Hitachi 57F59A Service Manual page 173

PRODUCT SERVICE NOTE: Components marked with a
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety of the
receiver through improper servicing.
SYMBOL PART # DESCRIPTION
D945 CH02731 DIO-FMUP-1056E
D946 2348282M DIODE MTZ-J30B TAPE
D947 2344041M DIODE 1SS254TA/1SS270TA
D948 2348143M DIODE MTZ-J7.5CTA
D949 CH02011M DIODE 1SR153-400
D950 CH02673R LED SM3517F6T (GREEN )
D951 2344041M DIODE 1SS254TA/1SS270TA
D952 2344041M DIODE 1SS254TA/1SS270TA
D954 2337951S DIODE RU4Z(LF015-302)
D959 2344041M DIODE 1SS254TA/1SS270TA
D960 2337951S DIODE RU4Z(LF015-302)
D962 2348082M DIODE MTZ-J 4.3BTA
D963 2359314G DIODE RU-3C P12.5
D964 2348143M DIODE MTZ-J7.5CTA
DF01 2344041M DIODE 1SS254TA/1SS270TA
DH01 2348093M DIODE MTZ-J4.7C TAPE
DH02 2344041M DIODE 1SS254TA/1SS270TA
DH03 2344041M DIODE 1SS254TA/1SS270TA
DH04 2348091M DIODE MTZ-J4.7A TAPE
DH05 2348193M ZENER DIODE MTZJ-12C TA
DH06 2344041M DIODE 1SS254TA/1SS270TA
DH07 2359312S DIODE RU3C LF-C4 (1000V 1.5A )
DH08 2334243M ZENER RD16E (B2 T2/TP/TA)
DH09 CH00041M DIODE ES1FV1 (1500V)
DH10 2334324M ZENER DIODE RD36E TAPE (B3)
DH11 2359312S DIODE RU3C LF-C4 (1000V 1.5A )
DH12 2344041M DIODE 1SS254TA/1SS270TA
DH13 CH00031M DIODE AU02V1(280V)
DH14 2348282M DIODE MTZ-J30B TAPE
DH15 2335042M ZENER HZ-22 (2L TP)
DH16 2334305M ZENER RD30E (B4 T2/TP/TA)
DH17 2344041M DIODE 1SS254TA/1SS270TA
DH18 2344041M DIODE 1SS254TA/1SS270TA
DH19 2344041M DIODE 1SS254TA/1SS270TA
FUSES, PROTECTORS
E940 AZ00919M PROTECTOR 0491007.NRT1-[JA]
E941 AZ00919M PROTECTOR 0491007.NRT1-[JA]
E943 AZ00921M PROTECTOR 0491010.NRT1-[JA]
E944 AZ00921M PROTECTOR 0491010.NRT1-[JA]
E945 AZ00917M PROTECTOR 0491004.NRT1-[JA]
E946 AZ00911M PROTECTOR 0491.500NRT1-[JA]
E947 AZ00916M PROTECTOR 0491003.NRT1-[JA]
F901 FN00476 FUSE 51MS 080 L-U 125V 8A
F902 FN00464 FUSE 51MS 010 L-U 125V 1A
F903 FN00473 FUSE 51MS 050 L-U 125V 5A
FE91 2721351 FUSE HOLDER
FE92 2721351 FUSE HOLDER
FE93 2721351 FUSE HOLDER
GF01 CJ00072R SPARK GAP 2.5KV
GF02 CJ00072R SPARK GAP 2.5KV
INTEGRATED CIRCUITS (IC's)
I601 CP06891 IC TDA8174A
I701 2362606 IC NJM4558D
I702 CP04234 IC BA09T
I901 CP08515F ANALOG MONOLITHIC IC STR-A6159
I902 CP08533 STR-6737M(LF1901)
I903 CP07851 MONO IC TLP421
I904 CP07851 MONO IC TLP421
I905 CP07851 MONO IC TLP421
I906 CP07851 MONO IC TLP421
I907 CP08301 IC STA821M
I908 CP08291 IC STA811M
I941 2381343 IC (SE115N)
IH01 CP07091 IC M62501P
JUMPER WIRES
K001 2784381M 0.60MM TAPED JUMP.WIRE
K002 2784381M 0.60MM TAPED JUMP.WIRE
K003 2784381M 0.60MM TAPED JUMP.WIRE
K004 2784381M 0.60MM TAPED JUMP.WIRE
K005 2784381M 0.60MM TAPED JUMP.WIRE
K006 2784381M 0.60MM TAPED JUMP.WIRE
K007 2784381M 0.60MM TAPED JUMP.WIRE
!
have special characteristics important to safety. Before replacing any
SYMBOL
0 0 K008
0 0 K009
0 0 K010
0 0 K011
0 0 K012
0 0 K013
0 0 K014
0 0 K015
0 0 K016
0 0 K017
0 0 K018
0 0 K019
0 0 K020
0 0 K021
0 0 K022
0 0 K023
0 0 K024
0 0 K026
0 0 K027
0 0 K028
0 0 K029
0 0 K030
SI 10MA 16.51V 0 0 K031
0 0 K032
SI 500MW 36V 0 0 K033
0 0 K034
0 0 K035
0 0 K036
0 0 K037
SI 200MA 400MW 0 0 K038
SI 5MA 30.51V 0 0 K039
0 0 K040
0 0 K041
0 0 K042
K043
K044
0 0 K045
0 0 K046
0 0 K047
0 0 K048
0 0 K049
0 0 K050
0 0 K051
0 0 K052
0 0 K053
0 0 K054
0 0 K055
0 0 K056
0 0 K057
0 0 K058
0 0 K059
K060
K061
0 0 K062
0 0 K063
0 0 K064
0 0 K065
0 0 K066
0 0 K067
0 0 K068
0 0 K069
0 0 K070
0 0 K071
0 0 K072
0 0 K073
0 0 K074
K075
K076
0 0 K077
0 0 K078
0 0 K079
0 0 K080
0 0 K081
0 0 K082
0 0 K083
172
PART # DESCRIPTION
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
!
2784381M 0.60MM TAPED JUMP.WIRE
!
2784381M 0.60MM TAPED JUMP.WIRE
!
2784381M 0.60MM TAPED JUMP.WIRE
!
2784381M 0.60MM TAPED JUMP.WIRE
!
! 2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
!
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
2784381M 0.60MM TAPED JUMP.WIRE
