I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L
GAS TARGET TOP RANGE /

ELECTRIC OVENS

GE570 / GE576
For use in GB & IE
230561-14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GE570 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blue Seal GE570

Summary of Contents for Blue Seal GE570

  • Page 1: Electric Ovens

    I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS TARGET TOP RANGE / ELECTRIC OVENS GE570 / GE576 For use in GB & IE 230561-14...
  • Page 2 (tel): 800 263 1455 (Toll Free) NEW ZEALAND Moffat Limited Web: www.moffat.co.nz E.Mail: sales@moffat.co.nz Main Office: (tel): 0800 663328 UNITED KINGDOM Blue Seal Web: www.blue-seal.co.uk E.Mail: sales@blue-seal.co.uk Sales: (tel): +44 121 327 5575 (fax): +44 121 327 9711 Spares: (tel): +44 121 322 6640...

  • Page 3: Table Of Contents

    Contents Blue Seal Gas Target Top Range / Electric Ovens GE570 Gas Target Top Range / Electric Static Oven. GE576 Gas Target Top Range / Electric Convection Oven. Introduction ....................2 Specification ....................3 Model Numbers Covered in this Specification...

  • Page 4: Introduction

    Introduction We are confident that you will be delighted with your BLUE SEAL Gas Target Top Range / Electric Oven, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Blue Seal appliance, there are two important things you can do.

  • Page 5: Specification

    Specifications Model Numbers Covered in this Specification GE570 Gas Target Top Range / Electric Static Oven - 900mm. GE576 Gas Target Top Range / Electric Convection Oven - 900mm. General A commercial heavy duty, gas fired Target Top having a high output, two stage double-ring cast iron burner offering accurate temperature control and infinitely variable heat with the heat radiating out from the centre of the Target Top.

  • Page 6: Gas Supply Requirements

    Specifications Gas Supply Requirements - Australia: Natural Gas LP Gas (Propane) Target Top Target Top Input Rate (N.H.G.C.) 45 MJ/hr 45 MJ/hr Gas Supply Pressure 1.13 - 3.40 kPa 2.75 - 4.50 kPa Burner Operating Pressure (*) 1.0 kPa 2.60 kPa Gas Connection ”...

  • Page 7: Gas Connection

    Specifications - All Other Markets: Natural Gas Town Gas (**) Input Rate (N.H.G.C.) 45 MJ/hr 45 MJ/hr Gas Supply Pressure 1.13 - 3.40 kPa 0.75 - 1.50 kPa Burner Operating Pressure (*) 0.95 kPa 0.63 kPa Gas Connection ” B.S.P. Male LP Gas (Propane) Butane Input Rate (N.H.G.C.)

  • Page 8: Electrical Supply Requirements

    MODEL 1P+N+E, 230-240V 3P+N+E, 400-415V L1 - 8.2 Amps 6.5 kW, 6.5 kW L2 - 9.2 Amps GE570 26.6 Amps @ 235 V L3 - 9.2 Amps L1 - 9.5 Amps 6.8 kW, 6.8 kW L2 - 9.2 Amps GE576 27.9 Amps @ 235 V...

  • Page 9: Dimensions

    Dimensions Dimensions GE570 / GE576...

  • Page 10: Installation

    Blue Seal Target Top Range / Electric Ovens are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation.

  • Page 11: Clearances

    Installation Components having adjustments protected (e.g. paint sealed) by manufacturer are only to be adjusted by an authorised service agent. They are not to be adjusted by the installation person. NOTE: Do not obstruct or block appliances flue. Never directly connect a ventilation system to appliance flue outlet.

  • Page 12: Electrical Connection

    Installation NOTE: Gas pressure regulator provided with this appliance is convertible between Natural Gas and LPG as per ‘Gas Conversion Section’ in this manual. Ensure regulator is converted to correct gas type that appliance will operate on. Regulator outlet pressure is fixed ex-factory for gas type that regulator is converted to and it is NOT to be adjusted.
  • Page 13 Installation Caution Changing supply from 3 phase to single phase will increase electrical current loading on supply cable. Ensure supply cable used is of a sufficient size for current loading, refer to 'Electrical Supply Requirements' table. Tighten cable gland to secure against tension on cable.

  • Page 14: Operation

    / operator. Blue Seal appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product.
  • Page 15 Operation Lighting Pilot Burner (Target Top) Remove centre casting with casting removal tool. Depress control knob and rotate anti-clockwise to ‘PILOT’ position. With control knob depressed, manually light pilot burner located in front of main burner. Hold in control knob for approximately 10 to 15 seconds, then release. Pilot burner should remain alight.

  • Page 16: Oven

    Oven is fitted with top and bottom elements. Thermostat maintains overall oven temperature. Top element is further controlled by oven top heat control. Convection Ovens (GE570 / GE576) are fitted with a circulation fan. NOTE: Thermostat on static oven provides overall control of temperature within oven by controlling both elements, where as Oven Top Heat Control provides a means of balancing distribution of heat between top and bottom of oven.

  • Page 17: Cleaning And Maintenance

    Cleaning and Maintenance General Caution Always turn off electrical and gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. Clean Target Top / Range regularly. A clean appliance looks better, will last longer and will perform better.

  • Page 18: Periodic Maintenance

    Cleaning and Maintenance Target Top a. This should be kept clean of any build up of food spillage’s. Provided cast iron work surface is regularly used it will maintain itself in good condition with no special cleaning required. b. Clean any food residue and spillage from channels around centre casting and main plates before use.

  • Page 19: Fault Finding

    Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.

  • Page 20: Wiring Schematic

    Wiring Schematic Static Oven Schematic (GE570)
  • Page 21 Wiring Schematic Static Oven Wiring Diagram (GE570)

  • Page 22: Ge570

    Wiring Schematic Convection Oven Schematic (GE576)

  • Page 23: Ge570

    Wiring Schematic Convection Oven Wiring Diagram (GE576)

  • Page 24: Gas Conversion And Specifications

    Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas and electrical supplies before commencing servicing. NOTE:  These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning appliance. ...

  • Page 25: Gas Specifications

    Gas Conversion and Specifications NOTE: Ensure pilot burner and thermocouple are correctly located and pilot burner aligns Pilot Burner Main Burner with main burner ignition port. (Refer to Ignition Port Thermocouple figure opposite for correct fitting and 2± 2.0 18± 2.0 alignment dimensions).

  • Page 26: Gas Regulator

    Gas Conversion and Specifications Gas Regulator NOTE, Pin rotated - NAT Gas / LPG / Butane Only. for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet NOTE, Pin rotated for LPG pressure is fixed ex-factory and is NOT to be adjusted.

  • Page 27: Gas Specifications

    Gas Conversion and Specifications Gas Specifications - Australia: Natural Gas LP Gas (Propane) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 1.10mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 1.55mm Pilot Burner Injector 0.35 0.25 Burner Aeration Screw X (Inner) 25mm 25mm Burner Aeration Screw Y (Outer)
  • Page 28 Gas Conversion and Specifications - UK Only: Category: 2H3P. Flue Type: Natural Gas (G20) Propane (G31) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 1.10mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 1.55mm Pilot Burner Injector 0.35 0.25 Burner Aeration Screw X (Inner) 25mm 20mm Burner Aeration Screw Y (Outer)
  • Page 29 Gas Conversion and Specifications - All Other Markets: Natural Gas Town Gas (**) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 4.20mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 6.30mm Pilot Injector 0.35 0.70 Burner Aeration Screw X (Inner) 25mm 20mm Burner Aeration Screw Y (Outer)

  • Page 30: Replacement Parts List

    Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for servicing and repair of this appliance. Instructions supplied with parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on reverse of front cover of this manual).
  • Page 31 Gas Type to Convert to Model Nat. Gas Butane Town Gas Nat. Gas (UK) LPG (UK) GE570 / GE576 231972 231971 231973 N/A (*) 231972 231971 NOTE: (*) Town Gas Option is only available with specific ex-factory built Town Gas models, which can also be converted to any other gas.
