Summary of Contents for Kramer PT-571
-
Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Models: PT-571 HDMI Line Transmitter PT-572 HDMI Line Receiver... -
Page 2: Table Of Contents
Technical Specifications Figures Figure 1: PT-571 HDMI Line Transmitter Figure 2: PT-572 HDMI Line Receiver Figure 3: Connecting the PT-571/PT-572 HDMI Line Transmitter/Receiver Figure 4: CAT 5 PINOUT Tables Table 1: PT-571 HDMI Line Transmitter Features Table 2: PT-572 HDMI Line Receiver Features... -
Page 3: Introduction
2 Ultra-Compact PicoTOOLS™ - 4 units can be rack mounted side-by-side in a 1U rack space with the optional RK-4PT rack adapter 3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com 4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Quick Start
Using twisted pair cable, see section 3.3; about HDMI, see section • Recommendations for achieving the best performance, see section 1 For details of the PT-571 HDMI Line Transmitter and PT-572 HDMI Line Receiver, see sections and 4.2, respectively KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Summarizing The Hdmi Line Transmitter/Receiver System
1 Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non- Kramer CAT 5, CAT 6 and CAT 7a cables may not reach these ranges 2 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances... -
Page 6: About Hdmi
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital audio/video interface, widely supported in the entertainment and home cinema industry. It delivers the highest high-definition image and sound quality. Note that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee. In particular, HDMI: •... -
Page 7: Achieving The Best Performance
PT-572 HDMI Line Receiver, see section 4.1 Your PT-571 HDMI Line Transmitter The Kramer Pico TOOLS PT-571 HDMI Line Transmitter receives an HDMI signal, encodes it, and transmits it over a CAT 5 cable to the PT-572. The PT-571 has: •... -
Page 8: Your Pt-572 Hdmi Line Receiver
OUT RJ-45 Connector Connect to the IN RJ-45 connector on the PT-572 4.2 Your PT-572 HDMI Line Receiver The Kramer Pico TOOLS PT-572 HDMI Line Receiver receives an encoded signal over a CAT 5 cable transmitted from the PT-571, decodes it, and converts it to an HDMI output. The PT-572 has: •... -
Page 9: Connecting The Pt-571 And Pt-572
Figure 3, do the following: 1. Connect the CAT 5 OUT RJ-45 connector on the PT-571 to the CAT 5 IN RJ-45 connector on the PT-572 via a CAT 5 cable (see section 5.1). 2. On the PT-571, connect an HDMI source (for example, a DVD player) to the HDMI IN connector. -
Page 10: Figure 3: Connecting The Pt-571/Pt-572 Hdmi Line Transmitter/Receiver
Connecting the PT-571 and PT-572 Figure 3: Connecting the PT-571/PT-572 HDMI Line Transmitter/Receiver KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 11: Wiring The Cat 5 Line In/Line Out Rj-45 Connectors
Kramer BC-DGKat524 (CAT 5 24 AWG), BC-DGKat623 (CAT 6 23 AWG) and BC DGKat7a23 (CAT 7a 23 AWG) cables , 19” RK-4PT rack adapter 1 Specifications are subject to change without notice 2 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... - Page 12 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 13 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
