DOCUMENT HISTORY

VERSION DATE
V1.00 18/11/02
V1.01 22/11/02

1 MAIN FEATURES

1.1 SPECIFICATIONS

1.1.1 GENERAL

TV standard
Colour system
Sound system
Power
consumption
Sound Output Power
Speaker
Teletext system
Aerial input
Channel coverage
Tuning system
Visual screen size
Channel indication
Program Selection
Aux. terminal
Remote Control
Unit

1.1.2 EURO-SCART 1 (21 Pin)

Pin Signal Description
1 Audio Output Right
2 Audio Input Right
3 Audio Output Left
4 Audio Earth
5 Blue Earth
6 Audio Input Left
7 Blue Input
Creation of document (Author M Hearn) for project CP830 100Hz TV.
Reformatting of the document, plus insertion of Document History section
PAL - SECAM B/G D/K, PAL I/I, SECAM L/L
Tuner PAL, SECAM
AV PAL, SECAM, PAL 60, NTSC M, NTSC 4.43
NICAM B/G, I, D/K, L,
FM 2Carrier B/G, D/K
29"(4:3) Real Flat :84W approx.
7W x 2 (at 60% mod, 10%THD)
12W 8 ohm x2
9 pages memory FASTEXT (FLOF or TOP)
75 ohm unbalanced
Off-air channels, S-cable channels and hyperband
frequency synthesiser tuning system
29" : 68cm
On Screen Display
100 programmes
EURO-SCART 1 : Audio / Video In and Out, R/G/B
In, Slow and Fast switching.
EURO-SCART 2 : Audio / Video In and Out, SVHS In.
AV3 : Audio-Video Jack on front of cabinet.
Headphone jack (3.5 mm) on front of cabinet
SVHS3 (option) : Jack on front of cabinet ? sound
input common with AV3.
R-46G22
Matching value
0.5 Vrms, Impedance < 1 k , ( RF 54% Mod )
0.5 Vrms, Impedance > 10 k
0.5 Vrms, Impedance < 1 k , ( RF 54% Mod )
0.5 Vrms, Impedance > 10 k
0.7 Vpp 0.1V, Impedance 75
COMMENTS
-5-
