Aaeon MB-662 Quick Installation Manual

Lpx board socket 370 pentium iii with lcd, lan, audio, 4 coms & ssd
Hide thumbs Also See for MB-662:

Advertisement

Quick Links

Download this manual See also: User Manual

Quick Installation Guide

MB-662
LPX Board Socket 370 Pentium III
with LCD, LAN, Audio, 4 COMs & SSD
N o t i c e :
The guide is designed for experienced users to
setup the system within the shortest time. For
detailed information, please always refer to the
electronic user's manual.
Safety
Precautions
Warning! Always completely disconnect the power cord
from your chassis whenever you work with the
hardware. Do not make connections while the
power is on. Sensitive electronic components can
be damaged by sudden power surges. Only
experienced electronics personnel should open
the PC chassis.
Caution!
Always ground yourself to remove any static
charge before touching the CPU card. Modern
electronic devices are very sensitive to static
electric charges. As a safety precaution, use a
grounding wrist strap at all times. Place all
electronic components in a static-dissipative
surface or static-shielded bag when they are not
in the chassis.
Part no. 2007662001 2nd. Ed. Printed in Taiwan Feb., 2001
MB-662
Installation Guide
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB-662 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aaeon MB-662

Summary of Contents for Aaeon MB-662

  • Page 1: Quick Installation Guide

    Quick Installation Guide MB-662 LPX Board Socket 370 Pentium III with LCD, LAN, Audio, 4 COMs & SSD N o t i c e : The guide is designed for experienced users to setup the system within the shortest time. For detailed information, please always refer to the electronic user's manual.
  • Page 2 MB-662 Location of Jumpers & Connectors CN31 JP18 CN25 JP13 CN16 CN17 CN12 CN29 CN24 JP16 BC-599/596 MB-662 Installation Guide...

  • Page 3: List Of Jumpers

    COM4 RS-232/422/485 Selection JP12 Speaker (external) / Buzzer JP13 System Status LED Pin Header JP14 Power Reset Connector JP15 DiskOnChip (DOC) Address Selection JP16 IR Touchscreen Power Pin Header JP17 100/66 Mhz Frequency Select JP18 Keyboard Lock MB-662 Installation Guide...

  • Page 4: List Of Connectors

    Digital I/O Connector CN30 COM3 Connector CN31 COM4 Connector CN32 COM1 Connector CN33 Joystick / MIDI Port CN34 Audio Connector for CD_IN CN35 Phone Jack for Line_OUT CN36 Phone Jack for MIC CN37 Phone Jack for Line_IN BC-599/596 MB-662 Installation Guide...
  • Page 5 (follow clear CMOS illustration) then, immediately return jumper to protect mode. * Protect Clear CMOS Default LCD Panel Voltage Setting (JP6) The LCD panel driving voltage is set by using JP6 jumper settings illustrated as follows: * 3.3V * Default MB-662 Installation Guide...
  • Page 6 * Default Ethernet Tx/Rx/Link LED Connector (JP8) With ethernet Tx/Rx/Link LED indicator, the ethernet status can be trace up through LED indicator readings. The pin definitions are listed as follows: Signal Signal Rx-LED Link LED Tx-LED BC-599/596 MB-662 Installation Guide...
  • Page 7 10 12 * Default Speaker/Buzzer (JP12) This onboard jumper provides users easy manual settings for on board buzzer and external speaker. By just following the illustration of the settings below: * on board buzzer external speaker * Default MB-662 Installation Guide...
  • Page 8 Just follow the pin definition for each 7 LEDs illustrated below: Signal Signal Power_ON LED CPU_fan LED System_fan LED HDD_access LED Low_temperature LED High_temperature LED LAN_access LED BC-599/596 MB-662 Installation Guide...
  • Page 9 16MB up to 288MB, unformatted. In order to manage the disk, the DiskOnChip 2000 includes the TrueFFS, M-Systems Flash File System proprietary software. The DiskOnChip 2000 package is pin-to-pin compatible with a standard 32-pin EPROM device. D400 D800 DC00 * Disable * Default MB-662 Installation Guide...
  • Page 10 Provide the users to manually select the operating frequency with the use of jumper JP17. Illustrated setting as follows: * 66 Mhz Frequency 100 Mhz Frequency * Default Keyboard Lock (JP18) Keyboard Lock (CN18) Signal Signal KBLOCK BC-599/596 MB-662 Installation Guide...
  • Page 11 5VSB +12V Display Connectors (CN3) and (CN12) The MB-662's PCI SVGA interface can drive conventional CRT displays and is capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD, and active LCD displays. The board has two connectors to support these displays, one for standard CRT VGA monitors and one for flat panel displays.
  • Page 12 A standard conventional D-sub connector is equipped to interface with conventional CRT displays. Refer to pin definitions as follows: Signal GREEN BLUE Chassis GND Chassis GND Chassis GND Chassis GND Chassis GND DDDA H-SYNC V-SYNC DDCK BC-599/596 MB-662 Installation Guide...
  • Page 13 LCD display connector (CN12) CN12 is a 50-pin, dual-in-line header used for flat panel displays. When the MB-662's power is applied, the control signal is low until just after the relevant flat panel signals are present. Configuration of the VGA interface is done completely via the software utility.
  • Page 14 MB-662 USB Connector (CN6) MB-662 is equipped with a dual port USB onboard connector. It acquires the new generation of plug and play ( Hot Plugging ) feature, for both low speed and high speed devices. It could also be expanded up to 127 connections through USB hub. Refer pin...

  • Page 15: Connecting The Floppy Drive

    1 should be on the right. Check the documentation that came with the drive for more information. If you desire, connect the B: drive to the connectors in the middle of the cable as described above. Please refer to the pin definitions on the next page. MB-662 Installation Guide...
  • Page 16 1.) Plug infrared module into IrDA connector. Caution must be taken with the connector's orientation before plugging into IrDA connector. 2.) Enable infrared function in the BIOS system setup. IrDA connector pin definitions: Signal Signal FIrRx IrTx IrRx CIrRx BC-599/596 MB-662 Installation Guide...
  • Page 17 LPT1 is disabled, LPT2 or LPT3 is enabled. And if LPT2 is disabled, LPT1or LPT3 is enabled. The pin definitions for both CN10 and CN21 are listed as follows: ( Please turn to next page). MB-662 Installation Guide...
  • Page 18 MB-662 Parallel Port 1 Connector (CN10), 25-pin D-sub Signal Signal /STB /ACK BUST /SLCT /AUTOFD /INIT /SLCTINI Parallel Port 2 Connector (CN21), 13x2 pin header Signal Signal /STB /AUTOFD /INIT /SLCTINI /ACK BUST SLCT BC-599/596 MB-662 Installation Guide...
  • Page 19 Quick Installation Guide Keyboard and Mouse Connector (CN11) The MB-662 provides a keyboard connector which supports both a keyboard and a PS/2 style mouse. Please refer to the pin definitions listed below: Keyboard and Mouse Connector (CN11), Dual mini-din connector...
  • Page 20 +12V fan speed sensor RJ-45 Ethernet Connector (CN14) MB-662 is outfitted with a standard RJ-45 LAN connector. With support from Realtek RTL8139C chipset using either 10Mbs or 100Mbs are possible through it's N-way auto-negotiation featured operation. Refer to the pin definitions listed below:...

  • Page 21: Connecting The Hard Drive

    (see your hard drive's documentation for the location of the connector). Connect a second drive as described above. Unlike floppy drives, IDE hard drives can be connected to either end of the cable. The pin definitions for this section are listed on the next page. MB-662 Installation Guide...
  • Page 22 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND IO WRITE IO READ IO CHANNEL READY IRQ14 IOCS16 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0 HARD DISK SELECT 1 IDE ACTIVE MGND MVcc BC-599/596 MB-662 Installation Guide...
  • Page 23 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 SIGNAL GND IO WRITE IO READ IO CHANNEL READY IRQ14 IOCS16 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0 HARD DISK SELECT 1 IDE ACTIVE MGND MB-662 Installation Guide...
  • Page 24 NRI1 LCD Inverter Backlight Power Connector (CN25) CN25 enables power transmission when connected from the main- board to the LCD panel for backlight lighting. Refer to the pin de- finitions below: Signal +5V ENB +12V ENB BC-599/596 MB-662 Installation Guide...
  • Page 25 Quick Installation Guide Digital I/O Connector (CN29) MB-662 offers digital I/O functions connector for easy access and link with digital devices. (Input 4031: GPI15 [bit7]; Input 4032: GPI17 [bit1], GPI18 [bit2], GPI19 [bit3]; Output 4036: GPO17 [bit1], GPO 18 [bit2], GPO19 [bit3], GPO20 [bit4] ) The pin definitions are...
  • Page 26 MB-662 COM1 (CN32) COM1 RS-232 (CN32) Signal Signal DCDA DSRA RXDA RTSA TXDA CTSA DTRA DTRA COM4 (CN31) COM4 RS-232/422/485 (CN31) Signal Signal DCDB DSRB RXDB RTSB TXDB CTSB DTRB IRIB 485TXD+ 485TXD- 422RXD- 422RXD- BC-599/596 MB-662 Installation Guide...
  • Page 27 Quick Installation Guide Joystick / MIDI Port (CN33) MB-662 is equipped with a 4 in 1 connector and provides joystick / MIDI port. All designed for easy access to the users. Refer to the pin definitions below: Joystick / MIDI Port Connector (CN33)
  • Page 28 Signal Line_OUT Left Line_OUT Right Phone Jack for MIC (CN36) A standard phone jack is also provided for the users ease and con- venience. The pin definitions are listed below: MIC Phone Jack (CN36) Signal MIC_IN BC-599/596 MB-662 Installation Guide...
  • Page 29 Quick Installation Guide Phone Jack for Line_IN (CN37) The MB-662 is designed with line_OUT and for additional ease a line_IN connection is definitely needed. It also comes with stan- dard easy connection. Pin definitions below: Line_IN Phone Jack (CN37) Signal...
  • Page 30 MB-662 BC-599/596 MB-662 Installation Guide...
