  • Page 1 LED Profile VW500 USER MANUAL LEDMOV135...

  • Page 2: General Instructions

    WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage, and maintenance of the unit. SAFETY General instructions • The products referred to in this manual conform to the European Community Directives and are therefore marked with CE.

  • Page 3: Specifications

    INTRODUCTION The LED Profile VW500 is a variable white LED profile. Features 500W LED with exquisite colour rendering (up to CRI 95) Innovative five-colour mixable LED light source Variable white colour temperature presets from 2800K – 8000K Adjustable +/- green hue tuning...

  • Page 4: Maintenance And Cleaning The Unit

    MAINTENANCE Maintenance and cleaning the unit • Make sure the area below the installation place is free from unwanted persons during setup. • Switch off the unit, unplug the main cable and wait until the unit has cooled down. • All screws used for installing the device and any of its parts should be tightly fastened and should not be corroded.
  • Page 5 OVERVIEW...
  • Page 6 DIMENSIONS...

  • Page 7: Operation

    OPERATION Display menu functions DMX Address: Assign DMX starting address to the fixture. DMX Mode: Select between 1, 4, 5, 7, 11, 13, 13.2, 17 channel modes or HSV. Colour Temperature: Select from 36 different white temperatures (2800K – 8000K) Hue Adjust: -25%/+25% submenu.
  • Page 8 PHOTOMETRICS...

  • Page 9: Menu Functions

    MENU FUNCTIONS Main Menu Menu Level 2 Menu Level 3 Meu Level 4 Default DMX Address <001> DMX Channel 11Ch 11Ch 13Ch 13Ch2 17Ch 2800K 2900K 3000K 3100K 3200K … Colour … Dimmer<0 – 255> 2800K Temperature 5600K Hue <-25 – 25> 5700K Static 6000K...
  • Page 10 Backlight Fixture Hours 9999H Information Version V 1.0 21A40138 Reset Factory...

  • Page 11: Dmx Charts

    DMX CHARTS 1Ch Function Value Setting Dimmer 000 – 255 0 – 100% 4Ch Function Value Setting Dimmer 000 – 255 0 – 100% 000 – 005 Open 006 – 013 C3050 Md Yellow 014 – 021 C3040 Lt Yellow 022 –...
  • Page 12 5Ch Function Value Setting 000 – 255 0 – 100% Green 000 – 255 0 – 100% Blue 000 – 255 0 – 100% Amber 000 – 255 0 – 100% Lime 000 – 255 0 – 100% 7Ch Function Value Setting Dimmer...
  • Page 13 171 – 178 C5050 Md Blue 179 – 186 C5060 Dk Blue 187 – 194 C5690 Indigo 195 – 202 C5080 VDk Blue 203 – 210 C5081 VDk Blue 2 211 – 218 C4370 Yel Green 219 – 226 C4070 Green 227 –...
  • Page 14 195 – 202 C5080 VDk Blue 203 – 210 C5081 VDk Blue 2 211 – 218 C4370 Yel Green 219 – 226 C4070 Green 227 – 234 C4550 Turquoise 235 – 242 C4560 Aqua 243 – 250 C4570 Blue Green 251 –...
  • Page 15 000 – 010 Open Strobe 011 – 255 Strobe (From fast to slow) 17Ch Function Value Setting Dimmer 000 – 255 0 – 100% Dimmer Fine 000 – 255 0 – 100% 000 – 255 0 – 100% Red Fine 000 –...
  • Page 16 251 – 255 No Function 000 – 005 Open Colour Temperature 006 – 255 2800K – 8000K 000 – 000 No Function 001 – 255 -25 to 25 shift 000 – 007 No Function 008 – 015 Dimmer Reset 016 – 023 Red Shift On 024 –...
