Identifying the
LAN+Modem Card
Ports
Inserting the
LAN+Modem Card
I

NSTALLING AND

C
ARD
The dual-function LAN+Modem card has a LAN port and modem port. The
connectors and card ports are color coded. Take care to connect each cable to the
correct card port.
NOTE: When attaching connectors to the LAN+Modem card, insert them with
the icon side up. The connector should seat easily without forcing.
To install the card, slide it into the PC Card slot as shown below. The power to the
computer can be on or off. Without forcing the card, push until it seats firmly.
CAUTION: Forcing the card into the slot may bend the pins. If you do not know
how to insert cards in your computer, refer to the documentation supplied with
your computer on using PC Card (PCMCIA) slots.
C

ONNECTING THE
