WIRING CONNECTION
REAR CABINET
ANTENNA JACK
RED
R
RCA LINE OUT
L
WHITE
+
GREEN
LEFT
SPEAKER
-
SPECIFICATION
GENERAL
Power Supply Requirements.......................DC 12 Volts. Negative Ground
Maximum Output Power.........................................................80 Watts
Chassis Dimensions............................................181(W)X147(D)X53(H)
FM SECTION
Frequency Range..........................................................88MHz-108MHz
AM SECTION
Frequency Range........................................................530KHz-1700KHz
AUTO ANT+
YELLOW
FUSE 0.5A
PINK
B+ MEMORY
FUSE 3A
RED
TO +12V BATTERY
GREY
+
RIGHT
SPEAKER
-
BLACK
GROUND
LEGACY
INSTRUCTION MANUAL
ANTI-THEFT FULL DETACHABLE SYSTEM
WITH AM/FM TUNING RADIO
LR185D
Advertisement
Table of Contents
Related Manuals for Legacy LR185D
Summary of Contents for Legacy LR185D
-
Page 1: Wiring Connection
WIRING CONNECTION LEGACY REAR CABINET ANTENNA JACK AUTO ANT+ YELLOW LR185D FUSE 0.5A PINK B+ MEMORY FUSE 3A TO +12V BATTERY RCA LINE OUT INSTRUCTION MANUAL WHITE GREEN GREY LEFT RIGHT SPEAKER SPEAKER BLACK GROUND SPECIFICATION GENERAL Power Supply Requirements.......DC 12 Volts. Negative Ground Maximum Output Power............80 Watts... -
Page 2: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS 10. CLOCK ADJUSTMENT BUTTON When time on display push SET button and H or M button together at the same time to adjust HOUR or MINUTE. When adjustment is completed, release both buttons. 11. BAND BUTTON Press the button to select you desired band.
