Reference
Information
This section provides a procedure for installing button labels and mounting instructions for
the FOX SW8.
•
•

Button Labels

Use either blank 8-button strips in
Generator software (see

Installing Labels in the Switcher Buttons

Install new labels in the switcher front panel buttons as follows:
1.
2.
3.
4.
Button Labels
Mounting the Unit
Button Label Generator Program
Make new labels and cut them out.
NOTE: For best results, print or copy on transparent or translucent material.
Remove the button from the switcher; use a small, flat bladed screwdriver such as an
Extron Tweeker to gently pry a button out from the front panel (see figure 21, below).
T E
Clear Lens
Pry the two
pieces apart.
Separate the two-
piece button here at
the corner.
Figure 21. Illuminated Button Label Replacement
Locate the notch in the corner of one side of the clear button cap lens.
Separate the white backing (diffuser) from the clear button cap (lens); insert the blade of
the small screwdriver into the corner notch and gently twist the blade.
figure 22 on the next page or the Button Label
Base
X T
Diffuser
Button Label
FOX SW8 • Reference Information
on page 18).
