- Page 1 PHOENIX HD SCOOTER PHOENIXHD3 PHOENIXHD4 OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PREFACE AND INTRODUCTION ……..…………………………………… 3 SAFETY NOTICE…………………………………………………………...…. 2.1 Before driving 2.2 While driving 2.3 Labeling 2.4 EMI PARTS INTRODUCTION……………..……………….. ……………………. OPERATION…………………………………………………………………..1 Control panel 4.2 How to operate your scooter 4.3 How to set to freewheel mode DRIVING ON THE ROAD…………………………………………………….. -
Page 3: Preface And Introduction
1 . P R E FA C E A N D I N T R O D U C T I O N lease carefully read this owner’s manual before using the vehicle. Improper use of the vehicle could result in harm, injury or traffic accidents. To ensure that you get the most your scooter, please read this owner’s manual before using. -
Page 4: Safety Notice
For your safety, please follow and adhere to the same traffic laws as pedestrians. Please do not drive your scooter after consuming alcohol or when you are tired. Please be careful when driving your scooter in low light. It has not been designed for use at night. -
Page 5: While Driving
■ Ramps, inclines and drops Do not drive onto steep ramps greater than the specified gradient. Refer to the section entitled “CLIMBING ANGLE” in “9. SPECIFICATION“ Always use a low speed setting when ascending or descending a gradient. -
Page 6: Labeling
6° 8° Figure 1. Maximum Recommended lncline Angles 2.3 Labeling Please carefully read all the labeling on the scooter before drive it. For your future reminding, do not remove them. WARNING Please hold the tiller before loosening the tiller adjustment knob. -
Page 7: Emi
2 . S A F E T Y N OT I C E 2.4 EMI This portion of the content will provide the user with basic information that describes the problems with EMI, known sources of EMI, protective measures either to lessen the possibility or exposure or to minimize the degree of exposure, and suggested action should unexpected or erratic movement occur. - Page 8 2 . S A F E T Y N OT I C E 3. Long-range transmitters and transceivers, such as commercial broadcast transmitter (radio and TV broadcast antenna towers) and amateur (HAM) radios. Note: Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD player, and cassette players, and small appliances, such as electric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your powered scooter.
-
Page 9: Parts Introduction
3 . PA R T S I N T R O D U C T I O N PARTS DESCRIPTION Control panel Seat Anti-tip wheels Basket Seat Rotation Lever Seat Post Knob Charger Socket Battery Pack Seat Height Adjustment Tiller Adjustment Knob Freewheel Lever... -
Page 10: Operation
4 . O P E R AT I O N 4.1 CONTROL PANEL 1. Speed Dial 2. Horn Button 3. Battery Indicator 4. Power Switch 5. Power Eye 4.2 HOW TO OPERATE YOUR SCOOTER ■ Power switch To switch the power on , turn the key clockwise in the ignition. - Page 11 30%),and red indicates that an immediate recharge is necessary. The remaining power suggested by the battery indicator will vary by the actual driving time incurred and how you drive. Repeated starting, stopping, climbing will consume the power more quickly. ■ Main Circuit Breaker (Reset Button) When the voltage in your scooter’s batteries becomes low or...
- Page 12 The batteries should be charged up at least once a week even if the scooter is not used. 2. After charging or replacing a new battery, drive the vehicle for 2-3 minutes to make sure the battery capacity is sufficient.
-
Page 13: How To Set To Freewheel Mode
Freewheel Mode (Fig 4.2)：Pull the lever up and the scooter can be moved manually. Warning Never operate the freewheel lever while seated on the scooter or on an incline! OPERATION OF THE FREEWHEEL LEVER ‧ Always pull UP FIRMLY for freewheel mode ‧ Always push DOWN FIRMLY for drive mode... -
Page 14: Tiller Adjustment
4 . O P E R AT I O N ■ Tiller Adjustment The tiller can be adjusted in to many different positions to suit each driver. 1. Loosen the knob to adjust the tiller to positions you want. (Fig. 4.3) 2. -
Page 15: Driving On The Road
5 . D R I V I N G O N T H E ROA D ■ Starting and Driving Make sure the seat is installed properly. Make sure the tiller has been secured properly. Fold down the armrests so you can rest your arms on them. Turn the power switch to “ON”. -
Page 16: Battery Charging And Care
6 . B AT T E RY C H A R G I N G A N D C A R E 6.1 CHARGING THE BATTERY ■ Method 1: On board Charging (see photograph overleaf) Follow the procedure below step by step: 1. -
Page 17: Battery
6 . B AT T E RY C H A R G I N G A N D C A R E ■ Charging Hours The charging duration is about 6 hours. To ensure optimum performance a 10-hour charge is recommended. But we do not recommend a charging more than 24 consecutive hours. -
Page 18: Replacing Batteries
6 . B AT T E RY C H A R G I N G A N D C A R E The batteries carry a eight-month of manufacturer's warranty. This warranty only covers issues relating to manufacturing faults, and not faults relating to failure to recharge the batteries as instructed above. - Page 19 6 . B AT T E RY C H A R G I N G A N D C A R E Warning 1. The wiring system and charger are well situated in the battery pack while being assembled in plant. Do not attempt to re-locate the wiring system by yourself. The improper layout of wiring system may result in the wires pinched by battery box, which might result in the electronic system failure.
-
Page 20: Inspection And Maintenance
7 . I N S P E C T I O N A N D M A I N T E N A N C E 7.1 INSPECTION Clean the scooter with a damp cloth and dust down approximately once a week to preserve the appearance of the scooter. -
Page 21: Battery And Tire
■ Tires The condition of the tires depends on how you drive and use your scooter. Please check the tread depth regular. Replace the tires when the tread depth is less than 0.5 mm. -
Page 22: Moving About
7 . I N S P E C T I O N A N D M A I N T E N A N C E 7.5 MOVING ABOUT Switch off the power with power key before moving. Always dismount from the scooter before moving. ... - Page 23 7 . I N S P E C T I O N A N D M A I N T E N A N C E Knob lock Warning Always unplug the rear section electrical connector before separating the two sections.
-
Page 24: Assembly
7 . I N S P E C T I O N A N D M A I N T E N A N C E 7.7 ASSEMBLING THE SCOOTER Suggestion The assembly process is essentially the disassembly process in reverse. First study the text and photographs in the disassembly procedure before re-assembling the scooter. -
Page 25: Troubleshooting
8 . T R O U B L E S H O O T I N G ■ TROUBLE SHOOTING If you have trouble with your scooter, you can inspect the following before taking you scooter to the dealer. If you cannot solve the problem, contact your dealer for assistance. Problem Symptom Remedy... -
Page 26: Specification
9 . S P E C I F I C AT I O N S P E C I F I C AT I O N S Model PHOENIX HD 3 PHOENIX HD 4 Dimension (L x W x H mm) 980×550×1010mm 1055×550×965mm (L x W x H inch) -
Page 27: Warranty
For more detail, please see the Warranty Conditions below. Warranty Conditions: Any work or replacement part installation must be carried out by an authorized Drive dealer / service agent. To apply the warranty should your scooter require attention please contact your service provider. - Page 28 PHOENIXHD3/PHOENIXHD4 Motor serial # Key # ……………………………………………………………………………………………………………………………… Warranty Application Form Name 口 Male 口 Female Date of Birth Year Month Address 口 PHOENIXHD3 口 PHOENIXHD4 Model Scooter VIN: Motor Serial No: Key # Date of Purchase Year Month Purchaser Signature...
- Page 29 Drive Medical Design & Manufacturing 99 Seaview Boulevard Port Washington, NY Tel: (516) 998-4600 Fax: (516) 566-2043 www.drivemedical.com...
