SETTING THE TIMER

The timer can be used to delay appliance start up or shutdown.
This avoids wasting electricity by not operating the appliance
when it is not needed.
How to program delayed start up
Plug the appliance into the mains and turn the unit to
standby.
Touch the timer button (C3): the timer symbol (C13) and
the number of hours come on.
Use the + (C4) or - (C5) buttons to set the number of hours
delay before the appliance comes on.
The appliance works using the mode previously set.
The appliance can be set to come on within the next 24 hours.
A few second after set, the setting is memorised, the timer sym-
bol is lit and the display shows that the appliance is in standby.
To delet the setting, touch two times the timer button (C3). The
timer symbol (C13) switches off.
How to program delayed shutdown
With the air conditionin on, in every mode, it is possible to
set the delayed shutdown.
Touch the Timer (C3) button: the timer symbol (C13) and
the hours switch on.
Use the + (C4) or - (C5) buttons to set the number of hours
delay before the appliance turns off.
A few second after set, the setting is memorised, the timer sym-
bol is lit and the display shows the current mode.
At the end of the set time the appliance automatically turns in
standby mode.
To delet the setting, touch two times the timer button (C3). The
timer symbol (C13) switches off.

USING THE REMOTE CONTROL

Point the remote control at the receiver (A11) on the air
conditioner. The remote control must be no more than 16
ft (5 metres) away from the appliance (without obstacles
between the remote control and the receiver).
The remote control must be handled with extreme care. Do
not drop it or expose it to direct sunlight or sources of heat.
NOTE: The remote control can be safely stored in the appropiate
compartment A12 (see figure).
MAX 16 ft
MAX 5 metres
DESCRIPTION OF THE REMOTE CONTROL (D)
D1) ON/STAND-BY button
D2) Increase/decrease temperature/programmed operation
D3) " MODE" selection button
D4) Fan speed selection button (
D5) REAL FEEL selection button
D6) WHISPER COOL selection button
D7) Switch button °C/°F
D8) TIMER button
D1
D3
D4
INSERTING OR REPLACING THE BATTERIES
Remove the cover on the rear of the remote control;
Replace the old batteries with two new R03 " AAA" 1.5V bat-
teries, inserting them correctly (see the instructions inside
the battery compartment);
Replace the cover.
If the remote control unit is replaced or discarded, the batteries
must be removed and disposed of in accordance with current
legislation as they are harmful to the environment. Do not mix
old and new batteries.
Do not mix alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium) batteries. Do not dispose of batteries in fire.
Batteries may explode or leak. If the remote control is not be
used for a certain length of time, remove the batteries.
Note:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residen-
tial installation.
This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turn-
10
)
D2
D8
D7
D5
D6
