Wyrestorm EX-100-USB3 Quick Start Manual

100m usb 3.2 hdbaset extender with poh+

Download this manual

100m USB 3.2 HDBaseT

Extender with PoH+

EX-100-USB3

WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the

installation process.

IMPORTANT! Installation Requirements

• Read through the

Wiring and Connections

guidelines before creating or choosing premade cables.

• Visit the product pages to download the latest firmware, document version,

additional documentation, and configuration tools.

Basic Wiring Diagram

EX-100-USB3 Quickstart Guide | 240617

section for important wiring

wyrestorm.com

In the Box

1x EX-100-USB3

1x DC 20V 3A Power Supply (US/EU/UK/AU)

1x 1.8m USB 3.0 Type-A to Type-B Cable (5Gb)

4x Mounting Bracket

1x Quickstart Guide (this document)
