RIBBON SENSOR
LIMITS
iPH REPORT
VIEW
PRINT
44
Displays the values from the ribbon sensor readings (see example below) for
printers equipped with the thermal transfer option, where:
RIBBON ADC LOW
111
RIBBON ADC HIGH
249
Displays the IntelliSEAQ™ printhead report data, including the printer key,
printhead serial number, installation date, and printhead maintenance dates, where:
Outputs the data to the front panel display.
Prints a reference label in the following format:
iPH REPORT
TUE 12:44PM 23MAY2006
4212-HE25-060224-090
PRINTHEAD SERIAL #: 5x-00289
PRINTHEAD MODEL # 163
PRINTER SERIAL # 60430014
PRINTHEAD INCHES 11175
INSTALLATION DATE - INITIAL 02/02/2006
INSTALLATION DATE - LAST 28/ 02/2006
PRINTHEAD CLEANING
CLEAN PROCEDURES: 0
CLEAN COUNTER RESET 0
NUMBER OF INCHES - INITIAL 0
Chapter 4 – Menu System
