Model CB-MIxx
Before use, please read instructions carefully. After installation, store instructions for future reference.
ISO9001:2000
International Certification
Instruction Manual for
Cyber Series Intellectualized-Controlled Screen
Thank you for purchasing a Grandview projection screen.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Grandview Cyber Series CB-MIxx
Summary of Contents for Grandview Cyber Series CB-MIxx
- Page 1 Website: www.grandviewscreen.ca Guangzhou Grandview Crystal Screen Co., Ltd. Thank you for purchasing a Grandview projection screen. P.O. 51 1400 Federal Ind. Zone No. 363, Y ushan West Road, Before use, please read instructions carefully. After installation, store instructions for future reference.
- Page 2 Description Floating wall bracket Top panel Alluninium casing Up buckle Baffle Down buckle Fixing screw Screen fabric Bottom rod Accessaries M5x10 Screw (6pcs) Floating wall bracket (2pcs) 5 40mm Tapping screw & cap (8sets) Ceiling hanger (2pcs) Trigger line ( 1pc ) Externnal IR Receiver (1 Allen key (1pc) Instruction manual (1pc)
-
Page 3: Installation
Installation Warnings Take out all the parts from the packaging and follow the accessagires guideline to ensure you have all parts. The ceiling or wall used for fixture installation must be secure to prevent the screens from falling. There are three installation measures for this product, namely wall mounting, ceiling mounting and ceiling hang. The While installing electrical motors, please hire professionals or your local dealer to ensure safety. - Page 4 3. Loose the Fixing screw to lower down the Baffle all the way. ( Figure 6-7 ) Attention: > Please make sure there is no dust or dirt on the fabric surface before rolling it back to the casing > The recommened working time is less than 50 seconds. The motor will enter overheating protection status and stop working for every continuous 4 minuters operation, user would need to wait for a while until the motor cool down before operating again.
- Page 5 How to use Trigger Control: Ceiling hang installation 1. Insert one end of the signal cable into the Trigger jack of the handle controller, and the other end into the To choose the tapping screws with hanger or other screws with hanger (unprovided) according to ceiling material. DC5V-12V output hole of the projector (Figure 22-23) (Tips: Wood screws...
- Page 6 Operation Instruction Instructions Connecting to the external power: Controller button instruction 1. T ear off the glue cloth fixed on the bottom rod,ensure the bottom rod is not stuck by the casing. 1.To raise screen press "UP . " 2. Switch on the power (within stated voltage). remote controller 2.To hold screen at desired position press STOP .
