LOCATION AND FUNCTION OF CONTROLS 1.POWER BUTTON Press it to turn on or off the unit. 2.BAND BUTTON Press it to select your desired radio band AM or FM. 3.CD COMPARTMENT 4.FREQUENCY COUNTER By the pointer, the display shows the frequency of the broadcasting station being received.
Page 3
7. EJECT BUTTON Press it to eject the CD DISC. 8.MUTE BUTTON Press it to reduce the volume level immediately. 9. TUNING KNOB Rotate it to select your desired broadcasting station. 10.LOC BUTTON Press it to select distance reception or local reception. Local control is no effect at AM BAND 11.MODE BUTTON Press it in between CD or radio function.
Page 4
15.BALANCE BUTTON Slide it to get you desired sound balance between left channel and right channel. 16,17. TRACK UP/DOWN BUTTONS a. During CD mode, press Hold the button to allow you to skip forward. b. During CD mode, press Hold the button to allow you to skip backward.
DISC PLAY: Cleaning discs Before playing ,clean the disc with a clean, lint-free, Flip the disc in the direction of the arrow. Note: Do not use so solvents such as benzine, thinners, commercially available cleaners or anti static spray damage the unit: insert a disc with the label surface down, Doing so may damage the unit.
TROUBLE SHOOTING Before going through the check list, wiring connection, should any of the problem persist after check list has been made , consult your nearest service dealer. Symptom Cause The car ignition is not on. No power The fuse is blown Presence of CD disc inside Disc cannot the player...
Frequency range----------------------------------------------88MHz-108MHz Usable sensitivity-----------------------------------------------------------10uV. IF Frequency-----------------------------------------------------------10.7MHz AM SECTION Frequency range-------------------------------------------540KHz-1600KHz LINE -OUT Output-----------------------------------------250mV@FM10%THD POWER. Impedance---------------------------------------------------------------600ohm. CD PLAYER System-----------------------------------------compact disc audio system. Usable disc------------------------------------------------------compact disc. Signal to noise radio -------------------------70dB[1KHz] [IEC-A net work]. Chassis dimensions---------------------------------183[W]X53[H]X160[D]. WHITE (L) RED (R) FUSE YELLOW...
