SPECIFICATIONS
Model number
MSS-150
MSS-330
Platter / Tray
Net/gross weight
Package
Operating
Temperature
Indicator
Power source
Capacity
Division
150lb
0.05lb
330lb
0.1lb
12.3X12.8inch/315×325mm
2.1 kg / 3.1kg 4.6lb/ 6.8lb
Standard carton: 515x415x120 (mm
5 Units in one box: 640×430×530 (mm
Optimum: 15-30℃ (62-90f)
4×AA Batteries or AC/DC
Adapter 6V /100mA
INSTRUCTION MANUAL
3
)
3
)
MSS
MSS M-0612
Advertisement
Related Manuals for Tree MSS-150
Summary of Contents for Tree MSS-150
-
Page 1: Specifications
SPECIFICATIONS Model number Capacity Division MSS-150 150lb 0.05lb INSTRUCTION MANUAL MSS-330 330lb 0.1lb Platter / Tray 12.3X12.8inch/315×325mm Net/gross weight 2.1 kg / 3.1kg 4.6lb/ 6.8lb Standard carton: 515x415x120 (mm Package 5 Units in one box: 640×430×530 (mm Operating Optimum: 15-30℃ (62-90f) - Page 2 HOLD FUNCTION ： PARTS DESCRIPTIONS 1) Place the item on the Scale platform. ·TOP 2) Wait for the stable weight to be displayed. 3) Press the HOLD key. The " " hold indicator will turn on. 4) Remove the item from the Scale platform. He item's weight reading will remain on the display.
- Page 3 ： Features When to calibrate Display options：5 digital LCD Power：AC adapter 6V 100mA or 4xAA Size Batteries Note: Calibration is done in factory. Don't re-calibrate the Scale, unless it is not accurate. Auto back light (selectable) Auto Shut-off (selectable) Calibration: Auto Hold (Selectable) 1.
