GRANDVIEW REPRODUCING GENUINE COLORS
Grandview Crystal Screen Canada Ltd.
#11- 3751 North Fraser Way,
Marine Way Business Centre,
Burnaby, BC, Canada V5J 5G4
Tel: 1-604-412-9777
Fax: 1-604-412-9796
Website: www.grandviewscreen.ca
Guangzhou Grandview Crystal Screen Co., Ltd.
P.O. 511400 Federal Ind. Zone No. 363, Yushan West Road,
Shiqiao, Panyu District, Guangzhou, Guangdong, China
Tel: +8620-8489-9499 Fax: +8620-8480-3343
Website: www.grandviewscreen.com
GRANDVIEW REPRODUCING GENUINE COLORS
Model：CB-MIxxⅡ
Before use, please read instructions carefully. After installation, store instructions for future reference.
ISO9001:2000
International Certification
Cyber Series Integrated Screen
With IR Remote Control
Thank you for purchasing a Grandview projection screen.
Advertisement
Table of Contents
Related Manuals for Grandview Cyber Series CB-MIxx?
Summary of Contents for Grandview Cyber Series CB-MIxx?
- Page 1 Fax: 1-604-412-9796 Website: www.grandviewscreen.ca Guangzhou Grandview Crystal Screen Co., Ltd. Thank you for purchasing a Grandview projection screen. P.O. 511400 Federal Ind. Zone No. 363, Yushan West Road, Before use, please read instructions carefully. After installation, store instructions for future reference.
- Page 2 Description Floating mounting bracket Top panel Aluminum casing Upper groove Locking piece Lower groove Screen fabric Locking screw Bottom Rod Accessories Floating mounting bracket (2pcs) 5×40mm Tapping screw & cap (8sets) M5x10 Screw (6pcs) Ceiling hanger (2pcs) Trigger line ( 1pc ) Remote Controller External IR receiver...
- Page 3 Installation Warnings Take out all the parts from the package and following the accessories guideline ensure all the parts are there. The ceiling or wall used for fixture installation must be secure to prevent the screens from falling. There are three different types of installation available for this product: wall mount, ceiling mount or ceiling hang. While installing electrical motors, please hire professionals or your local dealer to ensure safety.
- Page 4 3.Loosen the locking screw to lower the locking piece down all the way (figure 6-7) Other Control Options Description 1.FM to IR control description: When you insert the Wireless Synchro Converter Receiver into the EXTR slot of the control panel, you can use a FM wireless remote control device.
- Page 5 Insert one end of the signal cord into the computer output jack located on the left side of the screen casing's end cap and the other end of the signal cord to the central control jack, RS232 or Grandview wall switch. (figure 23-24).
- Page 6 Operating Instructions Remote Control Instruction Connecting to an external power source: 1.Remove the glued on cloth on the bottom rod to ensure the rod is free from the casing. Button Function and Operation Instruction : 2.Switch on the power. (with the appropriate voltage) 1.Press UP button to lift the screen 2.Press STOP button to stop the screen 3.Press DOWN button to lower the screen...
