Engine Tightening Torques - KTM 390 Duke EU 2013 Repair Manual

21 TECHNICAL DATA
Wear limit
Crankshaft – diameter, crank pin
Crankshaft classification A
Crankshaft classification B
Clutch facing discs – thickness of total package
Clutch spring - length
Contact surface, clutch facing discs in clutch basket
Oil pressure regulator valve - minimum spring length
Oil pump
Play between external rotor and oil pump housing
Play between external rotor and internal rotor
Axial play
Shift shaft – play in sliding plate/shift quadrant
21.3

Engine tightening torques

Oil nozzle
Screw, gear sensor
Screw, ignition pulse generator
Screw, oil filter cover
Screw, retaining bracket
Screw, retaining bracket, stator cable
Screw, stator
Cylinder head screw
Nut, water pump impeller
Plug, water pump drain hole
Screw, alternator cover
Screw, bearing retainer
Screw, camshaft bearing bridge
Screw, chain securing guide
Screw, clutch cover
Screw, clutch spring
Screw, engine case
Screw, engine case
Screw, engine vent plate
Screw, freewheel gear retaining bracket M6
Screw, locking lever
Screw, oil pump
Screw, retaining bracket, shaft seal
ring, clutch cover
Screw, shift drum locating
Screw, starter motor
Screw, timing chain tensioner
Screw, timing chain tensioning rail
Screw, unlocking of timing chain ten-
sioner
Screw, valve cover
Screw, water pump cover
Nut, exhaust flange
Screw, balancer shaft gear
Screw, return spring, quick shifter
Stud, exhaust flange
Screw, conrod bearing
0.080 mm (0.00315 in)
31.970... 31.977 mm (1.25866... 1.25893 in)
31.978... 31.985 mm (1.25897... 1.25925 in)
≥ 21.30 mm (≥ 0.8386 in)
≥ 37 mm (≥ 1.46 in)
≤ 0.5 mm (≤ 0.02 in)
26.00 mm (1.0236 in)
0.09... 0.20 mm (0.0035... 0.0079 in)
0.10... 0.20 mm (0.0039... 0.0079 in)
0.10... 0.25 mm (0.0039... 0.0098 in)
0.15... 0.45 mm (0.0059... 0.0177 in)
M5
M5
M5
M5
M5
M5
M5
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6x40
M6x60
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M6
M8
M8
M8
M8
M8x1
6 Nm (4.4 lbf ft)
6 Nm (4.4 lbf ft)
6 Nm (4.4 lbf ft)
8 Nm (5.9 lbf ft)
6 Nm (4.4 lbf ft)
8 Nm (5.9 lbf ft)
8 Nm (5.9 lbf ft)
12 Nm (8.9 lbf ft)
10 Nm (7.4 lbf ft)
8 Nm (5.9 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
11 Nm (8.1 lbf ft)
11 Nm (8.1 lbf ft)
12 Nm (8.9 lbf ft)
10 Nm (7.4 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
10 Nm (7.4 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
11 Nm (8.1 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
10 Nm (7.4 lbf ft)
12 Nm (8.9 lbf ft)
12 Nm (8.9 lbf ft)
22 Nm (16.2 lbf ft)
20 Nm (14.8 lbf ft)
12 Nm (8.9 lbf ft)
22 Nm (16.2 lbf ft)
34 Nm (25.1 lbf ft)
158
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
–
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
–
®
Loctite 243™
–
–
®
Loctite 243™
–
®
Loctite 243™
–
–
–
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
®
Loctite 243™
–
–
®
Loctite 243™
–
–
–
–
®
Loctite 243™
®
Loctite 243™
–
–
