Hitachi 57F59A Service Manual page 161

PRODUCT SERVICE NOTE: Components marked with a
of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety of the
receiver through improper servicing.
SYMBOL PART # DESCRIPTION
R089 0790037R RES.CHIP 1/16W 1.0K OHM
R090 0790037R RES.CHIP 1/16W 1.0K OHM
R091 0790037R RES.CHIP 1/16W 1.0K OHM
R092 0790024R RES.CHIP 1/16W 100 OHM
R093 0790024R RES.CHIP 1/16W 100 OHM
R094 0790055R RES.CHIP 1/16W 22K OHM
R095 0790037R RES.CHIP 1/16W 1.0K OHM
R096 0790037R RES.CHIP 1/16W 1.0K OHM
R098 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R099 0790042R RES.CHIP 1/16W 2.2K OHM
R100 0790024R RES.CHIP 1/16W 100 OHM
R101 AQ00177R RES.CHIP 1/16W 240 OHM TAPE
R102 AQ00176R RES.CHIP 1/16W 220 OHM TAPE
R103 0790077R RES.CHIP 1/16W 1.0M OHM
R104 0790033R RES.CHIP 1/16W 470 OHM
R105 0790077R RES.CHIP 1/16W 1.0M OHM
R106 0790059R RES.CHIP 1/16W 47K OHM
R107 0790059R RES.CHIP 1/16W 47K OHM
R108 0790059R RES.CHIP 1/16W 47K OHM
R109 0790037R RES.CHIP 1/16W 1.0K OHM
R110 0790037R RES.CHIP 1/16W 1.0K OHM
R111 0790037R RES.CHIP 1/16W 1.0K OHM
R113 0790024R RES.CHIP 1/16W 100 OHM
R114 0790024R RES.CHIP 1/16W 100 OHM
R115 0790024R RES.CHIP 1/16W 100 OHM
R116 0790024R RES.CHIP 1/16W 100 OHM
R117 0790024R RES.CHIP 1/16W 100 OHM
R118 0790024R RES.CHIP 1/16W 100 OHM
R119 0790024R RES.CHIP 1/16W 100 OHM
R120 0790024R RES.CHIP 1/16W 100 OHM
R121 0790024R RES.CHIP 1/16W 100 OHM
R127 0790037R RES.CHIP 1/16W 1.0K OHM
R128 0790037R RES.CHIP 1/16W 1.0K OHM
R130 0790037R RES.CHIP 1/16W 1.0K OHM
R131 0790042R RES.CHIP 1/16W 2.2K OHM
R132 0790037R RES.CHIP 1/16W 1.0K OHM
R133 0790037R RES.CHIP 1/16W 1.0K OHM
R134 0790033R RES.CHIP 1/16W 470 OHM
R135 0790047R RES.CHIP 1/16W 5.6K OHM
R138 0790055R RES.CHIP 1/16W 22K OHM
R139 0790037R RES.CHIP 1/16W 1.0K OHM
R141 0790037R RES.CHIP 1/16W 1.0K OHM
R142 0790024R RES.CHIP 1/16W 100 OHM
R144 0790037R RES.CHIP 1/16W 1.0K OHM
R145 0790037R RES.CHIP 1/16W 1.0K OHM
R146 0790024R RES.CHIP 1/16W 100 OHM
R147 0790024R RES.CHIP 1/16W 100 OHM
R148 0790024R RES.CHIP 1/16W 100 OHM
R149 0790047R RES.CHIP 1/16W 5.6K OHM
R150 0790028R RES.CHIP 1/16W 220 OHM
R151 0790024R RES.CHIP 1/16W 100 OHM
R152 0790047R RES.CHIP 1/16W 5.6K OHM
R154 0790037R RES.CHIP 1/16W 1.0K OHM
R155 0790024R RES.CHIP 1/16W 100 OHM
R158 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R159 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R163 0790024R RES.CHIP 1/16W 100 OHM
R164 0790051R RES.CHIP 1/16W 10K OHM
R165 0790051R RES.CHIP 1/16W 10K OHM
R168 0790051R RES.CHIP 1/16W 10K OHM
R170 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R171 0790051R RES.CHIP 1/16W 10K OHM
R172 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R173 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R176 0790024R RES.CHIP 1/16W 100 OHM
R177 0790024R RES.CHIP 1/16W 100 OHM
R178 0790037R RES.CHIP 1/16W 1.0K OHM
R179 0790051R RES.CHIP 1/16W 10K OHM
R180 0790051R RES.CHIP 1/16W 10K OHM
R181 0790051R RES.CHIP 1/16W 10K OHM
R182 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R183 0790024R RES.CHIP 1/16W 100 OHM
R184 0790033R RES.CHIP 1/16W 470 OHM
R186 0790059R RES.CHIP 1/16W 47K OHM
R187 0790024R RES.CHIP 1/16W 100 OHM
!
have special characteristics important to safety. Before replacing any
SYMBOL PART # DESCRIPTION
R189 0790024R RES.CHIP 1/16W 100 OHM
R190 0790037R RES.CHIP 1/16W 1.0K OHM
R191 0790051R RES.CHIP 1/16W 10K OHM
R192 0790024R RES.CHIP 1/16W 100 OHM
R193 0790024R RES.CHIP 1/16W 100 OHM
R194 0790024R RES.CHIP 1/16W 100 OHM
R195 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R196 0790051R RES.CHIP 1/16W 10K OHM
R197 0790051R RES.CHIP 1/16W 10K OHM
R198 0790024R RES.CHIP 1/16W 100 OHM
R199 0790024R RES.CHIP 1/16W 100 OHM
R203 0790024R RES.CHIP 1/16W 100 OHM
R204 0790051R RES.CHIP 1/16W 10K OHM
R205 0790051R RES.CHIP 1/16W 10K OHM
R206 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R207 0790051R RES.CHIP 1/16W 10K OHM
R208 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R209 0790037R RES.CHIP 1/16W 1.0K OHM
R210 0790024R RES.CHIP 1/16W 100 OHM
R211 0790024R RES.CHIP 1/16W 100 OHM
R212 0790037R RES.CHIP 1/16W 1.0K OHM
R213 0790051R RES.CHIP 1/16W 10K OHM
R214 0790051R RES.CHIP 1/16W 10K OHM
R215 0790024R RES.CHIP 1/16W 100 OHM
R216 0790051R RES.CHIP 1/16W 10K OHM
R217 AQ00344R RES.CHIP 1/16W 100 OHM TAPE
R218 0790051R RES.CHIP 1/16W 10K OHM
R219 0790037R RES.CHIP 1/16W 1.0K OHM
R220 0790024R RES.CHIP 1/16W 100 OHM
R221 0790037R RES.CHIP 1/16W 1.0K OHM
R222 0790051R RES.CHIP 1/16W 10K OHM
R223 0790037R RES.CHIP 1/16W 1.0K OHM
R224 0790059R RES.CHIP 1/16W 47K OHM
R226 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R227 0790037R RES.CHIP 1/16W 1.0K OHM
R230 0790055R RES.CHIP 1/16W 22K OHM
R234 0790051R RES.CHIP 1/16W 10K OHM
R239 0790037R RES.CHIP 1/16W 1.0K OHM
R244 0790051R RES.CHIP 1/16W 10K OHM
R245 0790059R RES.CHIP 1/16W 47K OHM
R304 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R305 0790037R RES.CHIP 1/16W 1.0K OHM
R306 0790037R RES.CHIP 1/16W 1.0K OHM
R308 0790059R RES.CHIP 1/16W 47K OHM
R311 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R312 0790037R RES.CHIP 1/16W 1.0K OHM
R313 0790051R RES.CHIP 1/16W 10K OHM
R314 0790051R RES.CHIP 1/16W 10K OHM
R315 0790037R RES.CHIP 1/16W 1.0K OHM
R316 0790042R RES.CHIP 1/16W 2.2K OHM
R324 0790051R RES.CHIP 1/16W 10K OHM
R326 0790024R RES.CHIP 1/16W 100 OHM
R330 0790024R RES.CHIP 1/16W 100 OHM
R331 0790024R RES.CHIP 1/16W 100 OHM
R335 0790024R RES.CHIP 1/16W 100 OHM
R336 0790024R RES.CHIP 1/16W 100 OHM
R337 0790024R RES.CHIP 1/16W 100 OHM
R338 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R339 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R340 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R341 0790064R RES.CHIP 1/16W 100K OHM
R342 0790064R RES.CHIP 1/16W 100K OHM
R344 0790001R CHIP RESISTOR RECJUMPER-1-16C16T1608
R345 0790061R RES.CHIP 1/16W 56K OHM
R346 0790024R RES.CHIP 1/16W 100 OHM
R347 0790024R RES.CHIP 1/16W 100 OHM
R348 0790064R RES.CHIP 1/16W 100K OHM
R349 0790039R RES.CHIP 1/16W 1.5K OHM
R350 0790039R RES.CHIP 1/16W 1.5K OHM
R351 0790024R RES.CHIP 1/16W 100 OHM
R352 0790063R RES.CHIP 1/16W 82K OHM
R353 0790024R RES.CHIP 1/16W 100 OHM
R354 0790054R RES.CHIP 1/16W 18K OHM
R355 AQ00234R RES.CHIP 1/16W 33K OHM TAPE
R356 AQ00261R RES.CHIP 1/16W 330K OHM TAPE
160
DP65
