Specifications - Hitachi 57F59A Service Manual

Models: 51F59/A/J
Cathode-Ray Tube:
51F59A/J,57F59A/J,65F59A/J
R=P16LXL00RFA
G=P16LXL00HHA
B=P16LXL00BMB
Power Consumption:
• Power Consumption (operating)
51/57/65F59/A/J . . . . . . . . . . . . . . . . . . . . . .187W
• Power Consumption (maximum)
51/57/65F59/A/J . . . . . . . . . . . . . . . . . . . . . .235W
Antenna Impedance:
Receiving Channel:
Available signal:
Cable ANALOG (NTSC : STD/IRC/HRC)
Air ANALOG (NTSC)
DIGITAL (ATSC:8VSB)
CAUTION: Below is an EXAMPLE only. See Replacement Parts List for details. The following symbol near the fuse
indicates fast operation fuse (to be replaced). Fuse ratings appear within the symbol.
Example:
10 A 125V
"RISK OF FIRE - REPLACE FUSE AS MARKED"
TABLE OF CONTENTS

SPECIFICATIONS

57F59/A/J 65F59/A/J
51F59,57F59,65F59
R=P16MAB00RFA
G=P16MAB00HHA
B=P16MAB00BMB
75 Ohm Unbalanced
VHF / UHF / CATV
BAND CH
VHF 2~13
UHF 14~69
EXT. Mid (A-5)~(A-1), 4+
CATV Mid. A~I
CATV Super J~W
CATV Hyper (W+1)~(W+28)
CATV Ultra (W+29)~(W+94)
CIRCUIT PROTECTION
F
Intermediate Frequency:
Video Input:
Video Output:
Audio Input:
Stereo Audio Output:
Audio Output Power:
Front: 24 watts per channel at 10% distortion,
8 ohm Impedance. Max output 25 watts.
Anode Voltage:
DP65 31.7±0.2kv (1.59±0.2mA)
Brightness: 51"
(W/ ultra shield) 250cd/m2
(W/o ultra shield) 310cd/m2
Speakers: 51"
2 Woofers - 5 inch (12 cm) round
57"
2 Woofers - 6 inch (16 cm) round
65"
2 Woofers - 6 inch (16 cm) round
DIMENSIONS:
51F710A
Height (in.) 50-3/8
(mm) 1,279.0
Width (in.) 48-3/4
(mm) 1,239.0
Depth (in.) 21-7/8
(mm) 557
Weight (lbs.) 187.4
(kg.) 85
Circuit Board Assemblies:
CPT (B) P.W.B.
CPT (G) P.W.B
CPT (B) P.W.B.
Power/Deflection P.W.B.
Signal P.W.B.
Sensor P.W.B.
DCU P.W.B.
The rating of fuse F901 is 10A - 125V.
Replace with the same type fuse for continued protection
against fire.
13 13
DP65
Picture l-F Carrier 45.75 MHz
Sound l-F Carrier 41.25 MHz
Color Sub Carrier 42.17 MHz
1 Volt p-p, 75 Ohm
1 Volt p-p, 75 ohm
470 mVrms, 47 k Ohm
470 mVrms, 1 k Ohm
57" 65"
195cd/m2 150cd/m2
240cd/m2 185cd/m2
57F710A 65F710A
54-9/16 59-15/16
1,385.6 1,521.0
54 61
1,372.0 1,549.0
23-5/8 27-7/8
599.4 708
205 309
93 140
Digital P.W.B.
125V
10A
