Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS FCB Pinnacle 2 and 4 Flavor Units Release Date: March 26, 2007 Publication Number: 629091023INS Revision Date: May 13, 2013 Revision: B Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs... -
Page 2: Contact Information
Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal... -
Page 3: Safety Instructions
Failure to comply could result in serious injury, death or damage to the equipment. CAUTION: Always be sure to keep area around the unit clean and free of clutter. Failure to keep this area clean may result in injury or equipment damage. © 2007-2013, IMI Cornelius Inc. - 1 - Publication Number: 629091023INS... -
Page 4: Parts List
2. 1 - Tape Measure 3. 1 - Sharp Edge Tool (for insulation removal) 4. 1 - Imp Tubing Cutter 5. 1 - Brazing Torch 6. 2 - Brazing Rod Publication Number: 629091023INS - 2 - © 2007-2013, IMI Cornelius Inc. -
Page 5: Replacement Instructions
A. Remove wire connectors to pulse valve, 2 plugs. Set the wires aside. B. Remove wire connectors to hot gas valves, 2 plugs. Set the wires aside. Step 2 Step 1 Figure 3. © 2007-2013, IMI Cornelius Inc. - 3 - Publication Number: 629091023INS... - Page 6 D. Remove insulation on bottom of pulse valves, 2 each. E. Remove barrel inlet thermistors, 2 each, from pulse valve outlets. Figure 5. Remove insulation on bottom of hot gas valves, 2 each. Figure 6. Publication Number: 629091023INS - 4 - © 2007-2013, IMI Cornelius Inc.
- Page 7 8. Carefully make the tube-cut locations on the hot gas valve outlets at 1-3/8” from the backside of the copper T, as shown. Cut hot gas valve inlets, 2 each, with imp tubing cutter. 9. Remove insulation on hot gas valve inlet line (if present). 1‐3/8” Figure 8. © 2007-2013, IMI Cornelius Inc. - 5 - Publication Number: 629091023INS...
- Page 8 10. Carefully mark the tube-cut locations on the hot gas valve inlet at 1-5/8” up from the copper hot gas header, as shown Cut hot gas valve inlet line with imp tubing cutter. 1‐5/8” Figure 9. 11. Remove hot gas valve assembly. Step 2 Step1 Figure 10. Publication Number: 629091023INS - 6 - © 2007-2013, IMI Cornelius Inc.
- Page 9 12. Cover area behind and under braze area with wet legs. Figure 11. 13. Install hot gas valve assembly provided (three braze fittings). Step 1 Step 2 Figure 12. 14. Wrap hot gas and pulse valves with wet rags. © 2007-2013, IMI Cornelius Inc. - 7 - Publication Number: 629091023INS...
- Page 10 Figure 13. 16. Braze the 3 solder joints. Figure 14. 17. Install the new filter/drier using the two braze fittings with the 90° copper elbows, supplied in the kit. Publication Number: 629091023INS - 8 - © 2007-2013, IMI Cornelius Inc.
- Page 11 22. Charge unit to nameplate charge. 23. Remove gauges and rotate control box back into position, re-install 2 screws. 24. Repeat steps 1 and 2 in reverse order to complete the installation. © 2007-2013, IMI Cornelius Inc. - 9 - Publication Number: 629091023INS...
- Page 12 Pinnacle Hot Gas Valve Replacement Installation Instructions Publication Number: 629091023INS - 10 - © 2007-2013, IMI Cornelius Inc.
- Page 14 IMI Cornelius Inc. www.cornelius.com...
