KING COBRA/ KING COBRA-2
SERIES
I I n n s s t t a a l l l l a a t t i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s a a n n d d U U s s e e r r s s M M a a n n u u a a l l
K K C C 5 5 1 1 9 9 6 6 -R R / / K K C C 5 5 1 1 9 9 6 6 -2 2 -R R
R R e e t t r r o o f f i i t t L L o o c c k k f f o o r r I I L L C C O O 1 1 0 0 0 0 0 0 D D o o o o r r P P r r e e p p s s
M M a a n n u u a a l l l l y y P P r r o o g g r r a a m m m m a a b b l l e e C C y y l l i i n n d d r r i i c c a a l l L L o o c c k k
The KC5196-R/KC5196-2-R Manually Programmed Cylindrical locking system is designed to
replace Ilco 1000 Series locks with no modification to the door prep. It can hold up to 120 codes
and/or iButtons. The lock is powered by four, standard AA batteries. Manual emergency mechani-
cal override uses a standard 1-1/8" (or longer) mortise cylinder.
SEE PROGRAMMING GUIDE FOR PROGRAMMING INFORMATION.
FORM 59007-C
06-2007
Advertisement
Table of Contents
Related Manuals for Schlage KING COBRA KC5196-R
Summary of Contents for Schlage KING COBRA KC5196-R
- Page 1 M M a a n n u u a a l l l l y y P P r r o o g g r r a a m m m m a a b b l l e e C C y y l l i i n n d d r r i i c c a a l l L L o o c c k k The KC5196-R/KC5196-2-R Manually Programmed Cylindrical locking system is designed to replace Ilco 1000 Series locks with no modification to the door prep.
- Page 2 INSTALLATION INSTRUCTIONS SCHLAGE KC5196-R/KC5196-2-R 1. VERIFY DOOR PREP: Door prep for Ilco lock should appear as shown. If for any reason it does not, prep the door using hole sizes and dimensions shown.. NOT REQUIRED 5/32" DOOR EDGE LATCH PREP DEEP 1-1/8"...
- Page 3 NUT DRIVER TOOL BEND TAB ON LOCK WASER TO ENGAGE NEAREST NOTCH ON NUT SO CYLINDER DOES NOT LOOSEN DURING NORMAL OPERATION. RECOMMENDED CAM: SCHLAGE EVEREST: P/N B502-948 SCHLAGE CLASSIC: P/N B502-191 LOCK WASHER CYLINDER NOTE BLOCKING RING REQUIRED FOR CYLINDER 1-1/8”.
- Page 4 INSTALLATION INSTRUCTIONS SCHLAGE KC5196-R/KC5196-2-R 4. INSTALL LATCH: 5. SET HAND (IF REQUIRED): Use a 5/32” hex wrench to change the hand of the levers if necessary. Apply Loctite 242 to threads. 6. INSTALL OUTSIDE SPINDLE AND RETRACTOR: Remove and retain the IMPORTANT: latch guard and screw.
- Page 5 INSTALLATION INSTRUCTIONS SCHLAGE KC5196-R/KC5196-2-R 7. PREPARE INSIDE BASEPLATE FOR INSTALLATION: NOTE: BATTERY HOLDER SHOWN IN PLACE. IT MAY BE REMOVED TO PREVENT IT FROM FALLING OUT DURING INSTALLATION. A. Remove hinge screw from inside B. Swing hinge away from baseplate.
- Page 6 INSTALLATION INSTRUCTIONS SCHLAGE KC5196-R/KC5196-2-R 10. MAKE WIRING CONNECTIONS AND SECURE HINGE TO BASEPLATE: CONNECT BATTERY PACK AND OFFICE FUNCTION ONLY: ROUTE WIRING AS SHOWN PLUG IN OUTSIDE ESCUTCHEON HARNESS TO PC BOARD INSTALL BATTERIES AND PLUG IN BATTERY PACK TO PC BOARD 10.
