  • Page 1 VGA SWITCH 250MHz DS-44100-1 DS-45100-1 User Manual DS-44100-1 (2 In / 1 Out) DS-45100-1 (4 In / 1 Out)
  • Page 2: Product Introduction

    The VGA Switch / Splitter enables you to switch between two input video signals (DS-44100-1) or four input video signals (DS-45100-1) to be displayed on one monitor (one output video signal). The Switch / Splitter is an active device. It amplifies and rectifies the output signal and ensures high output gain, high bandwidth, high resolution and high reliability of the output signal.
  • Page 3: Specifications

    Specifications: Signal Type Connection Type VGA 15HDF Minimum input level 0.5Vp-p Video Input / Output Signal positive Maximum input level 1.0Vp-p positive I/O Impedance 75Ω Maximum Resolution 1920*1080 Horizontal Frequency 30-100KHz Video Vertical Frequency 40-120Hz Bandwidth 250MHz Maximum Transmission 65 meters Resolution 800 x 600p @ Distance 60Hz...

This manual is also suitable for:

Ds-45100-1
