ASSEMBLY INSTRUCTIONS
OPERATOR'S MANUAL
PARTS LIST
'Whisper-Jet'
Walk-Behind
Leaf Blower
Series 1
LBWJ13171KH
(P/N 3085655)
Actual product may differ slightly from product pictured above
Manual No. 3071787 (I.R. 2/23/04)
GIANT-VAC
COPYRIGHT © 2004
ALL RIGHTS RESERVED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Whisper-Jet and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Giant-Vac Whisper-Jet

  • Page 1 ASSEMBLY INSTRUCTIONS OPERATOR’S MANUAL PARTS LIST ‘Whisper-Jet’ Walk-Behind Leaf Blower Series 1 LBWJ13171KH (P/N 3085655) Actual product may differ slightly from product pictured above GIANT-VAC COPYRIGHT © 2004 Manual No. 3071787 (I.R. 2/23/04) ALL RIGHTS RESERVED...
  • Page 2: Model Number

    preliminaries Congratulations! You have just purchased one of the finest pieces of outdoor power equipment on the market today. If properly cared for, your new blower will provide years of dependable service. Please read and follow this instruction manual carefully in order to get the most out of your new equipment. Each product leaves our factory in excellent condition;...
  • Page 3: Slope Operation

    safety rules regarding outdoor power equipment IMPORTANT! READ CAREFULLY THE FOLLOWING SAFETY RULES BEFORE ASSEMBLING OR OPERATING UNIT. • Operate only in the daylight or with good artificial TRAINING light, keeping away from holes and hidden hazards. • Read, understand, and follow all instructions in the •...
  • Page 4: Maintenance And Storage

    safety rules regarding outdoor power equipment (cont.) • Watch for holes, ruts, or bumps. Uneven terrain • Always follow the engine manual instructions for could overturn the unit. Tall grass can hide storage preparations before storing the unit for both obstacles.
  • Page 5: Front Wheel Assembly

    unit assembly Note: Please refer to Parts List for correct part identification and placement. Please note that serrated flange nuts may be used in place of split lock washers and hex nuts in some assembly steps. FRONT WHEEL ASSEMBLY • Place Mounting Bracket against lower right corner of Blower Housing, aligning holes in bracket with threaded studs in housing.
  • Page 6: Starting The Engine

    unit operation STARTING THE ENGINE IMPORTANT NOTE: The procedures outlined within this section are general guidelines, and are in no way meant to replace or supercede engine manufacturer’s operating instructions. In order to obtain optimum performance from your engine, refer to your engine manual. WARNING! IMPELLER IS MOUNTED DIRECTLY TO ENGINE SHAFT –...
  • Page 7: Blower Operation

    unit operation (cont.) STARTING THE ENGINE (cont.) • Bracing unit with one hand on the upper handle and one foot on the right rear tire, grasp recoil handle and pull briskly. You may have to pull several times before engine starts. (If engine fails to start within a reasonable amount of time, discontinue and check engine manual for further instructions.) Note: Do not allow recoil rope to snap back into recoil;...
  • Page 8 unit operation (cont.) BLOWER OPERATION (cont.) • Do not start unit until you are ready to begin blowing, and promptly shut off unit as soon as operation is complete. • Keep hands, feet and clothing away from rotating parts. Never place your feet or hands in path of discharge. •...
  • Page 9: Troubleshooting

    maintenance GENERAL: • Follow implicitly the engine manufacturer’s recommendations for maintenance. • Always keep your machine clean - especially the engine. Check all adjustments periodically. Also, periodically check that all fasteners are secure. • Never make any adjustments to the unit until the engine is off and the spark plug wire is disconnected. •...
  • Page 10 maintenance (cont.) • EXCESSIVE NOISE OR VIBRATION: • Check to make sure all fasteners are tightened securely. • Remove intake baffle and visually inspect impeller for broken, bent, or cracked blades; also make sure impeller hub is securely tightened onto engine shaft – bolts should be torqued to 15 ft/lbs each. Pull recoil and check for bent engine shaft.
  • Page 11: Replacement Parts

    90° side of the caster bracket. 0° REPLACEMENT PARTS: Replacement parts are available through your Giant-Vac dealer...
  • Page 12 illustrated parts list - LBWJ13171KH (3085655)
  • Page 13 illustrated parts list - LBWJ13171KH (3085655) Item Part No. Qty. Description 3010240 WELDMENT, Housing- 85KWJ & 13KWJ 33874 DECAL, Thrown Objects, Large 3039109** ENGINE, 13HP Kohler CS12T-Hydro 13 91540 SCREW, 5/16-18 x 1-1/2 Hex Head Cap, GR5 91601 NUT, 5/16-18 Hex Flange Lock, GR5 33686 DECAL, Warning- Leaf Blower 1921982...
  • Page 14 illustrated parts list - LBWJ13171KH (3085655)
  • Page 15 SPACER, .375 I.D. x .750 O.D. x .500 75893 DECAL, Personal Protection 13010 DECAL, Danger, Cut Finger 29445 DECAL, GIANT-VAC (Small) 75861 DECAL, GIANT VAC 3046622 DECAL, 13 HP Whisper Jet 91304 SCREW, 3/8-16 x 1" Hex Head Cap, GR5...
  • Page 16 This warranty does not apply to engines, tires or other items that are purchased by Giant-Vac and warranted by the manufacturer of such items. Items such as bags, grass catchers, hoses and blades are not warranted, as these are considered expendable items.
