Getting to know the projector

Front and rear views

Lens shift controls
(under the badge)
Front
infrared
sensor
Lens
Focus
adjustment
adjustment
Control panel
Air outlet
Lamp cover
Mains input
Connection panel
Revision C, July 2014
GETTING TO KNOW THE PROJECTOR
Air outlet
Air outlet
Zoom
Rear infrared sensor
Air inlets
Adjustable feet

Remote control

ON POWER OFF
|
SOURCE
1 2 3
4 PIC 6
MUTE
ENTER
ASPECT
MENU
RATIO
USER MEMORY
A B C
SHARP
GAMMA O-SCAN NR
BRI-C C-TEMP TEST
3D 3D
2D/3D
SWAP FORMAT
Installation and Quick-Start Guide
Notes
40°
40°
Infrared reception
The projector uses the standard
MVision series infra-red remote
control.
Some of the controls are
duplicated on the projector control
panel, as shown on the next page.
For full details of how to use the
controls and the menu system,
see the Operating Guide.
Inst-03
