Tree MED-CAN M-1-1211 Quick Start Manual

Med-Can Scale
(MED-CAN M-1-1211)
WEIGHING
Before weighing
Whenever possible, please allow the scale to warm up for 30 seconds after
first turning the power on so that the scale will work properly and accurately.
Requires 2xAAA baterries. (See fig 1.)
Error messages
Err-O: Overload
: Low battery
Turn On / Off the scale:
Rotate the top cover anti-clockwise till cover the LCD to turn the scale off;
Rotate the top cover clockwise till LCD showed to turn the scale on, and
"ON0" will shown on the display
Weighing procedures
There are three modes to be choosen when turning on the scale.
＊ON0
: Normal weighing mode (Objects to be
weighed only on the platform) (See fig 2.)
1. Turn on the scale, "ON0" will be shown in display area.
Press [ ] key and all display segments appear on LCD
and finally "0" will appear on the display.
2. Press [ ] key to select weighing units. eg: "g"、"ct"、
"oz"、 "dwt". Put an object onto the platform, the weight will be shown on the
display.
3. Press [ ] in short time to set the display to "0". Rotate the top cover
anti-clockwise to turn the scale off.
(fig 1.)
(fig 2.)
-1-
＊ON1
: Prestore weight of empty container
1. When the display shows "ON0" after turning on the scale, press [
to choose "ON1",Then,press [
enters prestorage weight of empty container mode .
2. Bottom up the scale on a flat place, and then a sound "beep"will be heard .
At the same time ,backlight lightens. (See fig 3.)
3. Put the scale straight on a stable and flat place again.
LCD display will show the weight of empty
container .
4. Press [ ] key to store weight value of empty
container and the display will show "SAVE", then
the scale is off .
＊ON2
: Calculate weight of object in the container.
(Precondition:Weight value of empty container need
Be prestored first through above step ON1)
1. When "ON0" is showed in display area after turning on the scale, press
[ ] key to choose "ON2". Press [
Now it enters weighing mode of object in the container .
2. Put the objects into container, press [
necessary.
3． Bottom up the scale on a stable and flat place, and then a sound "beep"will
be heard .
4．Put the scale straight on a flat place .The weight of object in the container
will be read in LCD display with backlight.
5．Press [ ] key to select units .
6．Press [ ] key to zero the scale, and LCD display will show '0.0'. Repeat
above mentioned ON2 steps for next round weighing.
] key, finally it will show "0.0". Now, it
(fig 3.)
] key, finally the display shows '0.0'.
] key to zero the scale if
] key
