6.2 DTH-29U7FLF-S
LOC PART CODE PART NAME
ZZ100 PTACPWH29U7FLS ACCESSORY AS
12000 48B4846G2201 TRANSMITTER REMOCON
13000 4850Q00910 BATTERY
14000 4858213801 BAG INSTRUCTION
ZZ120 PTBCSHH29U7S COVER BACK AS
M211 4852163301 COVER BACK
M211D 4857817610 CLOTH BLACK
M541 4855415800 S/PLATE
M542 485580002207 LABEL SERIAL
ZZ130 PTCACAH29U7FFLS CABINET AS
M211A 7172401612 SCREW TAPPING
M211B 7178301212 SCREW TAPPITE
M211C 4856013600 SCREW SPKR FIX
M352 4853535600 HOLDER CORD
M481 4854864501 BUTTON POWER
M481A 4856716000 SPRING
M491 4851950201 BUTTON CTRL AS
M491A 7178301011 SCREW TAPPING
M561 48556174SD01 MARK BRAND
M681 4856812001 TIE CABLE
M682 4856816300 CLAMP WIRE
P405 4850704N07 CONNECTOR
PWC1 4859903511 CORD POWER
SP01A 7172401212 SCREW TAPPING
SP02A 7172401212 SCREW TAPPING
V901 4859640560 "CRT (PHILIPS 29"") "
V901A 4856215402 WASHER RUBBER
V901B 4856015820 SCREW CRT FIX
ZZ131 58G0000149 COIL DEGAUSSING
ZZ132 48519A4210 CRT GROUND NET
ZZ200 PTFMSJH29U7S MASK FRONT AS
M201 4852083901 MASK FRONT
ZZ201 PTSPPWD830 SPEAKER AS
51000 4858311110 SPEAKER
51100 4850704S30 CONN AS
52000 4858311110 SPEAKER
ZZ206 PTFPMSH28W8FP PCB FILTER MANUAL AS
CF802 CL1UC3474M C LINE ACROSS
LF200 5PS2901N2- FILTER PFC CHOKE
PF01A 4859238620 CONN WAFER
PF02A 4859238620 CONN WAFER
PF02B 4850702N08 CONN AS
PF802 4859242220 CONN WAFER
RF801 DPC7R0M290 POSISTOR
ZZ200 PTFPJBH28W8FP PCB FILTER EYE LET A
A001 4859811824 PCB FILTER
E804 4856310300 EYE LET
E805 4856310300 EYE LET
E806 4856310300 EYE LET
E807 4856310300 EYE LET
E808 4856310300 EYE LET
E809 4856310300 EYE LET
E810 4856310300 EYE LET
E811 4856310300 EYE LET
E812 4856310300 EYE LET
E813 4856310300 EYE LET
E814 4856310300 EYE LET
ZZ290 PTMPMSH29U7FFL PCB MAIN MANUAL AS
10 2193100801 SOLDER BAR
40 2291050314 FLUX SOLVENT
20 2193011101 SOLDER WIRE
30 2291050617P FLUX SOLDER
60 2291051001 FLUX KILLER
C106 CEXF1H221V C ELECTRO
C118 CMXL1J474J C MYLAR
C404 CMYH3C113J C MYLAR
C405 CMYE2J183J C MYLAR
C408 CMYE2G334J C MYLAR
DESCRIPTION REMARK
DTH-29U7FLF-S
R-46G22 (AAA)
AAA R03/NN SUPERGARD
L. D. P. E. T0. 05X250X40
DTH-29U7FLF-S
29U7 HIPS GY
"300 MM 20"" "
150ART P/E FILM (C/TV)
ART 90
DTH-29U7FLF-S
TT2 TRS 4X16 MFZN BK
TT2 WAS 3X12 MFZN BK
SWRM+SECC
NYROLN 66
29U7 (SILVER)
14Q1/M3 SWPA PIE0.5
29U7 4955401+5549601
TT2 WAS 3X10 MFZN
"DAEWOO 28"" BLACK "
NYLON66 DA100
NYLON 6 (V0)
SE100J+172792+USW=500
CW4232 H03VVH2-F=2250
TT2 TRS 4X12 MFZN
TT2 TRS 4X12 MFZN
A68ERF012X044
20''
SWRM+SK5 L=35
DC-29SF
2901H-1015-2P
DTH-29U7FLF-S
29U7 (SILVER)
DTG-28A7FZF
12W 8 OHM SP-58126F
YH025-04+35098+ULW=700
12W 8 OHM SP-58126F
DTH-28W8FZP
0.47MF 1J(UCVSNDF/SV
B82991-S2901-N2
YPW500-02
YPW500-02
YPH500-02+YLT500+USW=300
YFW800-02
96709 (BC)
DTH-28W8FZP
CP-810100X50(246X246/1X8)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
BSR T0.2 (R1.6)
DTH-29U7FLF-S
SN:PB=63:37 3PI(NO FLUX)
IM-1000
RS 60-1.2 1.6A
CF-329D
KFT-7
50V RSS 220MF (10X16) TP
63V 0.47MF MKT
1.6KV 0.011MF J
630V PU 0.018MF J
400V 0.33MF J
-72
LOC PART CODE PART NAME
C415 CEXF2E100V C ELECTRO
C416 CCYR3D471K C CERA
C417 CMYE2G103J C MYLAR
C418 CEYD1H689W C ELECTRO
C604 CEXF1E102V C ELECTRO
C805 CEYN2G181P C ELECTRO
C811 CCYR3D221K C CERA
C812 CH1BFE472M C CERA AC
C813 CEXF2E101V C ELECTRO
C814 CEYF2E470V C ELECTRO
C820 CCYR3A471K C CERA
C823 CEXF1E102V C ELECTRO
C832 CEXF1E102V C ELECTRO
C840 CEXF1C332V C ELECTRO
C841 CEXF1C222V C ELECTRO
C845 CEXF1E102V C ELECTRO
C861 CEXF1E102C C ELECTRO
C866 CCYR3A471K C CERA
C871 CEXF1E102V C ELECTRO
D404 DFMP3FU—- DIODE
D404A 4857027611 HEAT SINK
D404B 7174300811 SCREW TAPPTITE
D820 DBYW76—— DIODE
D860 DBYW76—— DIODE
F801 5FSCB4022R FUSE CERA
I101 1TDA4470M- IC IF
I301 1TDA8358J- IC VERTICAL
I301A 4857028227 HEAT SINK
I301B 7174301011 SCREW TAPPTITE
I601 1MSP3411V3 IC SOUND
I602 1TDA8946J- IC AUDIO
I602A 4857028215 HEAT SINK
I602B 7174301011 SCREW TAPPTITE
I701 1SDA555XFL IC MICOM OTP
I702 1AT24C16PC IC MEMORY
I703 1TS0P1238W IC PREAMP
I801 1STRF6654- IC SMPS
I801A 4857027920 HEAT SINK
I801B 7174300811 SCREW TAPPTITE
I804 1KP1010C— IC PHOTO COUPLER
I806 1DP130—— IC ERROR AMP
I810 TX0202DA— THYRISTOR
I820 1L7805CV— IC REGULATOR
I821 1LD1117V33 IC REGULATOR
I822 1L7808CV— IC REGULATOR
I823 1LD1117V50 IC REGULATOR
I824 1LD1117V18 IC REGULATOR
I826 1LD1117V33 IC REGULATOR
I827 1LD1117V25 IC REGULATOR
JP01 4859102130 JACK EARPHONE
JPA1 4859200401 SOCKET RGB
JPA2 4859200401 SOCKET RGB
JPA3 4859108450 JACK PIN BOARD
JPA4 4859106740 SVHS JACK
L150 58E0000041 COIL AFT
L380 58C0000120 COIL CHOKE
L381 58C0000120 COIL CHOKE
L401 58H0000054 COIL H-LINEARITY
L403 58C0000118 COIL CHOKE
LF801 5PLF24A1— FILTER LINE
M351 4858900002 HOLDER LED AS
M791 4857913304 RUBBER CUSHION
P401 4850705S04 CONN AS
P402 4859242420 CONN WAFER
P501 4850708N15 CONNECTOR
P601 4859231720 CONN WAFER
P801 4859287320 CONN WAFER
PF01 4859238620 CONN WAFER
DESCRIPTION REMARK
250V RSS 10MF (10X20) TP
HIKR 2KV 470PF K 125C
400V PU 0.01MF J
50V RHD 6.8MF (16X35.5)
25V RSS 1000MF (13X20) TP
400V LHS 180MF (25X35)
2KV R 220PF K 125C
AC400V 4700PF M U/C/V
250V RSS 100MF 18X35.5
250V RSS 47MF (16X25
1KV 470PF K 125C
25V RSS 1000MF (13X20) TP
25V RSS 1000MF (13X20) TP
16V RSS 3300MF
16V RSS 2200MF(13X25)TP
25V RSS 1000MF (13X20) TP
25V RUS 1000MF 13X20 TP
1KV 470PF K 125C
25V RSS 1000MF (13X20) TP
FMP3FU
AL EX BK
TT2 RND 3X8 MFZN
BYW76
BYW76
SEMKO F4AH 4A 250V MF51
TDA4470-M
TDA8358J
AL EX ANODIZING
TT2 RND 3X10 MFZN
MSP3411G-PP-B8-V3
TDA8946J
AL EX NO ANODOZING
TT2 RND 3X10 MFZN
SDA555XFL
AT24C16-10PC
TSOP1238WI1
STR-F6654
AL EX NO ANODIZING
TT2 RND 3X8 MFZN
KP-1010C
DP130
X0202DA
L7805CV
LD1117AV33 3.3V TO-220
L7808CV
LD1117AV50 5.0V TO-220
LD1117AV18 1.8V TO-220
LD1117AV33 3.3V TO-220
LD1117AV25 2.5V TO-220
YSC-1537
SR-21A1 (ANGLE TYPE)
SR-21A1 (ANGLE TYPE)
YSC03P-4120-14A
PH-SJ-9505A
TRF-A005
CH-100Q
CH-100Q
TRL-040F
CH-191A
LF-24A1
LH-3P
FR RUBBER SPONGE
YH025-05+YST025+ULW=400
YFW800-04
YH025-08+YBNH250+USW=600
YW025-04
MKS2822 (LOMAX NEW TYPE)
YPW500-02
