'PTO BLOWER'
MODELS 2000*/3200**/4000***
ASSEMBLY INSTRUCTIONS AND OPERATOR'S MANUAL
Congratulations!
You have just purchased one of the finest pieces of outdoor power equipment on the
market today. If properly cared for, your Giant-Vac PTO Blower will provide years of
dependable service. Please read and follow this instruction manual carefully in order to
get the most out of your new equipment.
First, inspect your machine upon delivery. Each Giant-Vac product leaves our factory in
excellent condition; occasionally, however, some damage may occur during shipment. If
any such damage is found upon initial inspection, immediately notify the transport carrier
who delivered your machine, as they are solely responsible for the damage as well as
any subsequent adjustments.
Your Giant-Vac PTO Blower requires very little assembly. Simply follow the instructions
contained within this manual to begin enjoying the benefits of your new unit.
Gasoline and Diesel engine exhaust and some of its constituents are
known to the State of California to cause cancer, birth defects and other
As an owner of off-road gasoline or diesel engine equipment and/or as an
employer, you also may have an obligation under the California
Occupational Safety and Health Act or under Proposition 65 to warn
persons exposed to gas and diesel engine exhaust and/or other
Proposition 65 chemicals in and around your workplace. See California
Health and Safety Code section 25249.5, Title 22 of the California Code of
Regulations at Section 1200 er seq., and Title 8 of the California Code of
*
Model 2000 P.T.O. Blower is designed to be used in conjunction with a P.T.O. 3-point hitch tractor equipped with an
18-25HP P.T.O. drive that can achieve 540 R.P.M.
** Model 3200 P.T.O. Blower is designed to be used in conjunction with a P.T.O. 3-point hitch tractor equipped with a 25-
38HP P.T.O. drive that can achieve 540 R.P.M.
***Model 4000 P.T.O. Blower is designed to be used in conjunction with a P.T.O. 3-point hitch tractor equipped with a
40+HP P.T.O. drive that can achieve 540 R.P.M.
THE GIANT-VAC
CALIFORNIA PROPOSITION 65 WARNING
reproductive harm.
Regulations Section 5194.
REV. B – 8/00
Manual No. 3079056 (8/2000)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Giant-Vac 2000 series
Summary of Contents for Giant-Vac 2000 series
- Page 1 You have just purchased one of the finest pieces of outdoor power equipment on the market today. If properly cared for, your Giant-Vac PTO Blower will provide years of dependable service. Please read and follow this instruction manual carefully in order to get the most out of your new equipment.
- Page 2 READ THE FOLLOWING SAFETY RULES CAREFULLY BEFORE OPERATING UNIT: • Regard your Giant-Vac PTO Blower as a piece of power equipment and teach this regard to all who will operate this unit. Never allow children or young teenagers to operate the unit.
-
Page 3: Unit Assembly
UNIT ASSEMBLY MODEL 2000 Your Giant-Vac Model 2000 PTO Blower comes fully assembled * and ready for installation onto your tractor. (Follow the manufacturer’s instructions for proper connection to the tractor.) * The only assembly step required is the installation of the inner deflector door control rod: •... - Page 4 (#35) and secure with locknut, tightening just enough to give control arm free (but not sloppy) movement. Assembly of your Giant-Vac PTO Blower is complete. You are now ready to mount your unit onto the 3-point hitch of your tractor.
-
Page 5: Unit Operation
With tractor engine running, set throttle to slow position, engage P.T.O. drive lever, then slowly increase throttle to a maximum of 540 R.P.M. Caution: Never run the tractor’s P.T.O. drive over 540 R.P.M. All Giant-Vac P.T.O. Blowers are designed for a maximum input of 540 R.P.M. CHANGING DIRECTION OF DISCHARGE: •... -
Page 6: Unit Maintenance
Each discharge opening has an adjustable deflector to assist in directing the ground air flow for varying conditions. *Please note that the Giant-Vac PTO blower is designed to be equally efficient in either left or right hand discharge mode. - Page 7 GIANT-VAC MFG. INCORPORATED, here-in-after called Giant-Vac, warrants each new Giant-Vac to the original retail purchaser of the new Giant-Vac equipment to be free from manufacturing defects in normal service for a period of 1 year, unless it is used for rental purposes, which limits the warranty to 30 days.
- Page 10 PARTS LIST # 5772 – REV. B GIANT-VAC MODEL 2000 PTO BLOWER Part Description SHEET 1 10167 Blower housing & shaft frame ----- -----------------------N/A on Model 2000------------------------ 20191 Intake baffle 31400 5/16” x 3/4” hex bolt 31003 5/16” lockwasher 24615...
- Page 11 PARTS LIST # 5772 – REV. B GIANT-VAC MODEL 2000 PTO BLOWER Part Description 31562 #12 x 3/4” self tapping screw 38035 Top hitch point bracket 31084 1/2” x 1-1/4” hex bolt 31078 1/2” lockwasher 31022 1/2” hex nut 51-60...
- Page 12 PARTS LIST # 5772 – REV. B GIANT-VAC MODEL 3200 / 4000 PTO BLOWER Part Description 3200 4000 SHEET 1 10178 Blower housing 10111 Blower housing 31084 1/2” x 1-1/4” hex bolt 31147 ½” x 1-1/2” hex bolt (shaft frame bottom cover) 31043 ½”...
- Page 13 PARTS LIST # 5772 – REV. B GIANT-VAC MODEL 3200 / 4000 PTO BLOWER Part Description 3200 4000 SHEET 2 10110 Blower back & shaft frame 27178 Control rod guide bracket 31084 1/2” x 1-1/4” hex bolt 31078 1/2” lockwasher 31022 1/2”...
- Page 14 PARTS LIST # 5772 – REV. B GIANT-VAC MODEL 3200 / 4000 PTO BLOWER Part Description 3200 4000 36167 Lower input shaft bearing 31147 1/2” x 1-3/4” hex bolt 31043 1/2” flatwasher 31078 1/2” lockwasher 31022 1/2” hex nut 37100...
