Pin No.
Pin Name
40
NC
41
SVM
42
ROUT
43
GOUT
44
BUT
45
GNDO
46
XREF
47
VSUPO
48
VRD/BCS
49
AGND
50
FBLIN1
51
RIN1
52
GIN1
53
BIN1
54
FBLIN2
55
RIN2 / PR
56
GIN2 / Y
57
BIN2/ PB
58
ASG2
59
HCS
60
NC
61
TEST
62
RESQ
63
SCL
64
SDA
65
C0
66
C1
67
C2
68
C3
69
C4
70
C5
71
C6
72
C7
73
VSUPD
74
GNDD
75
Y0
76
Y1
77
Y2
78
Y3
79
Y4
80
Y5
I/O
Description
O
Scan Velocity Modulator
O
Analog Output Red
O
Analog Output Green
O
Analog Output Blue
S
Ground, analog Back End
I
Reference Input for RGB DAC s
S
Supply voltage, Analog Back End
I
DAC Reference, Beam current safety
S
Analog Ground for Analog Matrix
I
Fast Blank1input
I
Analog Red1input
I
Analog Green1 input
I
Analog Blue1input
I
Fast Blank2 input
I
Analog Red2 input / PR Input
I
Analog Green2 input / Y Input
I
Analog Blue2 input / PB Input
S
Analog Shield Ground
I
Half Contrast
I
I
Reset Input, active low
I/O
I2C Bus clock
I/O
I2C Bus data
I
Picture Bus Chroma (LSB)
I
Picture Bus Chroma
I
Picture Bus Chroma
I
Picture Bus Chroma
I
Picture Bus Chroma
I
Picture Bus Chroma
I
Picture Bus Chroma
I
Picture Bus Chroma (MSB)
S
Supply voltage, Digital Circuitry
S
Ground, Digital Circuitry
I
Picture Bus Luma (LSB)
I
Picture Bus Luma
I
Picture Bus Luma
I
Picture Bus Luma
I
Picture Bus Luma
I
Picture Bus Luma
-27-
CP830F Service Manual
