CONTENTS Installation .....................3 DIN Front-Mount (Method A) ..................3 Installing the unit ....................3 Removing the unit .....................4 DIN Rear-Mount (Method B) ...................4 How To Remove And Install The Front Panel ............5 Wiring Connection ..................6 Operation .......................7 General Operation ....................7 Radio Operation......................8 CD Operation ......................9 Specification....................10 Trouble Shooting ..................11...
INSTALLATION Notes: • Choose the mounting location where the unit will not interfere with the normal driving function of the driver. • Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and the system work properly. •...
INSTALLATION 1. Dashboard 2. Nut (5mm) 3. Spring washer 4. Screw (5 x 25mm) 5. Screw 6. Strap Be sure to use the strap to secure the back of the unit in place. The strap can be bent by hand to the desired angle. 7.
INSTALLATION HOW TO REMOVE AND INSTALL THE FRONT PANEL 1. Press the release button and pull-off the front panel. Keep the front panel into the case. 2. To install the front panel, insert the panel into the housing and make sure the panel is properly installed, otherwise, abnormalities occurs on the display or some keys will not function properly.
WIRING CONNECTION FOR 2 x 7W WIRING CONNECTION FOR 2 x 7W SYSTEM MAIN UNIT ANTENNA CONNECTOR IGNITION SWITCH (B+) YELLOW MEMORY (GREY) BACK-UP Rch RED RCA CABLE BLACK GROUND (B–) Lch WHITE (FOR RCA LINE OUT VERSION ONLY) BLUE POWER ANTENNA (FOR POWER ANT.
OPERATION COMPACT DISC PLAYER EJECT TONE TUNE GENERAL OPERATION ON/OFF Press PWR button (1) to turn on the unit. Press it again to turn it off. BALANCE Slide BAL button (2) to left or right to adjust sound balance between left and right speakers.
OPERATION RESET BUTTON RESET button (17) is placed on the housing and must be activated with either a ballpoint pen or thin metal object. The RESET button (17) is to be activated for the following reasons: • Initial installation of the unit when all wiring is completed. •...
OPERATION CD OPERATION DISC PLAY Gently insert a compact disc with the label side facing up into the disc slot (13). The disc is then automatically loaded into the unit and starts playing with the first track of the disc. The digital display will indicate the track number and the time of the track. EJECT Press (eject) button (12) to stop CD play and eject CD from slot.
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 163 (D) x 50 (H) mm Tone Controls : ± 10 dB - Bass (at 100 Hz) : ± 10 dB - Treble (at 10 KHz) Maximum Output Power : 7W x 2 (ch) Current Drain...
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom Cause Solution No power. The car ignition switch is If the power supply is properly not on.
