2.6 Basic Flying Test

Carry out the following procedures to complete the basic flight test.
1. Wait the GPS signal to be well
Place the aircraft away from you and others at least 3 meters and wait the
2. Start motors and takeoff aircraft.
Execute CSC to start motors; all sticks back to midpoint as soon as motors start, then push
the throttle stick to take off the aircraft, meanwhile the home point is recorded. NOTE:
30secs after power on; 10secs after
position as home point at the first time the throttle stick is raised
After the home point is recorded successfully and the distance from aircraft is less than 8m,
LED indicator will blink 6 violet continually. Note: only when GPS signal is good (no Red
LED) LED indicator will blink 6 violet continually.
3.Operate sticks to control the flying attitude of the aircraft during flight
Transmitter (Mode2)
Throttle
Stick
Yaw Stick
Roll Stick
Pitch
Stick
©2013 DJI Innovations. All Rights Reserved
≥6; Motors have been started, auto-record the
Aircraft
18 |
≥6.
Operations
Push Throttle sticks to control the aircraft
to elevate and descend. The aircraft can
lock to an altitude when the throttle stick
is at midpoint.
Push the yaw stick to rotate the aircraft in
clockwise or counter clockwise direction.
Push roll stick to control the aircraft left
or right, pitch stick to control forward or
backward.
When both roll and pitch sticks are at
midpoint：
(1) GPS mode: the aircraft will be
stabilized and locked in horizontal
position.
(2) ATTI 1/ATTI 2 mode: the aircraft
will be stabilized but unlocked in
horizontal position.
LED
or no Red LED
LED
( )
∝
( )
6
