- Page 1 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS TARGET TOP RANGE / ELECTRIC OVENS G E 5 7 0 / G E 5 7 6 For use in GB &...
- Page 2 Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal 67 Gravelly Business Park Gravelly Park Birmingham West Midlands B24 8TQ (121) 327 5575 Fax: (121) 327 9711 UNITED STATES...
-
Page 3: Table Of Contents
Contents Blue Seal Gas Target Top Range / Electric Ovens GE570 Gas Target Top Range / Electric Static Oven. GE576 Gas Target Top Range / Electric Convection Oven. Introduction ....................2 Specification ....................3 Model Numbers Covered in this Specification... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your BLUE SEAL Gas Target Top Range / Electric Ovens, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Blue Seal appliance, there are two important things you can do. -
Page 5: Specification
Specifications Model Numbers Covered in this Specification GE570 Gas Target Top Range / Electric Static Oven - 900 mm. GE576 Gas Target Top Range / Electric Convection Oven - 900 mm. General A commercial heavy duty, gas fired Target Top having a high output, two stage double-ring iron cast burner offering accurate temperature control and infinitely variable heat with the heat radiating out from the centre of the Target Top. -
Page 6: Electrical Supply Requirements
1-Phase Connection 3-Phase Connection MODEL 1P+N+E 3P+N+E 230-240V 400-415V L1 - 8.2 Amps 6.5 kW, GE570 6.5 kW L2 - 9.2 Amps 26.6 Amps @ 235 V L3 - 9.2 Amps L1 - 8.6 Amps 6.6 kW, GE576 6.6 kW L2 - 9.2 Amps... -
Page 7: Dimensions
Dimensions Dimensions GE570 / GE576... -
Page 8: Installation
Blue Seal Target Top Range / Electric Ovens are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. -
Page 9: Clearances
Installation Components having adjustments protected (e.g. paint sealed) by manufacturer are only allowed to be adjusted by an authorised service agent. They are not to be adjusted by the installation person. NOTE: Do not obstruct or block the appliances flue. Never directly connect a ventilation system to the appliance flue outlet. -
Page 10: Electrical Connection
Installation NOTE: The gas pressure regulator provided with this appliance is convertible between Natural Gas and LPG as per the ‘Gas Conversion Section’ in this manual. Ensure the regulator is converted to the correct gas type that the appliance will operate on. The regulator outlet pressure is fixed ex-factory for the gas type that the regulator is converted to and it is NOT to be adjusted. - Page 11 Installation AUTIO N Changing the supply from 3 phase to single phase will increase the electrical current loading on the supply cable. Ensure that the supply cable used is of a sufficient size current loading, refer 'Electrical Supply Requirements' table overleaf. Tighten the cable gland to secure against tension on the cable.
-
Page 12: Operation
Blue Seal appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product. To use this appliance correctly please read the following sections carefully:- •... -
Page 13: Lighting The Pilot Burner (Target Top)
Operation Lighting the Pilot Burner (Target Top) Remove centre casting with the casting removal tool. Depress the control knob and rotate anti-clockwise to the ‘PILOT’ position. With the control knob depressed, manually light the pilot burner located in front of the main burner. Hold in the control knob for approximately 10 to 15 seconds, then release. -
Page 14: Oven
The oven is fitted with top and bottom elements. The thermostat maintains the overall oven temperature. The top element is further controlled by the oven top heat control. Convection Ovens (GE570 / GE576) are fitted with a circulation fan. NOTE: The Thermostat on the static oven provides overall control of the temperature within the oven by controlling both elements, where as the Oven Top Heat Control provides a means of balancing the distribution of heat between the top and bottom of the oven. -
Page 15: Cleaning And Maintenance
Cleaning and Maintenance AUTIO N Always turn ‘Off’ the electrical and gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. General Clean the Target Top / Range regularly. A clean appliance looks better, will last longer and will perform better. -
Page 16: Periodic Maintenance
Cleaning and Maintenance c. DO NOT use water on the castings while they are still hot as cracking may occur. Should it be necessary to clean the castings, allow the castings to cool and then remove for cleaning. Clean using a soft cloth moistened with a mild detergent and hot water solution and a scrubbing brush. -
Page 17: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. - Page 18 Wiring Schematic Static Oven Schematic (GE570)
- Page 19 Wiring Schematic Static Oven Wiring Diagram (GE570)
-
Page 20: Wiring Schematic
Wiring Schematic Convection Oven Schematic (GE576) - Page 21 Wiring Schematic Convection Oven Wiring Diagram (GE576)
-
Page 22: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure AUTIO N Ensure that the appliance is isolated from the gas supply before commencing servicing. NOTE: • These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. •... - Page 23 Gas Conversion and Specifications Pilot Burner Pilot Burner Main Burner To remove the pilot burner, disconnect the gas Injectors supply tube from the base of the pilot burner. Remove the bolt securing the retaining plate holding the pilot burner and thermo couple to the Gas Supply mounting bracket.
- Page 24 Gas Conversion and Specifications Gas Regulator NOTE: The regulator supplied is convertible between Natural Gas and LPG, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated for LPG Fig 16 Ensure that the gas supply is turned ‘OFF’...
-
Page 25: Gas Specifications
Gas Conversion and Specifications Gas Specifications - Australia / New Zealand Only Natural Gas LP Gas (Propane) Main Burner Injector (Inner Ring) Ø 1.70 mm Ø 1.10 mm Main Burner Injector (Outer Ring) Ø 2.60 mm Ø 1.55 mm Pilot Burner Injector 0.35 0.25 Burner Aeration Screw X (Inner) -
Page 26: Replacement Parts List
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on the reverse of the front cover of this manual). - Page 27 Ranges 900 mm Plinth Kit. Regulator 228531 Regulator (Natural Gas/LP Gas [Propane] Convertible) - ” BSP F/F. Gas Conversion Kits Gas Type to Convert to Model Australia / New Zealand Only UK Only Nat. Gas Nat. Gas GE570 / 576 231972 231971 231972 231971...
