1.2 Software Installation and Configuration

Configure the A2 flight control system in the Assistant software please adheres to this section.
required to configure every item in "Basic" page when use the A2 flight control system for the first time.

1.2.1 Install Driver and Assistant Software

1. Download
Download the driver
installer and assistant
software installer
from DJI website.
Assistant software supports only Windows operating systems (Win XP, Win7, Win8 (32 or 64 bit)).

1.2.2 Configure using Assistant Software on a PC

The USB port can supply power during configuration, no additional battery is required. Note that the USB port can
supply power not more than 500mA, an additional battery is necessary if connection failure or intermittent working.
Run the assistant software, and follow the built-in guide to carry out the configuration. Note that you may be asked
to register for first time use.
4
Menu
Setting
Options
Built-in
Guide
1. View
Click "Info" to view
user information
and software
version etc.
©2013 DJI Innovations. All Rights Reserved
2.Connect
Connect the
LED-BT-I module and
PC via a Micro-USB
cable.
3
2
2. Restore &Upgrade
Enter "Tools" to restore default
settings. And check whether the
firmware is the latest.
12 |
3.Install Driver
Run the driver
installer and follow
the prompts to finish
installation.
1
3.Set
Enter "Basic" page.
Set the Aircraft,
Mounting, RC, Gain"
in each tab.
Users are
4.Install Software
Run the assistant
software installer and
follow the prompts to
finish installation.
4.Check
Enter "View"
page to check all
basic settings.
