Installation,
configuration
and operation
FRITZ!Box
Fon WLAN 7570 vDSL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fritz!Box Fon WLAN 7570 vDSL and is the answer not in the manual?

Questions and answers

Related Manuals for AVM Fritz!Box Fon WLAN 7570 vDSL

Summary of Contents for AVM Fritz!Box Fon WLAN 7570 vDSL

  • Page 1 FRITZ!Box Fon WLAN 7570 vDSL Installation, configuration and operation...

  • Page 2: Legal Notice

    AVM will not be liable for damages arising directly or indirectly from the use of the manual or the software, nor for incidental or consequential damages, except in case of intent or gross negligence.

  • Page 3: Table Of Contents

    Security and Handling ......7 FRITZ!Box Fon WLAN 7570 vDSL ..... . 9 Package Contents.
  • Page 4 Removing the Program Group ....... .108 FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 5 Bandwidth Management ........137 FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 6 Updates and Software ........139 Support from the AVM Service Team......140 Glossary.

  • Page 7: Iconnecting And Operation

    Security and Handling CONNECTING AND OPERATION Security and Handling What to watch out for When working with the FRITZ!Box Fon WLAN 7570 vDSL, ob- Security serve the following security instructions in order to protect yourself and the FRITZ!Box from harm.
  • Page 8 Security and Handling For detailed information about the symbols, numerals and function keys used in the manual, see the section “Direc- tions for Operation” from page 110. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 9: Fritz!Box Fon Wlan 7570 Vdsl

    FRITZ!Box Fon WLAN 7570 vDSL An Overview The FRITZ!Box Fon WLAN 7570 vDSL is a Private Branch Exchange (PBX) for making telephone calls via the Internet and the fixed-line network. The FRITZ!Box connects your computers directly with your DSL line. Each connected computer can establish an Internet connection over the FRITZ!Box.
  • Page 10 The FRITZ!Box is equipped with an integrated firewall. Firewall When the FRITZ!Box Fon WLAN 7570 vDSL is operated as a router, this firewall protects your network from attacks from the Internet. The FRITZ!Box is equipped with a USB host controller to...

  • Page 11: Package Contents

    Package Contents The following is included in the FRITZ!Box Fon WLAN 7570 vDSL package: FRITZ!Box Fon WLAN 7570 vDSL one power supply unit with a cable for connection to the power mains one DS cable (gray) for connection to a DSL/VDSL and...

  • Page 12: Operation Requirements

    DSL software FRITZ!DSL, the minimum computer requirements are: – Pentium III processor comparable) with Windows Vista (32-bit) or Windows XP (32-bit) and CD drive – 128 MB RAM – 40 MB free memory on the hard drive FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 13: Connecting

    FRITZ!Box. Insert the FRITZ!Box CD in the CD-ROM drive of your computer. The Installation Help starts automatically. Follow the instructions in the Installation Help to pre- pare the FRITZ!Box for operation. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 14 If you want to connect an ISDN telephone or an ISDN PBX to the FRITZ!Box, please read the sections “Con- necting ISDN Telephones” on page 27 as well as “Con- necting ISDN PBXs” on page 28. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 15: Mounting On A Wall

    Mounting on a Wall Mount the wall holder included in the package on the wall. Mounting the wall holder for the FRITZ!Box Place the FRITZ!Box on the wall holder and slide it into posi- tion. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 16: Connecting To Electrical Power

    Connecting to Electrical Power Attaching the FRITZ!Box to the wall holder Connecting to Electrical Power Connecting to the power supply Set aside the power supply unit out of the FRITZ!Box package. Connecting FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 17: Connecting The Computer(S)

    FRITZ!Box at the same time. The computer is connected to the FRITZ!Box in the same way regardless of the operating system on the computer. All of the computers connected with the FRITZ!Box constitute a network. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 18: Connecting Computer(S) To The Lan Port

    Connect the other end of the LAN cable to a socket on the FRITZ!Box labeled “LAN 1”, “LAN 2”, “LAN 3” or “LAN 4”. Now the FRITZ!Box and computer are connected to each other. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 19 You can connect a network hub or switch to one of the LAN ports on the FRITZ!Box if you would like to connect multiple computers to the FRITZ!Box via LAN. Connecting FRITZ!Box to a network hub Set aside the network cable (yellow) from the FRITZ!Box Connecting package. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 20: Connecting Computer(S) Wirelessly Via Wlan

    For more information on WLAN, see the section “More about WLAN” from page 120. Connecting the FRITZ!WLAN USB Stick If you are using a AVM FRITZ!WLAN USB Stick N or a AVM Connect FRITZ!WLAN USB Stick as a WLAN adapter, you can transmit the security settings of the FRITZ!Box to your FRITZ!WLAN Stick quickly and conveniently using AVM Stick &...
  • Page 21 FRITZ!WLAN USB Stick N are connected with each other wirelessly For more information, see the manual for the AVM FRITZ!WLAN USB Stick N or the manual for the AVM FRITZ!WLAN USB Stick. Using WLAN adapters from Other Manufacturers Proceed as follows to install a WLAN adapter from another...
  • Page 22 Using WLAN adapters from Other Manufacturers SSID (name of the FRITZ!Box Fon WLAN 7570 vDSL WLAN radio network) Encryption method WPA (TKIP) or WPA2 (AESCCMP) Encryption WPA PSK The key is printed on the stickers on the base of the device and on the cover of the FRITZ!Box CD.

  • Page 23: Connecting To The Dsl/Vdsl Line

    FRITZ!Box will be established. Connecting to the DSL/VDSL Line Connecting to the DSL/VDSL splitter The gray cable is for connecting to the DSL/VDSL splitter. Connecting This cable is a combination of a DSL and VDSL cable. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 24: Connecting To The Isdn Line

    Connecting to the ISDN Line Your telephone line is either an analog line or an ISDN line. If you have an ISDN line, read here how to connect the FRITZ!Box with the ISDN line. Connecting to the ISDN NT FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 25: Connecting With The Analog Telephone Line

    Connecting to the analog telephone line via the DSL/VDSL splitter Set aside the green cable delivered in the package. Connecting Connect the longer gray branch of the cable to the socket on the FRITZ!Box labeled “ ”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 26: Connecting Telephone, Fax, Or Answering Machine

    Analog devices with an RJ11 plug are connected to the RJ11 sockets “FON 1” or “FON 2” located on the back panel of the FRITZ!Box using the TAE/RJ11 adapter included in the package. Connecting an analog telephone to an RJ11 jack FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 27: Connecting Isdn Telephones

    Use an ISDN cable to connect an ISDN telephone. Connecting Connect one end of the ISDN cable with the ISDN tele- phone. Connect the other end of the ISDN cable with the “S int” port of the FRITZ!Box. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 28: Connecting Isdn Pbxs

    Connect the other end of the ISDN cable with the “S int” port of the FRITZ!Box. If you have no more than two analog devices con- nected to the PBX, you can connect them directly to the FRITZ!Box and do without the PBX. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 29: Opening The User Interface

    This settings file can be loaded back into your FRITZ!Box at any time. The FRITZ!Box features a Wizard to accompany you step by step through the process of saving and restoring your set- tings. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 30: Internet Connections

    Select the “Advanced Settings” menu in the “Set- tings” area. Select “Internet / Account Information”. Configure the desired settings. Take advantage of the Online Help available in the FRITZ!Box user interface for more information and instructions. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 31 VDSL modem or a router, or integrated into an existing net- work, you must also configure your Internet connection as described above. To do so, enable the expert mode in the “System / Expert Mode” menu. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 32: The Dect Function

    To register a cordless phone on the FRITZ!Box, please follow the corresponding instructions in your telephone manual. Press and hold down the search key on the FRITZ!Box la- beled “DECT” during the entire registration process. This facilitates telephone registration. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 33: Making An Internal Call To A Cordless Phone

    In the “Start Menu” area, select the “Telephony De- vices” menu. In the “Cordless Phones (DECT)” area, select the cord- less phone you want to log off and click the “Delete” button. Now the cordless phone will be logged off. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 34: Switching The Dect Function On And Off

    The DECT function is switched on when the first cord- less phone is registered. Switching off the DECT function When the last cordless phone is logged off in the FRITZ!Box user interface, the DECT function is switched off automatically. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 35: Telephone Connections

    If you used the Basic Configuration Wizard after connecting your FRITZ!Box and entered numbers then, these numbers are already entered in your FRITZ!Box. In this case you can start right away with the configuration of the connected te- lephony devices. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 36: Configuring Telephony Equipment

    Telephony Devices” Wizard is available in the FRITZ!Box. Telephony Devices Supported The following telephony devices are supported by the FRITZ!Box: telephones – analog telephones – ISDN telephones – telephones with an integrated answering machine – cordless (DECT) phones FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 37 Internet or the fixed-line net- work. – call acceptance: Specify here whether the tele- phone should react to all calls or only to calls for certain telephone numbers. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 38: Functions And Settings For Telephony

    If the number of a caller or someone called is entered in the Telephone Book, the Call List will display the name from the Telephone Book. The Call List can be saved as a file. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 39 Telephone Book Telephone Book A Telephone Book is at your disposal in the FRITZ!Box. If an AVM handset is registered at the FRITZ!Box, the Tele- phone Book can be transferred to the handset. Call Diversion With this function you can divert incoming calls to another number.
  • Page 40 To check an answering machine internally, enter the follow- ing keypad sequences: ss600 Answering machine 1 ss601 Answering machine 2 ss602 Answering machine 3 ss603 Answering machine 4 etc. etc. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 41: The Answering Machine Menu

    Select a greeting during monitoring Record greeting > End with 1 Listen to “Recording and selection” menu again Back to Main menu Listen to “Record greetings” menu again Back to main menu Listen to main menu again FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 42: Usb Devices

    The FRITZ!Box is equipped with a USB port (also known as a USB host controller). Various USB devices can be connected to the host controller: an AVM FRITZ!WLAN USB Stick N or an AVM FRITZ!WLAN USB Stick a USB mass storage device (hard drive, memory stick)

  • Page 43: Accessing Usb Devices

    USB remote connection function. The USB device is detected as new hardware by the operating system on this computer, so that device software can be in- stalled as if it were connected directly to the computer. The FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 44 Enable the expert mode option of the FRITZ!Box in the “System / Expert Mode” menu. Confirm by clicking “Apply”. Open the “USB Devices / Overview of Devices” menu. Select the setting “Enable USB remote connection” and click “Apply”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 45 Open the “USB Devices / USB Remote Connection” menu. Disable all types of USB devices. As a final step, click “Apply”. The result of the changed USB settings can be viewed in the “Overview of Devices”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 46: Usb Mass Storage Devices

    Select the “Advanced Settings” menu in the “Set- tings” area. Select the “USB Devices / Mass Storage Devices” menu. Configure the access rights and password protection for the USB mass storage devices. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 47 (streaming). The hard drive with the music collection is simply connected to the USB port of the FRITZ!Box and a suitable playback de- vice is integrated into the local network. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 48: Usb Printers

    USB remote connection. These printers usually can be used only with an operating system for which the printer manufacturer has provided driver software. Such printers connected to the FRITZ!Box are not sup- ported as network printers. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 49 If you want to use the printer with the USB remote connec- tion enabled, then any computer that is to use the printer must have the program for the USB remote connection (see page 44) and the suitable printer drivers installed. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 50 You must make this selection because the printer port on the computer functions as a local port. Select the setting “Use an existing port” and then choose the entry “AVM: (FRITZ!Box USB Printer Port)” from the list. Click “Next”. Select the manufacturer for the USB printer connected to the FRITZ!Box from the “Manufacturers”...
  • Page 51 Click “Next”. In the “Select a Printer Port” window, select the option “Use the following port” and select “AVM: (FRITZ!Box USB Printer Port)” from the list field. Click “Next”. Select the manufacturer for the USB printer connected to the FRITZ!Box from the “Manufacturers”...
  • Page 52 CUPS printing software is included in the follow- ing documentation: http://www.cups.org/documentation.php Configuration questions should also be directed to the manufacturer of the Linux distribution or to an Internet or usenet forum that deals with CUPS or the distribution used. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 53 If the printer cannot be selected, it may be possible to select a compatible printer or printer driver. Click the “Add” button to save your settings. The printer is then available to all computers connected wi- th the FRITZ!Box. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 54: Fritz!Wlan Usb Stick N And Fritz!Wlan Usb Stick

    For more information, see the section “More about WLAN” from page 120 and the manual for the FRITZ!WLAN USB Stick. With the AVM Stick & Surf technology it is easy to establish AVM Stick & Surf a secure WLAN connection. Stick & Surf is possible with the FRITZ!WLAN USB Stick N and with the FRITZ!WLAN USB Stick.

  • Page 55: Usb Hub

    You can connect two USB mass storage devices and one USB printer, or three USB mass storage devices (like a hard drive or memory stick) to the USB hub. We strongly advise to use a USB hub with its own power supply. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 56: Tips For Using Usb Devices

    Y cable) only if they have their own power supply or a USB hub with its own power supply. AVM has no influence over external interference to the USB storage devices on the FRITZ!Box. Thus such phe-...

  • Page 57: Configuration And Operation At The Telephone

    You may first configure all of your settings as desired, and then save them permanent- Permanent saving cannot be reversed. However, you can reprogram different settings or restore the FRITZ!Box to its factory settings. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 58 This means that the WLAN func- tion can be enabled without having use a wired connection to open the user interface. Enable/Disable WLAN r96s1s enables the WLAN function r96s0s disables the WLAN function FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 59 <Ext.> Enable Do Not Disturb for a Prescribed Period r80<Ext.>s defines the period for Do Not Disturb at extension <Ext.> <Start>s<End>s r91ss saves the settings r81<Ext.>s6s enables Do Not Disturb for the defined pe- riod FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 60 <Ext.>s ring r91ss saves the settings Enable/Disable the Alarm Function r881ss enables the alarm function for all ex- tensions for which an alarm time was r881r disables the alarm function for all ex- tensions FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 61 Internet numbers. Call Forwarding Immediately for Your Outgoing Caller ID Pick up the handset. s21s<DNo>r Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 62 Wait for the acknowledgement tone. Hang up the handset. Disable Call Forwarding Immediately for Any MSN Pick up the handset. s21ss<MSN>r Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 63 Wait for the acknowledgement tone. Hang up the handset. Call Forwarding When Busy for Any MSN Pick up the handset. s67s<DNo> Dial the sequence shown at left. s<MSN>r Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 64 Wait for the acknowledgement tone. Hang up the handset. Disable Call Forwarding When Busy for All MSNs Pick up the handset. s67ssr Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 65 Wait for the acknowledgement tone. Hang up the handset. Call Forwarding Delayed for All MSNs Pick up the handset. s61s<DNo>sr Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 66 Wait for the acknowledgement tone. Hang up the handset. Disable Call Forwarding Delayed for All MSNs Pick up the handset. s61ssr Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 67 Call Diversion Immediately (Without Ringing) Pick up the handset. r41<Ext.>s Dial the sequence shown at left. <DNo>/<Ext.>s r91ss Save your settings if desired by di- aling the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 68 Call Diversion After the Third Ring or When Busy Pick up the handset. r44<Ext.>s Dial the sequence shown at left. <DNo>/<Ext.>s r91ss Save your settings if desired by di- aling the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 69 Hang up the handset. Disable Call Diversion Pick up the handset. r40<Ext.>ss Dial the sequence shown at left. r91ss Save your settings if desired by di- aling the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 70 Hang up the handset. Disable Call Waiting Pick up the handset. r2 <Ext.> s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 71 Hang up the handset. CLIR on a Case-by-Case Basis Pick up the handset. s31r Dial the sequence shown at left. Now you hear the external dial tone. Dial the number you want to call. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 72 The caller’s display will continue to show the number that was actually dialed. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 73 Pick up the handset. r53<Ext.>s0s Dial the sequence shown at left to enable transmission of the connected line’s num- ber. r91ss Save your settings if desired by dialing the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 74 Hang up the handset. Enable Automatic Outside Dialing Pick up the handset. r1<Ext.>s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 75: Operation At The Telephone

    You have the possibility of shortening the dialing procedure by closing your entry with the r key. Shorten the Dialing Procedure <number> r indicates that a number has been dialed to shorten the dialing procedure FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 76 “List of Internet Numbers”. Making Internal Calls All calls conducted between telephones connected to the FRITZ!Box, be they analog or ISDN/DECT phones, are inter- nal telephone calls. These calls are free of charge. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 77 (for instance, 51). 5<MSN> If you would like to call an ISDN terminal de- vice that does not have an internal phone number, dial 5, followed by the MSN that was saved in the ISDN terminal device. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 78 Pick up a Call Pick up the handset. Dial the sequence shown at left. The call is now connected to your extension and you can talk to the caller. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 79 20 seconds, as it would for an external call. When you pick up your handset, the number of desired party will be dialed automatically. “Call Back on Busy” can be used for both external and in- ternal connections. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 80 “Call Back on No Response” can be used both for external and internal connections. This command can be activated five times for each line. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 81 Callback requests can also be deleted manually, with the oldest callback request being deleted first. Delete Callback Requests Manually Pick up the handset. r37r Dial the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 82 In this case the phone rings as soon Call as you hang up. Pick up the handset again to re- turn to the last call that was on hold. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 83 The connection that was active last before you initiated the three-party conference is now active again. The other call is on hold. You can alternate between the two connections by dialing the same sequence again. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 84 Caller 2. In this case, your phone rings as soon as you hang up. Pick up the handset to return to Caller 1 again. Hang up the handset to end the connection. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 85: Transferring Calls

    Dial the sequence shown at left. The connection on hold and the active connection are connected with each other. The external parties continue the call while you clear the connection. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 86 Dial the sequence shown at left. The connection on hold and the active connection are connected with each other. The external parties continue the call while you clear the connection. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 87 With this type of external transfer, both parties are con- nected to each other over your PBX. This means that both B channels on your ISDN line remain busy with this con- nection as long as the parties are connected to each other. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 88 You will need to enter this code again when you resume the call. After the acknowledgement tone, the connection is suspended. You can hang up the handset. The call remains suspended at the ISDN provider’s lo- cal switch for two minutes. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 89 Wait for the acknowledgement tone. The baby monitoring phone function is now enabled. Do not hang up the handset! Dial the number of the extension to listen in at an extension with room monitoring activated. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 90 Enter a Keypad Sequence on an Extension without Automatic Outside Dialing Pick up the handset. 0sr<Seq> Dial the sequence shown at left. <Seq> stands for the keypad sequence you received from your tele- phone carrier. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 91: Troubleshooting

    Restart the FRITZ!Box. Remove the power cable from the socket. Wait about five seconds before reconnecting to the power supply. Try again to open the FRITZ!Box user interface by en- tering fritz.box in the address field. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 92 In the web browser, enter the following IP address in place of fritz.box: 192.168.178.1 If the user interface cannot be reached via this ad- dress, check the settings configured for your network adapter as described in section “IP Settings” from page 102. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 93 Internet Explorer 6: Select the “Connections” settings page under “Tools / Internet Options...”. In the “Dial-up and Virtual Private Network settings” section, enable the option “Never dial a connection”. As a final step, click “OK”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 94 Select the “Connections” settings page under “Tools / Internet Options...”. Click the “LAN Settings...” button in the “Local Area Net- work (LAN) settings” area, and in the next window, click the “Advanced...” button in the “Proxy server” area. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 95 In the next window, click the “Advanced...” button and enter in the “Add this Web site to the zone:” field: fritz.box Disable the option “Require server verification (https:) for all sites in this zone”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 96 “Connecting Computer(s) to the LAN Port” from page 18. Make sure that the computer obtains its IP address automatically. You can check this setting in the com- puter’s IP settings (see section “IP Settings” from page 102). Restart your computer. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 97: The Wlan Adapter Cannot Find Fritz!Box

    10.2 The WLAN Adapter Cannot Find FRITZ!Box If the radio network “FRITZ!Box Fon WLAN 7570 vDSL” is not found by the WLAN adapter of a computer, work through the following steps to find the source of the error and re- solve it.
  • Page 98 Start a web browser. Enter fritz.box in the address field. Select the “Settings” menu. Select the “Advanced Settings / WLAN / Radio Set- tings” menu and enable the setting “Announce name of the radio network (SSID)”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 99: Wlan Connection Is Not Established

    Print out this page by clicking the “Print Page” button at the upper left of the page. Remove the network cable and check the configura- tion of the WLAN adapter in the printout. Try again to establish a connection. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 100 WLAN adapter and contact the manufac- turer of the WLAN adapter if necessary. Enable WLAN encryption again after completing the tests. Follow the steps listed above and then enable the kind of encryption that was previously configured. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 101 Proceed as described in the section “Connect- ing Computer(s) to the LAN Port” from page 18. Start a web browser. Enter fritz.box in the address field. Select the “Settings” menu. Open the “Advanced Settings / WLAN / Radio Set- tings” menu. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 102: Ip Settings

    FRITZ!Box. Click the right mouse button and select “Properties”. If the “User Account Control” window is displayed, click “Continue” in this window. Under “This connection uses the following items”, se- lect the “Internet Protocol Version 4 (TCP/IPv4)” entry and click “Properties”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 103 Click the “Properties” button. Select “Internet Protocol (TCP/IP)” in the list of items used in this network connection and click “Proper- ties”. Enable the options “Obtain an IP address automatical- ly” and “Obtain DNS server address automatically”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 104: Windows 2000

    Select “Start / Settings / Control Panel / Network and Dial-up Connections”. Double-click to select the LAN connection with the net- work adapter bound to FRITZ!Box. Click the “Properties” button. Double-click to select “Internet Protocol (TCP/IP)” in the list of network components. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 105 In the “Network” window, select the “Built-in Ether- net” entry from the “Show:” drop-down menu. Switch to the “TCP/IP” settings page and select the “Using DHCP:” option from the “Configure IPv4” drop- down menu. Click “Apply Now”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 106 The computer now receives an IP address from the FRITZ!Box. Obtaining an IP Address Automatically in Linux For comprehensive information and tips on the topic of net- work configuration in Linux, see, for example: http://www.tldp.org/HOWTO/NET3-4-HOWTO-5.html FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 107: Uninstallation

    WLAN, deactivate the WLAN connection to FRITZ!Box in the WLAN adapter of the computer. 11.2 Removing the Printer Port The AVM FRITZ!Box printer port is removed using the Con- trol Panel of the Windows operating system. Removing the Printer Port in Windows Vista Open “Start / Settings / Control Panel / Programs and...

  • Page 108: Removing The Program Group

    Open “start / Control Panel / Add or Remove Pro- grams”. Make sure that the “Change or Remove Pro- grams” button is selected in the left-hand column. Select the “AVM FRITZ!Box Printer Port” entry from the list of “Currently installed programs”. Click the “Change/Remove” button.
  • Page 109 Open “start / Control Panel / Add or Remove Pro- grams”. Make sure that the “Change or Remove Pro- grams” button is selected in the left-hand column. Select the “AVM FRITZ!Box Documentation” entry from the list of “Currently installed programs”. Click the “Change/Remove” button.

  • Page 110: Directions For Operation

    Directions for Operation Symbols, Keys and LEDs The following sections present important information and tips for opera- tion of the FRITZ!Box Fon WLAN 7570 vDSL. 12.1 Symbols and Highlighting This symbol indicates useful hints to assist you in working with the FRITZ!Box.

  • Page 111: The Telephone Keypad

    In the place of the abbreviation <DNo>, enter the complete number of the external line. <DNo./Ext.> Enter the external telephone number (desti- nation number) or extension number (Ext.) to which your calls are to be diverted. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 112: Leds

    Update firmware is being updated DECT the DECT function is enabled flashes registration procedure for a DECT handset in progress Online an Internet connection is established Internet a telephone connection to the Internet is active FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 113: Handset And Ring Patterns

    Internal dial tone External dial tone Positive confirmation Neg. acknowledgment Call waiting Calls External call Internal call Call back Internet telephony Registration error Fixed-line substitute Handset and ring patterns on FRITZ!Box Fon WLAN 7570 vDSL FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 114: Product Details And Useful Information

    Telephone Cable The DSL/VDSL cable is a special combined cable developed by AVM to connect the FRITZ!Box Fon WLAN 7570 vDSL to the DSL/VDSL splitter and the ISDN NT or analog telephone line. If you need a longer cable, you can extend one or multiple ends of the combined cable using RJ45 double couplings.

  • Page 115: Wlan Button

    Network Cable Network Cable Additional network cable is required if you would like to use all of the FRITZ!Box Fon WLAN 7570 vDSL network ports. The FRITZ!Box Fon WLAN 7570 vDSL network cable (yellow) is a standard Ethernet cable. If you need a replacement ca- ble, a longer cable or an extension, use a standard STP-type (Shielded Twisted Pair, 1:1) CAT5 Ethernet cable.

  • Page 116: Technical Specifications

    IEEE 802.11a – 54 Mbit/s – IEEE 802.11b – 11 Mbit/s – IEEE 802.11g – 54 Mbit/s – IEEE 802.11n draft 2.0 – 300 Mbit/s Router Function DSL/VDSL router DHCP server Firewall with IP masquerading/NAT FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 117: Physical Specifications

    Physical Specifications Dimensions (WxDxH): approx. 210 x 155 x 25 mm Supply voltage: 230 V / 50 Hz Maximum power consumption: 16 W Average power consumption: 6 W Firmware can be updated Conform to CE standards FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 118: Declaration Of Ce Conformity

    The manufac- AVM GmbH turer Alt-Moabit 95 D-10559 Berlin herewith declares that the product FRITZ!Box Fon WLAN 7570 vDSL Type: ADSL/VDSL WLAN Router complies with the following directives: 1999/5/EC R&TTE Directive: Radio Equipment and Telecommunica- tions Terminal Equipment 2004/108/EEC EMC Directive: Electromagnetic Compatibility...

  • Page 119: Disposal

    Electronic Equipment Act (ElektroG), the FRITZ!Box Fon WLAN 7570 vDSL, as well as all devices and electronic com- ponents contained in the FRITZ!Box Fon WLAN 7570 vDSL package may not be disposed with household waste. Please bring these to your local collection points for dispos-...

  • Page 120: More About Wlan

    54 Mbit/s 25 Mbit/s 802.11n 2.4 / 5 GHz 300 Mbit/s 100 Mbit/s The throughputs listed differentiate between gross and net transmission rates. The net speed describes the transmis- sion rate of the user data. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 121 Input, Multiple Output) use the entire frequency band available more effectively than the older standards. The use of the 802.11n standard—and thus the availability of higher throughput rates—is possible only if the WLAN connection is secured using the WPA2 security mechanism (AES-CCMP). FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 122: Security

    WLAN to use its Internet access or shared net- work resources. FRITZ!Box includes settings on various levels that contrib- ute to the security of your WLAN and thus to the security of your computers. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 123 WPA (TKIP) or WPA2 (AES-CCMP) or both methods. It is advisable to change the preconfigured WLAN key as soon as possible. Changes to the settings can be config- ured on the FRITZ!Box user interface. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 124 We strongly recommend the use of a WLAN adapter that supports WPA or WPA2 (for instance, the FRITZ!WLAN USB Stick N). WEP is out of date and data encrypted with WEP can be deciphered within minutes. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 125: Frequency Ranges

    Caused by Other Wireless Networks” from page 101. The FRITZ!Box can operate in the 5-GHz frequency band as 5-GHz Frequency Band an alternative. This frequency range is used much less of- ten than the most common 2.4-GHz frequency range. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 126 Maximum Data Throughput (Mbit/s) Increasing bandwidths also increases the probability of in- terference by wireless networks in the vicinity. Large band- widths reduce the frequency range available to other wire- less networks in the vicinity. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 127 Allocation of the WLAN channels in the 5-GHz range: Channel Frequency (GHz) Channel Frequency (GHz) 5.180 5.540 5.200 5.560 5.220 5.580 5.240 5.600 5.260 5.620 5.280 5.640 5.300 5.660 5.320 5.680 5.500 5.700 (20 MHz band- width only) 5.520 FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 128: More About Network Settings

    Upon delivery, the network settings of the FRITZ!Box are preconfigured as follows: Factory Settings All computers are located in the enabled same IP network IP address 192.168.178.1 Subnet mask 255.255.255.0 DHCP server enabled FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 129: Ip Address

    What IP address must you assign for the FRITZ!Box and IP Address what else must be taken into consideration? The IP address must come from the address range of your existing subnet. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 130 “Show expert settings” and confirm this set- ting by clicking “Apply”. Open the “System / Network Settings” menu. Click the “IP Addresses” button. Make the changes on the “IP Settings” page and then click “Apply”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 131: Dhcp Server

    200 in the fourth group of numerals of the IP address are reserved for the DHCP server. Assigning the IP addresses via the DHCP server ensures that all of the computers connected with the FRITZ!Box are located in a single subnet. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 132 FRITZ!Box even when the DHCP server is disabled, you must enter the IP addresses manually in the comput- er’s network settings. First disable the option “Obtain an IP address automatically” and then enter the IP address man- ually in the appropriate field. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 133: Subnetwork

    IP network” is enabled in the FRITZ!Box. Factory Settings All computers are located in the enabled same IP network IP address 192.168.178.1 Subnet mask 255.255.255.0 DHCP server enabled If the factory settings were not changed, this setting has the following effect: FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 134 192.168.178.20 - 200 LAN 2 192.168.178.20 - 200 LAN 3 192.168.178.20 - 200 LAN 4 192.168.178.20 - 200 WLAN 192.168.182.20 - 200 Computers connected with the FRITZ!Box via different inter- faces are located in different subnets. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 135 “Apply”. Open the “System / Network Settings” menu. Click the “IP Addresses” button. The “IP Settings” page is opened. Here you can change the setting “All computers are located in the same IP network”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 136: More About Internet Telephony

    FRITZ!Box, you can make calls in all direc- tions: from the fixed-line network into the fixed-line network from the Internet into the fixed-line network from the Internet into the Internet and receive calls from all directions as well. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 137: Bandwidth Management

    Because the FRITZ!Box also places a higher priority on Inter- net telephony connections over Internet data connections, unwelcome interference is largely avoided. Just as for any other analog call, once Internet telephony transmission ca- pacity has been reached, remote partners receive a busy signal. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 138: Customer Service Guide

    Customer Service Guide Customer Service Guide Help on All Important Service Topics AVM is there to help should any questions or problems arise. Here you will find the important information you need, in the form of manuals, up- dates and support.

  • Page 139: Information In The Internet

    The latest software is also available for download at the fol- lowing address: www.avm.de/en/download Experienced users can also download updates from the AVM FTP server. Click the “FTP Server” link in the download area, or enter the following address: ftp.avm.de FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 140: Support From The Avm Service Team

    Click the “Mail Form” link to open the e-mail support form. Fill out the form and send it to AVM by clicking the “Send” button. Our Support team will respond by e-mail as quickly as pos- sible.
  • Page 141 Support by Fax Support by Fax If necessary, you can reach AVM Support at the fax number: +49 (0)30 / 39 97 62 66 The following information should be included in your fax to the Support team: Your name and address.

  • Page 142: Glossary

    24 Mbit/s. ADSL2+ is completely downward compatible, meaning that terminal equipment compliant with ADSL and ADSL2 can al- so be operated on ADSL2+ lines, although the devices can- not exploit the advantages of ADSL2+. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 143 IP addresses of the DNS serv- er to be used and of the default gateway. In assigning the IP addresses the DHCP server selects from a prescribed pool of IP addresses. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 144 IP addresses. This means that even pri- vate users have an economical way of placing their own In- ternet offers on their computer at home. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 145 Some firewalls also integrate additional concepts like IP masquerading and NAT to decouple data traffic by distin- guishing strictly between the internal and external network. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 146 If a computer wants to transfer data packets to a computer in another network, it must first transmit the packet to the gateway. To do this, the computer must know the address of the gateway. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 147 000 and 255. Every IP address contains two components: the network ad- dress and the host address. These two components can be read out of an IP address only if the subnet mask is also specified. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 148 Internet. Masquerading works by converting the IP address- es used in a network to one public IP address. From the out- side it appears that all requests are sent from a single com- puter. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 149 If a computer from the local network offers server services, for instance, the configuration of a router using NAT or IP masquerading must forward the port used by the server FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 150 A local IP network can consist of one subnetwork or be di- vided into multiple subnetworks. The division into subnet- works is performed when the local IP network is configured. The subnetworks of a local IP network are also IP networks. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 151 Subnet mask: 255.255.0.0 The assignment of the first two groups of numerals in the subnet mask indicates that the first two groups of numerals in the IP ad- dress define the network. The following addresses result: FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 152 For this an Auto Configuration Client (ACC) must be in- tegrated in the device. The specifications for automatic configuration of the ADSL terminal device are stored on the Auto Configuration Server by the given Internet Service FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 153 Through traffic shaping these delays are avoided by provid- ing the dispatch of confirmation packets with bandwidth suitable for the given download activities. All of the packets to be sent are also assigned a priority suitable for their packet types. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 154 Internet telephony used to be possible only with a headset connected to the computers of the callers and their conver- sation partners. Today voice connections via the Internet, even to fixed-line and mobile networks, can be conducted conveniently using VoIP telephone systems that allow FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 155 Internet in private or public institutions. Many airports, hotels and cafes, for instance, make WLAN hotspots availa- ble to their customers, either free or subject to a charge. Ul- timately this has maneuvered WLAN into serious competi- tion with mobile UMTS technology. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 156 Bluetooth is the more useful solution, however, as Bluetooth uses consider- ably less power than wireless LAN. What is more, Bluetooth technology is more flexible and thus offers a greater band- width of potential applications. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 157: Index
