Hitachi 57F59A Service Manual page 157

PRODUCT SERVICE NOTE: Components marked with a
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety of the
receiver through improper servicing.
SYMBOL PART # DESCRIPTION
C340 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK
C341 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C342 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C343 AA01113R CCC225K06-B-16CT
C344 AA01113R CCC225K06-B-16CT
C345 AA01123R CCC105K10-B-16CT
C346 AA01123R CCC105K10-B-16CT
C347 AA01123R CCC105K10-B-16CT
C348 0800352R CAP.-ELECTRO.470UF 10V
C350 AA00937R CAP.CHIP-CERAMIC 10UF 10V 2012BK
C352 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C353 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C354 0800352R CAP.-ELECTRO.470UF 10V
C355 AA01802R CCC103K50-B-16CT MCH18
C356 0800352R CAP.-ELECTRO.470UF 10V
C357 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C358 AA00969R CAP.CHIP2125-B-22UF6.3V
C361 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C364 AA01115R CAP.CHIP1608-B-4.7UF6.3V
C365 AA01113R CCC225K06-B-16CT
C366 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C367 AA01123R CCC105K10-B-16CT
C368 AA01123R CCC105K10-B-16CT
C369 AA01802R CCC103K50-B-16CT MCH18
C370 AA01802R CCC103K50-B-16CT MCH18
C372 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C373 AA01802R CCC103K50-B-16CT MCH18
C374 AA01802R CCC103K50-B-16CT MCH18
C375 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
C376 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
C377 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
C378 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C379 0800326R CAP.-ELECTRO. 100UF-M 16V
C380 AA01115R CAP.CHIP1608-B-4.7UF6.3V
C381 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
C382 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C383 AA01802R CCC103K50-B-16CT MCH18
C384 0893179R CAP.CHIP-CERAMIC 100000PF 16V TAPE
C390 0893222R CAP 1608CHIP10000PFKB 50V TAPE
C501 AA01123R CCC105K10-B-16CT
C502 AA01123R CCC105K10-B-16CT
C503 AA01123R CCC105K10-B-16CT
C504 AA01123R CCC105K10-B-16CT
C505 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C506 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C509 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C510 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C511 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C512 AA01123R CCC105K10-B-16CT
C513 AA01123R CCC105K10-B-16CT
C514 AA01802R CCC103K50-B-16CT MCH18
C515 AA01802R CCC103K50-B-16CT MCH18
C516 AA01115R CAP.CHIP1608-B-4.7UF6.3V
C517 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V)
C518 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V)
C519 AA01136R CERAMIC CAPACITOR(0.47UF 6.3V)
C520 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C521 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C522 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C523 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C524 AA01123R CCC105K10-B-16CT
C525 AA01123R CCC105K10-B-16CT
C526 AA01123R CCC105K10-B-16CT
C527 AA01123R CCC105K10-B-16CT
C528 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
C529 0800326R CAP.-ELECTRO. 100UF-M 16V
C530 0893188R CERAMIC CAPACITOR(47000PF 16V)
C531 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C532 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C533 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C534 AA01802R CCC103K50-B-16CT MCH18
C535 0800352R CAP.-ELECTRO.470UF 10V
C536 0800352R CAP.-ELECTRO.470UF 10V
C537 0893188R CERAMIC CAPACITOR(47000PF 16V)
C538 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
!
have special characteristics important to safety. Before replacing any
SYMBOL PART # DESCRIPTION
C539 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C540 AA01123R CCC105K10-B-16CT
C541 AA01123R CCC105K10-B-16CT
C542 0893188R CERAMIC CAPACITOR(47000PF 16V)
C543 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C544 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C545 AA01123R CCC105K10-B-16CT
C546 AA01123R CCC105K10-B-16CT
C547 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C548 AA01123R CCC105K10-B-16CT
C549 AA01123R CCC105K10-B-16CT
C550 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C551 AA01123R CCC105K10-B-16CT
C552 AA01123R CCC105K10-B-16CT
C553 AA01123R CCC105K10-B-16CT
C554 AA01123R CCC105K10-B-16CT
C555 AA01802R CCC103K50-B-16CT MCH18
C556 0800326R CAP.-ELECTRO. 100UF-M 16V
C557 AA01802R CCC103K50-B-16CT MCH18
C558 0800326R CAP.-ELECTRO. 100UF-M 16V
C559 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C560 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C561 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C562 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C563 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C564 AA01121R CERAMIC CAPACITOR(0.47UF 10V)
C566 AA01123R CCC105K10-B-16CT
C567 AA01123R CCC105K10-B-16CT
C568 AA01123R CCC105K10-B-16CT
C569 AA01123R CCC105K10-B-16CT
C570 AA01802R CCC103K50-B-16CT MCH18
C571 0800326R CAP.-ELECTRO. 100UF-M 16V
C572 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C573 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C574 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C575 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C576 AA00968R CCC106M06-B-20CT (10UF 6.3V 2012M)
C580 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C582 AA01802R CCC103K50-B-16CT MCH18
C583 AA01802R CCC103K50-B-16CT MCH18
C584 0800326R CAP.-ELECTRO. 100UF-M 16V
C585 0800326R CAP.-ELECTRO. 100UF-M 16V
CA01 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CA02 AA00982R CERAMIC CAPACITOR(0.33UF 25V-B
CA03 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA04 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA05 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CA06 AA00991R CERAMIC CAPACITOR(0.1UF 50V-B)
CA07 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA08 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA09 0893213R CAP1608CHIP 2200PFKB 50V TAPE
CA10 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA11 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA12 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA13 0893213R CAP1608CHIP 2200PFKB 50V TAPE
CA14 AA01141R CERAMIC CAPACITOR(0.1UF 16V)
CA15 AA01144R CERAMIC CAP. 1608-B 1.0UF 16V
CA24 AA01802R CCC103K50-B-16CT MCH18
CA25 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA26 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA27 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA28 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA29 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA30 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
CA31 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
CA32 0893208R CAP 1608CHIP 1000PFKB 50V TAPE
CA33 0800318R CAP.-ELECTRO. 47UF-M 25V
CA34 0800318R CAP.-ELECTRO. 47UF-M 25V
CA35 0800328R CAP. ELECTRO. 100UF-M 35V
CA36 0880194R CAP.-POLYESTER 0.1UF-J 50V
CA37 0880194R CAP.-POLYESTER 0.1UF-J 50V
CA38 0880194R CAP.-POLYESTER 0.1UF-J 50V
CA39 AL01153S CAP.ELECTR. 1000UF-M 35V
CA41 0284824F CAP.-ELECTRO. 2200UF 35V
CA42 0284824F CAP.-ELECTRO. 2200UF 35V
156
DP65
