- Page 1 Truss Mate II User Manual www.showtech.com.au...
-
Page 2: Table Of Contents
Truss Mate II Table of Contents 1. Safety instructions…………………………………………………………3 1.1 Power Connection ………………………………….……………….4 1.2 Overhead Rigging …………………………………………………...4 1.3 DMX Connection ……………………………………………………..6 1.4 Cleaning and Maintenance ………………………………………6 2. Menu Navigation .…………………………………………………………7 3. DMX Allocation….………………………………………………………….8 4. Technical Specifications ……………………….……………………….9... -
Page 3: Safety Instructions
NO USER SERVICABLE PARTS INSIDE. If unit is out of service, please contact your point of purchase. If any troubles arise, remove the power plug and contact your ShowPro representative for repair. Do not open the machine by yourself, it might result a danger of electric shock. -
Page 4: Power Connection
Truss Mate II 1.1 Power Connection AC Power This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC AC Plug Connection Wire AC Live Brown AC Neutral Blue AC Ground Green/Yellow 1.2 Overhead Rigging This item must be built in a way that it can hold 10 times more of its weight for 1 hour without causing any damage. - Page 5 Truss Mate II DANGER OF FIRE! When installing the device, make sure there is no highly-flammable material (decoration articles, etc.) within a distance of min. 0.5m. Mount the projector with the mounting bracket to your trussing system using an appropriate clamp.
-
Page 6: Dmx Connection
Truss Mate II 1.3 DMX Connection DMX Linking the Trussmate II will work with a DMX controller using a 3-pin DMX serial connection. DMX Connection the Trussmate II uses 3-pin DMX data connections for its DMX personalities: 3 Ch, 8 Ch. See the User Manual for information about connecting and configuring the product for DMX operation. -
Page 7: Menu Navigation
Truss Mate II 2.0 Menu Navigation Menu Level 1 Menu Level 2 Menu Level 3 Remark Default: 3-CH，d 1 1：R 2：G 3：B 4：GB 5：RB 6：RG 7：RGB（Default ：RGB） P1：3Colors snap (Default P1) P2：3 Colors Fade P3：7Colors snap P4：7Colors Fade Speed : 1-100（slow - fast）... -
Page 8: Dmx Allocation
Truss Mate II 3.0 DMX Allocation 3-CH Function Value Percent/Setting 000-255 0~100% Green 000-255 0~100% Blue 000-255 0~100% 8-CH Function Value Percent/Setting 000-255 0~100% Green 000-255 0~100% Blue 000-255 0~100% 000-015 No Function Color 016-255 Color Macros 000-015 No Function... -
Page 9: Technical Specifications
Truss Mate II 204-255 Dimmer speed mode2 (middle speed) Dimmer speed mode3 (slow speed) 4.0 Technical Specifications OPTICS LED Specification 3W RGBW 3 in 1 LEDs LED quantity Field Angle 32° Beam Angle 16 ° Output 114 lux @ 5 meters... - Page 10 Truss Mate II Charging during use Input Voltage AC 90V-240V AC 50/60 Hz auto-ranging Power Consumption 13.6W Fuse T1A 250V Physical Weight 1.29 Kg Size 135.5x121.3x108.3 Cooling System Fan-free convection cooled IP Rating IP20...
