KEYPAD ONLY Interior Number Description Part Number Number Description Part Number 4AA Battery Holder Spindle See pg. 41 4AA Battery Strap Spring See pg. 41 4AA Battery Holder & Cover Screws, Battery Strap (2) 4B-CM Rose, Inside...

  • Page 10: Co-100-993-R Keypad Only

    CO-Series Service Manual CO-100-993-R KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 8 *** Baseplate Subassembly, 993 See pg. 39 Baseplate Stand-Offs See pg. 41 Cylinder See pg. 48 Wiring Harness Classroom/Storeroom 23518392 Gasket, Baseplate Tailpiece Gasket Kit, Outside...

  • Page 11: Co-100-993-R Keypad Only

    CO-Series Service Manual CO-100-993-R KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Screws, Battery Strap (2) 4B-E Holder & Cover Kit...

  • Page 12: Co-100-993-S Keypad Only

    CO-Series Service Manual CO-100-993-S KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 8 *** Baseplate Subassembly, 993 See pg. 39 Baseplate Stand-Offs See pg. 41 Cylinder See pg. 48 Wiring Harness Classroom/Storeroom 23518392 Gasket, Baseplate Tailpiece Gasket Kit, Outside...

  • Page 13: Co-100-993-S Keypad Only

    CO-Series Service Manual CO-100-993-S KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Holder Screws, Battery Strap (2) 4B-E & Cover Kit...

  • Page 14: Co-100-993-M Keypad Only

    CO-Series Service Manual CO-100-993-M KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 8 *** Baseplate Subassembly, 993 See pg. 39 Tailpiece Cylinder See pg. 48 Clip, Tailpiece Gasket, Baseplate Cover, Spindle, 993 Spindle and Hub Gasket Kit, Outside...

  • Page 15: Co-100-993-M Keypad Only

    CO-Series Service Manual CO-100-993-M KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Holder Screws, Battery Strap (2) 4B-E & Cover Kit...

  • Page 16: Co-200-Cy Keypad Only

    CO-Series Service Manual CO-200-CY KEYPAD ONLY Exterior Part Part Number Description Number Number Description Number Baseplate Stand-Offs See pg. 41 7 *** Baseplate Subassembly, CY See pg. 39 Classroom/Storeroom 23518392 Latch Retractor 46928800 Wiring Harness Office/Privacy 23518384 Cylinder See pg. 48...

  • Page 17: Co-200-Cy Keypad Only

    CO-Series Service Manual CO-200-CY KEYPAD ONLY Interior Part Part Number Description Number Number Description Number 4AA Battery Holder Spring Cage Spring Cage, 23599210 4AA Battery Strap Inside Screws, Spring Cage (2) 4AA Battery Holder & Cover Screws, Battery Strap (2)

  • Page 18: Co-200-Ms Keypad Only

    CO-Series Service Manual CO-200-MS KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 5 *** Baseplate Subassembly, MS See pg. 39 Spindle See pg. 41 ¹⁄₁₆ 46928818 Stand-Offs, MS/MD See pg. 41 Lock Case, Narrow, 1 " wide ¹⁄₄...

  • Page 19: Co-200-Ms Keypad Only

    CO-Series Service Manual CO-200-MS KEYPAD ONLY Interior Number Description Part Number Number Description Part Number 4AA Battery Holder Spring Cage Spring Cage, 23599210 Inside 4AA Battery Strap Screws, Spring Cage (2) 4AA Battery Holder & Cover Screws, Battery Strap (2)

  • Page 20: Co-200-Md Keypad Only

    CO-Series Service Manual CO-200-MD KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 5 *** Baseplate Subassembly, MS See pg. 39 Spindle See pg. 41 ¹⁄₁₆ Stand-Offs, MS/MD See pg. 41 Lock Case, Narrow, 1 " wide 46928834 ¹⁄₄...

  • Page 21: Co-200-Md Keypad Only

    CO-Series Service Manual CO-200-MD KEYPAD ONLY Interior Part Part Number Description Number Number Description Number 4AA Battery Holder Spring Cage Spring Cage, 23599210 4AA Battery Strap Inside Screws, Spring Cage (2) 4AA Battery Holder & Cover Screws, Battery Strap (2)

  • Page 22: Co-200-993-R Keypad Only

    CO-Series Service Manual CO-200-993-R KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 8 *** Baseplate Subassembly, 993 See pg. 39 Baseplate Stand-Offs See pg. 41 Cylinder See pg. 48 Wiring Harness Classroom/Storeroom 23518392 Gasket, Baseplate Tailpiece Gasket Kit, Outside...

  • Page 23: Co-200-993-R Keypad Only

    CO-Series Service Manual CO-200-993-R KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Screws, Battery Strap (2) 4B-E Holder & Cover Kit...

  • Page 24: Co-200-993-S Keypad Only

    CO-Series Service Manual CO-200-993-S KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 8 *** Baseplate Subassembly, 993 See pg. 39 Baseplate Stand-Offs See pg. 41 Cylinder See pg. 48 Wiring Harness Classroom/Storeroom 23518392 Gasket, Baseplate Tailpiece Gasket Kit, Outside...

  • Page 25: Co-200-993-S Keypad Only

    CO-Series Service Manual CO-200-993-S KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Holder Screws, Battery Strap (2) 4B-E & Cover Kit...

  • Page 26: Co-200-993-M Keypad Only

    CO-Series Service Manual CO-200-993-M KEYPAD ONLY Exterior Number Description Part Number Number Description Part Number 8 *** Baseplate Subassembly, 993 See pg. 39 Baseplate Stand-Offs See pg. 41 Cylinder See pg. 48 Wiring Harness Classroom/Storeroom 23518392 Gasket, Baseplate Escutcheon, Gasket Kit, Outside...

  • Page 27: Co-200-993-M Keypad Only

    CO-Series Service Manual CO-200-993-M KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Holder Screws, Battery Strap (2) 4B-E & Cover Kit...

  • Page 28: Co-200/250-Cy, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-CY, ALL MODELS EXCEPT KEYPAD ONLY Exterior CO-200 Shown Here Part Part Number Description Number Number Description Number Escutcheon Latch, Escutcheon CY 23599038 Latch, CY See pg. 50 Screws, Escutcheon Screws, Latch 7 *** Baseplate Subassembly & Reader Module, CY See pg.

  • Page 29: Co-200/250-Cy, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-CY, ALL MODELS EXCEPT KEYPAD ONLY Interior Part Part Number Description Number Number Description Number 4AA Battery Holder Spring Cage Spring Cage, 23599210 4AA Battery Strap Inside Screws, Spring Cage 4AA Battery Screws, Battery Strap Spindle See pg. 41 Holder &...

  • Page 30: Co-200/250-Ms, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-MS, ALL MODELS EXCEPT KEYPAD ONLY Exterior CO-200 Shown Here Number Description Part Number Number Description Part Number Baseplate Subassembly & Reader Module, Strike 5 *** See pg. 39 Strike See pg. 44 Screws, Strike ¹⁄₁₆ 46928818 Lock Case, Narrow, 1 "...

  • Page 31: Co-200/250-Ms, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-MS, ALL MODELS EXCEPT KEYPAD ONLY Interior Number Description Part Number Number Description Part Number 4AA Battery Holder Spring Cage Spring Cage, 23599210 4AA Battery Strap Inside Screws, Spring Cage (2) 4AA Battery Holder & Cover Screws, Battery Strap (2)

  • Page 32: Co-200/250-Md, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-MD, ALL MODELS EXCEPT KEYPAD ONLY Exterior CO-200 Shown Here Number Description Part Number Number Description Part Number Baseplate Subassembly & Reader Module, Strike 5 *** See pg. 39 Strike See pg. 44 Screws, Strike ¹⁄₁₆ Lock Case, Narrow, 1 "...

  • Page 33: Co-200/250-Md, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-MD, ALL MODELS EXCEPT KEYPAD ONLY Interior Number Description Part Number Number Description Part Number 4AA Battery Holder Spring Cage Spring Cage, 23599210 Inside 4AA Battery Strap Screws, Spring Cage (2) 4AA Battery Holder & Cover Screws, Battery Strap (2)

  • Page 34: Co-200/250-993-R, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-993-R, ALL MODELS EXCEPT KEYPAD ONLY Exterior CO-200 Shown Here Number Description Part Number Number Description Part Number Escutcheon, MS/ Escutcheon Tailpiece † MD/993 (Assembly 23599046 Twisted Tailpiece Screws, Escutcheon & Screws) Clip, Tailpiece Spindle and Hub Baseplate Subassembly &...

  • Page 35: Co-200/250-993-R, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-993-R, ALL MODELS EXCEPT KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Screws, Battery Strap (2) 4B-E Holder & Cover Kit...

  • Page 36: Co-200/250-993-S, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-993-S, ALL MODELS EXCEPT KEYPAD ONLY Exterior CO-200 Shown Here Number Description Part Number Number Description Part Number Escutcheon, MS/ Escutcheon Tailpiece † MD/993 (Assembly 23599046 Twisted Tailpiece Screws, Escutcheon & Screws) Clip, Tailpiece Spindle and Hub Baseplate Subassembly &...

  • Page 37: Co-200/250-993-S, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-993-S, ALL MODELS EXCEPT KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Holder Screws, Battery Strap (2) 4B-E &...

  • Page 38: Co-200/250-993-M, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-993-M, ALL MODELS EXCEPT KEYPAD ONLY Exterior CO-200 Shown Here Number Description Part Number Number Description Part Number Escutcheon, MS/ Escutcheon Tailpiece † MD/993 (Assembly 23599046 Clip, Tailpiece Screws, Escutcheon & Screws) Cover, Spindle, 993 Spindle and Hub 46929295 Baseplate Subassembly &...

  • Page 39: Co-200/250-993-M, All Models Except Keypad Only

    CO-Series Service Manual CO-200/250-993-M, ALL MODELS EXCEPT KEYPAD ONLY Interior Part Number Description Number Cover Cover COM200C Screw, Cover Baseplate Assembly, 993 23599251 Batteries, AA F206-488 4AA Battery Holder 4AA Battery Strap 4AA Battery Holder Screws, Battery Strap (2) 4B-E &...

  • Page 40: Co-993-Dt

    CO-Series Service Manual CO-993-DT Exterior CO-200 Shown Here Number Description Part Number Escutcheon, MS/ Escutcheon † MD/993 (Assembly 23599046 Screws, Escutcheon & Screws) Cylinder See pg. 48 Gasket, Baseplate Gasket Kit, Outside 46929154 Gasket, Reader Lever, Outside See pg. 45...

  • Page 41: Exterior Escutcheon Assemblies With Reader Modules

    CO-Series Service Manual EXTERIOR ESCUTCHEON ASSEMBLIES WITH READER MODULES Outside Escutcheon Assemblies are used to replace existing Baseplate Subassemblies and Reader Modules. Outside Escutcheons will include outside escutcheon assembly, less lever and cylinder. If a lever or cylinder are required, these must be ordered separately.

  • Page 42: Co-200/250 Coin Cell Battery Replacement

    * Each plate is 0.075" thick, so if two Under Device Plate are required, the over door thickness will increase by more than ¹⁄₈". Note: Please consider door thickness when specifying a new CO-Series lock or ordering a Door Thickness Kit. See page 41 for Door Thickness Kits.

  • Page 43: Door Thickness Kit

    CO-Series Service Manual DOOR THICKNESS KIT The Door Thickness Kit is used to install a lock on a door that is thicker or thinner than 1³⁄₄”. Use the chart below to deter- mine what is needed. This kit can also be used as replacement parts. Locks cannot be installed on doors thicker than 2³⁄₄”...

  • Page 44: Mounting Screw And Spindle Details For Cy, Ms, And Md

    CO-Series Service Manual MOUNTING SCREW AND SPINDLE DETAILS FOR CY, MS, AND MD The charts below show the details of items that vary by door thickness. These parts are not sold individually. They can be purchased within the Door Thickness Kits which are shown on page 41.

  • Page 45: Thin Door Shims

    CO-Series Service Manual THIN DOOR SHIMS Thin Door Shims are used to install a lock on a door that is thinner than 1³⁄₄”. These shims are sold in the Door Thickness Kit and individually. Compatibility: Models CO-100 / CO-200 Types...

  • Page 46: Strike Plates

    CO-Series Service Manual STRIKE PLATES 10-025 10-013 10-072 ANSI, No box Square Corner, T Square Corner, Box Size: Strike with box Size: 1¹⁄₄" x 4⁷⁄₈" Size: 1¹⁄₄" x 4⁷⁄₈" 1¹⁄₈" x 2³⁄₄" Lip Length: Lip Length: 1³⁄₁₆", 1³⁄₈" Lip Length: 1³⁄₁₆", ⁷⁄₈", 1", 1¹⁄₂",...

  • Page 47: Levers

    CO-Series Service Manual LEVERS Levers shown below can accommodate Schlage and Falcon cylinders. Levers listed on page 46 will accommodate additional competitor cylinders. All lever designs are available in finishes 605, 606, 612, 619, 625, 626, 643E and 626AM. Interior Levers...
  • Page 48 CO-Series Service Manual LEVERS CONTINUED LEVERS FOR USE WITH COMPETITOR CYLINDERS Competitor lever designs come in finishes 626 standard, and 605, 606, 612, 619, 625, 643e, and 626 AM with extended lead-times. Lever Design-Part Numbers Order Cylinder Cylinder Type Suffix...

  • Page 49: Spring Cages

    KIL 6 Pin (Schlage & Falcon Cylinders) 46928552 46928602 46928651 RD/JD FSIC 6 Pin (Schlage Cylinders) 46928552 46928610 46928651 SFIC 6 & 7 Pin (Schlage, Falcon, BEST, Corbin GD/BD 46928560 46928669 Russwin, Yale, Medeco Cylinders) LD SA6 KIL 6 Pin (Sargent Cylinders) 46928578 46928628 46928677...

  • Page 50: Tailpieces

    Schlage (6 Pin) 23446339 FSIC (Less) Schlage (6 Pin) 23446339 SFIC Schlage (7 Pin) 23446347 N523-091 23446347 Schlage, Falcon, BEST, Corbin Russwin, † SFIC (Less) 46929456 09-774 46929456 Yale, Medeco (6 & 7 Pin) LD SA6 KIL (Less) Sargent (6 Pin)

  • Page 51: Spring Cage And Tailpieces Kits

    KIL 6 Pin (Schlage & Falcon Cylinders) 23593270 23593346 RD/JD FSIC 6 Pin (Schlage Cylinders) 23593288 23593353 SFIC 6 & 7 Pin (Schlage, Falcon, BEST, Corbin GD/BD 23593304 23593437 23593510 Russwin, Yale, Medeco Cylinders) LD SA6 KIL 6 Pin (Sargent Cylinders)

  • Page 52: Latches

    CO-Series Service Manual LATCHES 13-049 14-049 14-050 14-051 43-001 Backset Description Part Number ¹⁄₂ ¹⁄₈ ¹⁄₄ ³⁄₄" " Size, Square Corner, Electrified Latch, 1 " x 2 " 13-049 ³⁄₄ ¹⁄₈ ¹⁄₄ ³⁄₄" " Size, Anti-Friction Fire Door Latch, 1 "...

  • Page 53: Ordering Procedures

    CO-Series Service Manual ORDERING PROCEDURES How to Order: REQUIRED FIELDS FACTORY DEFAULT AND OPTIONS CO 200 C123 4B 13-049 10-025 1-3/4 1. Series 2. Class Manually Programmable Rights on Lock Rights on Lock Rights on Magnetic Card 3. Chasis: Cylindrical...
