CONTENTS Installation ...3 Remove The Unit From The Dash Board ...4 Operation ...5 General Operation ...5 Radio Operation ...6 CD Operation...7 Wiring Connection ...8 Specification...8...
INSTALLATION Here is the installation diagram. HEX BOLT Precautions 1. Choose the mounting location where the unit will not interfere with the normal driving functions of the driver. 2. Avoid installing the unit where it would be subject to high temperature, such as from direct sunlight, or from hot air, from the heater, or where it would be subject to dust, dirt or excessive vibration.
REMOVE THE UNIT FROM THE DASH BOARD 1. Remove the metal strap attached to the back of the unit. 2. Disconnect all the wires of the unit and the antenna plug. 3. Remove the handle frame from the trim plate. 4.
OPERATION GENERAL OPERATION • ON/OFF Press POWWR button (1) to turn on the unit. Press it again to turn it off. • BALANCE Rotate the button (2) clockwise or anti-clockwise to adjust sound balance between left and right speakers. • VOLUME Rotate the button (3) clockwise or anti-clockwise to adjust volume level.
RADIO OPERATION • BAND Press BND button (7) to change bands as below: • SELECT STATION Rotate the TUNING knob (8) clockwise or anti-clockwise to adjust the frequency upward or downward. • LOCAL/DISTANT Press the LOC/RPT button (9) to select between local setting for reception of strong station and distant setting for reception of weak stations when tuning.
CD OPERATION • DISC PLAY Gently insert a compact disc with the label side facing up into the disc slot (13). The disc is then automatically loaded into the unit and starts playing with the first track of the disc. The digital display will indicate the track number and the time of the track.
IGNITION B(+) LEFT SPEAKER SPECIFICATION General Power Supply Requirements Chassis Dimensions Maximum Output Power CD Player Signal to Noise Ratio Channel Separation Frequency Response Radio Section Frequency Range Intermediate Frequency Usable Sensitivity (Mono) Stereo Separation at 1 KHz Frequency Range...
