GB
Installation Instructions
For Garage Door Opener
UK 60 / UK 80
UK 100
With automatic chain tensioner
Please read these
installation instructions
carefully!
We disclaim all liability
under the terms of the
warranty for any
damage caused by
improper installation!
Serial number:
Installation Instruction UK - Page 1
Advertisement
Related Manuals for Seip UK 60
Summary of Contents for Seip UK 60
-
Page 1: Installation Instructions
Installation Instructions For Garage Door Opener UK 60 / UK 80 UK 100 With automatic chain tensioner Please read these installation instructions carefully! We disclaim all liability under the terms of the warranty for any damage caused by improper installation! -
Page 2: Pre-Assembly
Preassembly You have unpacked your UK garage door opener and have it in front of you. 2. Take the part designated with a 2 in the drawing, and place it in front. Slide the C-profile coupling piece over part 2 all the way home. Part 1 and part 2 are now connected with one another. - Page 3 Mounting Minimum headroom Installation on lintel Installation on ceiling 35 mm Minimum headroom When mounting as shown in the diagrams at right, make sure there are at least 35 mm (1,37") of head- room between the ceiling and highest point reached by the door while pivoting. Installation without the minimum headroom of 35 mm If there is not enough room to leave the minimum headroom of 35 mm, then the opener must be mounted with a drawbar extension (available as an optional extra).
- Page 4 Endschaltereinstellung Your UK garage door opener automatically stops when one of the red limit-switch actuators trips a limit switch (in either "closing" or "opening" dirction). Adjust the limit switches by hand "Opening" direction Please set the limit-switch actuator for the "opening" direction so that the door comes to a halt about 30 mm (1,2") before its final...
- Page 5 1 : Lighting (blue) 2 : " (blue) UK 80+UK 100: 3 : 22or 28 V AC, dependend on speed setting 4 : " UK 60: 3: 24 V AC 4: " 5 : Motor (black or green) 6 : " (red)
- Page 6 Technical Data UK Data UK 60 UK 80 UK 100 DC motor 24 V- low noise 24 V- low noise 24 V- low noise Gears self-locking, 55 kg self-locking, 75 kg self-locking, 95 kg Operating speed fast 13 cm per sec.
-
Page 7: Remote Control Set
Remote Control Set The receiver is fixed on the electric board. Besides you find the codification block with 12 switches. 1-channel hand-transmitters Opening a 1-channel hand-transmitter as shown on the drawing besides, you will find the same codification block as the one for the receiver. You may adjust all 12 switches as you like. - Page 8 Problems? No problem..~Power failure? The opener doesn´t ~Disconnect and connect receiver. react on the transmitter ~Is the door stuck because of snow and ice? nor on the push-button ~Check the lines and the connections of the push-button switch. switch. ~Is there water in the push-button switch or in the key operated switch? ~Check the line of the push-button switch.
- Page 9 Problems? No problem..
