5.4.2 ACQUISITION FEATURES
Multistandard Digital Data Slicer
Parallel Multi-norm Slicing (TTX, VPS, WSS)
Four Different Framing Codes Available
Data Caption only Limited by available Memory
Programmable VBI-buffer
Full Channel Data Slicing Supported
Fully Digital Signal Processing
Noise Measurement and Controlled Noise Compensation
Attenuation Measurement and Compensation
Group Delay Measurement and Compensation
Exact Decoding of Echo Disturbed Signals
5.4.3 PORTS
One 8-bit I/O-port with open drain output and optional I 2 C Bus emulation support (Port 0)
Two 8-bit multifunction I/O-ports (Port 1, Port 3)
One 4-bit port working as digital or analogue inputs for the ADC (Port 2)
One 2-bit I/O-port with secondary functions (P4.2, 4.3, 4.7)
5.4.4
-CONTROLLER I/O PIN CONFIGURATION AND FUNCTION TABLE
PIN
NAME
3
S/SW2
4
S/SW2
5
S/SW1
6
S/SW1
8
RESET out
15
AFT
16
AGC in
17
KEY
18
OCP
21
Mod SW
22
SECAM L
23
IR
24
SOUND INTInput
48
AGC out
51
LED
52
Power
CONFIGURATION
STAND BY
Open Drain
Open Drain
Open Drain
Open Drain
Low
High impedance
High impedance
High impedance
High impedance
High impedance
High impedance
High impedance
input
Sound interrupt input-edge
--
Push Pull
Push Pull - Low
TV ON
Open Drain
Open Drain
Open Drain
Open Drain
Open Drain
High impedance
High impedance
High impedance
High impedance
Push Pull
Push Pull
High impedance
PWM out
Push Pull
Push Pull - High
-53-
CP830F Service Manual
DESCRIPTION
4
3
Source
L
L
Tuner
L
H
AV2-16/9
H
L
AV2-4/3
H
H
AV2-4/3
6
5
Source
L
L
Tuner
L
H
AV1-16/9
H
L
AV1-4/3
H
H
AV1-4/3
Reset video IC s
AFT input? ADC input
AGC input ? ADC input
Keyboard input ? ADC input
Over Current Protection ? Switch
High = Negative modulation, Low =
Positive modulation (L/L ).
Low = L, High =L
Infrared Interrupt input
triggered
Control tuner AGC (TOP)
Low : LED Red
High : LED Green
SMPS operation mode (Burst/ ON)
