SETUP INSTRUCTIONS
2018
390 Duke
Art. no. 3213834en

Advertisement

loading
Need help?

Need help?

Do you have a question about the 390 Duke Series 2018 and is the answer not in the manual?

Questions and answers

Summary of Contents for KTM 390 Duke Series 2018

  • Page 1 SETUP INSTRUCTIONS 2018 390 Duke Art. no. 3213834en...
  • Page 3 KTM accepts no liability for delivery options, deviations from figures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.
  • Page 4: Means Of Representation

    1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips.
  • Page 5 SETUP 2 Unpacking and setting up the vehicle – Remove the straps and box. A00034-10 – Remove the adhesive tape in the upper area of the motorcycle. A00035-10 – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have fin- ished work on the vehicle.
  • Page 6 2 SETUP The lettering on the handlebar is in the middle of the han- dlebar clamp. – Position all controls in their exact positions on the handlebar. Tighten all screws. – Check the clutch lever play. ( p. 6) – Check the play in the throttle cable.
  • Page 7 Install the battery. ( p. 10) – Remove the remaining films. – Refuel. ( p. 13) – Check the headlight setting. ( p. 14) – Prepare the vehicle according to the specifications in the KTM Dealer.net for handover to the customer.
  • Page 8 3 WORK Checking the clutch lever play Note Clutch damage If there is no free travel by the clutch lever, the clutch will begin to slip. – Check the free travel of the clutch lever each time before using the motorcycle. –...
  • Page 9 WORK 3 Checking the play in the throttle cable – Check the throttle grip for smooth operation. – Move the handlebar to the straight-ahead position. Turn the throttle grip back and forth slightly and determine the play in throttle cable 3 …...
  • Page 10 3 WORK Removing the passenger seat – Insert the ignition key in seat lock and turn it clockwise. – Raise the rear of the seat, push it towards the rear, and lift it off. – Remove the ignition key from the seat lock. H01991-10 Mounting the passenger seat –...
  • Page 11: Recharging The Battery

    WORK 3 Mounting the front rider's seat Main work – Attach the front rider's seat in area and lower at the rear. – Finally, check that the driver's seat is correctly mounted. H01994-01 Finishing work – Mount the passenger seat. ( p.
  • Page 12 3 WORK – Remove the front rider's seat. ( p. 8) – Disconnect the negative cable of the battery. Main work – Connect the battery charger to the battery. Adjust the battery charger. EU battery charger XCharge-professional (00029095050) Alternative 1 US battery charger XCharge-professional (00029095051) Alternative 2...
  • Page 13 WORK 3 – Position negative cable ; mount and tighten the screw. V01273-11 Finishing work – Mount the front rider's seat. ( p. 9) – Mount the passenger seat. ( p. 8) – Set the time and date. ( p. 11) 3.11 Setting the time and date Condition...
  • Page 14 3 WORK The year flashes and is underlined. – Press the UP or DOWN button until the current year is set. – Press the SET button. The date is stored. 3.12 Opening the filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled.
  • Page 15 WORK 3 3.13 Closing the filler cap Warning Fire hazard Fuel is highly flammable, toxic and a health hazard. – Check the filler cap is locked correctly after clos- ing. – Change your clothing in case of fuel spills on them. –...
  • Page 16 Total fuel tank 13.5 l Super unleaded capacity, approx. (3.57 US gal) (ROZ 95/RON 95/PON 91) p. 19) (KTM 390 Duke F00792-10 EU/AU/JP/US, AR/CN/CO, MY/PH) Total fuel tank Gasohol 95 E20 capacity, approx. (RON 95) p. 19)
  • Page 17 WORK 3 3.16 Adjusting the headlight range Preparatory work – Check the headlight setting. ( p. 14) Main work – Turn adjusting screw to adjust the headlight range. Info Turn clockwise to increase the headlight range; turn counterclockwise to reduce the headlight range. If you have a payload, you may have to correct the headlight range.
  • Page 18: Technical Data

    4 TECHNICAL DATA Chassis tightening torques EJOT PT Screw, chain guard ® K60x30 7 Nm (5.2 lbf ft) Remaining screws, chassis 4 Nm (3 lbf ft) Remaining nuts, chassis 5 Nm (3.7 lbf ft) Remaining screws, chassis 5 Nm (3.7 lbf ft) Screw, chain guard 7 Nm (5.2 lbf ft) Loctite...
  • Page 19 TECHNICAL DATA 4 Screw, ignition lock (tamper-proof 13 Nm (9.6 lbf ft) screw) Screw, license plate holder 12 Nm (8.9 lbf ft) Loctite ® 243™ Screw, lower rear panel 7 Nm (5.2 lbf ft) Screw, magnetic holder on side 5 Nm (3.7 lbf ft) Loctite ®...
  • Page 20 4 TECHNICAL DATA Screw, top triple clamp 15 Nm (11.1 lbf ft) Banjo bolt, brake line 24 Nm (17.7 lbf ft) Fitting side stand 35 Nm (25.8 lbf ft) Loctite ® 243™ Remaining nuts, chassis 45 Nm (33.2 lbf ft) Remaining screws, chassis 45 Nm (33.2 lbf ft) Screw, engine bearer...
  • Page 21 SUBSTANCES 5 Gasohol 95 E20 (RON 95) Standard/classification – Gasohol 95 E20 (RON 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specifications. – Super unleaded fuel with an ethanol content of 19 to 20% is permissible. Info Do not use fuel made of methanol (e.
  • Page 22 *3213834en* 3213834en 01/2018 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KTM http://www.ktm.com...
