Daewoo DTH-29U3 Service Manual page 75

CP830F Service Manual
LOC PART CODE PART NAME
CC523 HCBK104KCA C CHIP CERA
CC524 HCBK102KCA C CHIP CERA
CC526 HCQK220JCA C CHIP CERA
CC527 HCQK220JCA C CHIP CERA
CC528 HCBK102KCA C CHIP CERA
CC549 HCBK104KCA C CHIP CERA
CC550 HCBK104KCA C CHIP CERA
CC551 HCBK104KCA C CHIP CERA
CC552 HCQK270JCA C CHIP CERA
CC553 HCQK270JCA C CHIP CERA
CC556 HCBK102KCA C CHIP CERA
CC560 HCBK102KCA C CHIP CERA
CC561 HCBK104KCA C CHIP CERA
CC567 HCBK102KCA C CHIP CERA
CC568 HCBK104KCA C CHIP CERA
CC569 HCBK102KCA C CHIP CERA
CC570 HCBK104KCA C CHIP CERA
CC601 HCBK102KCA C CHIP CERA
CC602 HCBK102KCA C CHIP CERA
CC617 HCBK104KCA C CHIP CERA
CC620 HCQK309CCA C CHIP CERA
CC621 HCQK309CCA C CHIP CERA
CC622 HCQK680JCA C CHIP CERA
CC629 HCBK104KCA C CHIP CERA
CC631 HCBK104KCA C CHIP CERA
CC635 HCBK104KCA C CHIP CERA
CC665 HCBK222KCA C CHIP CERA
CC667 HCBK222KCA C CHIP CERA
CC680 HCBK102KCA C CHIP CERA
CC701 HCFK103ZCA C CHIP CERA
CC709 HCBK104KCA C CHIP CERA
CC711 HCBK104KCA C CHIP CERA
CC712 HCQK151JCA C CHIP CERA
CC713 HCBK104KCA C CHIP CERA
CC715 HCBK104KCA C CHIP CERA
CC716 HCFK103ZCA C CHIP CERA
CC720 HCFK103ZCA C CHIP CERA
CC726 HCQK330JCA C CHIP CERA
CC727 HCQK330JCA C CHIP CERA
CC730 HCBK104KCA C CHIP CERA
CC737 HCBK102KCA C CHIP CERA
CC742 HCBK102KCA C CHIP CERA
CC744 HCBK102KCA C CHIP CERA
CC777 HCBK104KCA C CHIP CERA
I501 1VSP9402AQ IC CHIP VIDEO
I502 1DDP3315CQ IC CHIP
RC102 HRFT561JCA R CHIP
RC106 HRFT101JCA R CHIP
RC107 HRFT101JCA R CHIP
RC109 HRFT104JCA R CHIP
RC112 HRFT223JCA R CHIP
RC114 HRFT472JCA R CHIP
RC116 HRFT243JCA R CHIP
RC117 HRFT243JCA R CHIP
RC118 HRFT151JCA R CHIP
RC119 HRFT272JCA R CHIP
RC153 HRFT470JCA R CHIP
RC159 HRFT682JCA R CHIP
RC160 HRFT472JCA R CHIP
RC161 HRFT102JCA R CHIP
RC169 HRFT222JCA R CHIP
RC177 HRFT562JCA R CHIP
RC179 HRFT222JCA R CHIP
RC501 HRFT101JCA R CHIP
RC506 HRFT750JCA R CHIP
RC513 HRFT103JCA R CHIP
RC516 HRFT471JCA R CHIP
RC527 HRFT333JCA R CHIP
DESCRIPTION REMARK
50V X7R 0.1MF K 2012
50V X7R 1000PF K 2012
50V CH 22PF J 2012
50V CH 22PF J 2012
50V X7R 1000PF K 2012
50V X7R 0.1MF K 2012
50V X7R 0.1MF K 2012
50V X7R 0.1MF K 2012
50V CH 27PF J 2012
50V CH 27PF J 2012
50V X7R 1000PF K 2012
50V X7R 1000PF K 2012
50V X7R 0.1MF K 2012
50V X7R 1000PF K 2012
50V X7R 0.1MF K 2012
50V X7R 1000PF K 2012
50V X7R 0.1MF K 2012
50V X7R 1000PF K 2012
50V X7R 1000PF K 2012
50V X7R 0.1MF K 2012
50V CH 3PF C 2012
50V CH 3PF C 2012
50V CH 68PF J 2012
50V X7R 0.1MF K 2012
50V X7R 0.1MF K 2012
50V X7R 0.1MF K 2012
50V X7R 2200PF K 2012
50V X7R 2200PF K 2012
50V X7R 1000PF K 2012
50V Y5V 0.01MF Z 2012
50V X7R 0.1MF K 2012
50V X7R 0.1MF K 2012
50V CH 150PF J 2012
50V X7R 0.1MF K 2012
50V X7R 0.1MF K 2012
50V Y5V 0.01MF Z 2012
50V Y5V 0.01MF Z 2012
50V CH 33PF J 2012
50V CH 33PF J 2012
50V X7R 0.1MF K 2012
50V X7R 1000PF K 2012
50V X7R 1000PF K 2012
50V X7R 1000PF K 2012
50V X7R 0.1MF K 2012
VSP9402
DDP3315CQ
1/10 560 OHM J 2012
1/10 100 OHM J 2012
1/10 100 OHM J 2012
1/10 100K OHM J 2012
1/10 22K OHM J 2012
1/10 4.7K OHM J 2012
1/10 24K OHM J 2012
1/10 24K OHM J 2012
1/10 150 OHM J 2012
1/10 2.7K OHM J 2012
1/10 47 OHM J 2012
1/10 6.8K OHM J 2012
1/10 4.7K OHM J 2012
1/10 1K OHM J 2012
1/10 2.2K OHM J 2012
1/10 5.6K OHM J 2012
1/10 2.2K OHM J 2012
1/10 100 OHM J 2012
1/10 75 OHM J 2012
1/10 10K OHM J 2012
1/10 470 OHM J 2012
1/10 33K OHM J 2012
-74-
LOC PART CODE PART NAME
RC530 HRFT103JCA R CHIP
RC532 HRFT223JCA R CHIP
RC550 HRFT102JCA R CHIP
RC551 HRFT471JCA R CHIP
RC560 HRFT102JCA R CHIP
RC568 HRFT102JCA R CHIP
RC569 HRFT151JCA R CHIP
RC580 HRFT821JCA R CHIP
RC581 HRFT102JCA R CHIP
RC582 HRFT102JCA R CHIP
RC583 HRFT102JCA R CHIP
RC584 HRFT821JCA R CHIP
RC585 HRFT911JCA R CHIP
RC586 HRFT911JCA R CHIP
RC587 HRFT821JCA R CHIP
RC591 HRFT393JCA R CHIP
RC595 HRFT271JCA R CHIP
RC598 HRFT271JCA R CHIP
RC602 HRFT104JCA R CHIP
RC661 HRFT103JCA R CHIP
RC662 HRFT103JCA R CHIP
RC712 HRFT101JCA R CHIP
RC713 HRFT391JCA R CHIP
RC715 HRFT103JCA R CHIP
RC718 HRFT223JCA R CHIP
RC720 HRFT101JCA R CHIP
RC721 HRFT151JCA R CHIP
RC722 HRFT241JCA R CHIP
RC723 HRFT391JCA R CHIP
RC724 HRFT102JCA R CHIP
RC725 HRFT103JCA R CHIP
RC729 HRFT103JCA R CHIP
RC730 HRFT223JCA R CHIP
RC731 HRFT223JCA R CHIP
RC732 HRFT103JCA R CHIP
RC733 HRFT473JCA R CHIP
RC734 HRFT103JCA R CHIP
RC735 HRFT223JCA R CHIP
RC736 HRFT103JCA R CHIP
RC737 HRFT682JCA R CHIP
RC738 HRFT000-CA R CHIP
RC739 HRFT000-CA R CHIP
RC740 HRFT000-CA R CHIP
RC741 HRFT682JCA R CHIP
RC742 HRFT682JCA R CHIP
RC743 HRFT682JCA R CHIP
RC750 HRFT183JCA R CHIP
RC770 HRFT332JCA R CHIP
RC790 HRFT512JCA R CHIP
RC799 HRFT472JCA R CHIP
RCA77 HRFT750JCA R CHIP
ZZ200 PTMPJRH29U7FFL PCB MAIN RADIAL AS
C102 CEXF1E470V C ELECTRO
C117 CEXF1H229V C ELECTRO
C121 CEXF1E470V C ELECTRO
C150 CEXF1E100V C ELECTRO
C152 CEXF1E100V C ELECTRO
C153 CEXF1H229V C ELECTRO
C157 CEXF1E100V C ELECTRO
C164 CEXF1E470V C ELECTRO
C188 CEXF1E100V C ELECTRO
C301 CMXM2A224J C MYLAR
C305 CEXF1E221V C ELECTRO
C313 CMXM2A104J C MYLAR
C315 CEXF1H101V C ELECTRO
C320 CBXF1H104Z C CERA SEMI
C350 CCXF1H223Z C CERA
C351 CCXF1H223Z C CERA
DESCRIPTION REMARK
1/10 10K OHM J 2012
1/10 22K OHM J 2012
1/10 1K OHM J 2012
1/10 470 OHM J 2012
1/10 1K OHM J 2012
1/10 1K OHM J 2012
1/10 150 OHM J 2012
1/10 820 OHM J 2012
1/10 1K OHM J 2012
1/10 1K OHM J 2012
1/10 1K OHM J 2012
1/10 820 OHM J 2012
1/10 910 OHM J 2012
1/10 910 OHM J 2012
1/10 820 OHM J 2012
1/10 39K OHM J 2012
1/10 270 OHM J 2012
1/10 270 OHM J 2012
1/10 100K OHM J 2012
1/10 10K OHM J 2012
1/10 10K OHM J 2012
1/10 100 OHM J 2012
1/10 390 OHM J 2012
1/10 10K OHM J 2012
1/10 22K OHM J 2012
1/10 100 OHM J 2012
1/10 150 OHM J 2012
1/10 240 OHM J 2012
1/10 390 OHM J 2012
1/10 1K OHM J 2012
1/10 10K OHM J 2012
1/10 10K OHM J 2012
1/10 22K OHM J 2012
1/10 22K OHM J 2012
1/10 10K OHM J 2012
1/10 47K OHM J 2012
1/10 10K OHM J 2012
1/10 22K OHM J 2012
1/10 10K OHM J 2012
1/10 6.8K OHM J 2012
1/10 0 OHM 2012
1/10 0 OHM 2012
1/10 0 OHM 2012
1/10 6.8K OHM J 2012
1/10 6.8K OHM J 2012
1/10 6.8K OHM J 2012
1/10 18K OHM J 2012
1/10 3.3K OHM J 2012
1/10 5.1K OHM J 2012
1/10 4.7K OHM J 2012
1/10 75 OHM J 2012
DTH-29U7FLF-S
25V RSS 47MF (5X11) TP
50V RSS 2.2MF (5X11) TP
25V RSS 47MF (5X11) TP
25V RSS 10MF TP
25V RSS 10MF TP
50V RSS 2.2MF (5X11) TP
25V RSS 10MF TP
25V RSS 47MF (5X11) TP
25V RSS 10MF TP
100V 0.22MF J BULK
25V RSS 220MF (8X11.5) TP
100V 0.1MF J TP
50V RSS 100MF (8*11.5) TP
50V F 0.1MF Z (TAPPING)
50V F 0.022MF Z (TAPPING)
50V F 0.022MF Z (TAPPING)
