Table of Contents

ASSEMBLY INSTRUCTIONS
OPERATOR'S MANUAL
PARTS LIST
Walk-Behind
Leaf Blower
EXTREME II
SERIES 1
Actual product may differ from product pictured above
Manual 3071775 (Rev 1, 04/30/04)
Models covered:
LBX10151BV
LBX85151KH
LBX9151H
LBX13151KH
(3085656)
(3085658)
(3085659)
(3085657)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LBX10151BV and is the answer not in the manual?

Questions and answers

Scott Ryan
July 4, 2025

What is the oil capacity on the LBXq0151bv?

0

Related Manuals for Giant-Vac LBX10151BV

Summary of Contents for Giant-Vac LBX10151BV

  • Page 1 ASSEMBLY INSTRUCTIONS OPERATOR’S MANUAL PARTS LIST Walk-Behind Leaf Blower EXTREME II Models covered: LBX10151BV (3085656) LBX85151KH (3085658) SERIES 1 LBX9151H (3085659) Actual product may differ from product pictured above LBX13151KH (3085657) Manual 3071775 (Rev 1, 04/30/04)

  • Page 2: Model Number

    preliminaries Congratulations! You have just purchased one of the finest pieces of outdoor power equipment on the market today. If properly cared for, your new blower will provide years of dependable service. Please read and follow this instruction manual carefully in order to get the most out of your new equipment. Each product leaves our factory in excellent condition;...

  • Page 3: Slope Operation

    safety rules regarding outdoor power equipment IMPORTANT! READ CAREFULLY THE FOLLOWING SAFETY RULES BEFORE ASSEMBLING OR OPERATING UNIT. • Operate only in the daylight or with good artificial TRAINING light, keeping away from holes and hidden hazards. • Read, understand, and follow all instructions in the •...

  • Page 4: Maintenance And Storage

    safety rules regarding outdoor power equipment (cont.) • Watch for holes, ruts, or bumps. Uneven terrain • Always follow the engine manual instructions for could overturn the unit. Tall grass can hide storage preparations before storing the unit for both obstacles.

  • Page 5: Front Wheel Assembly

    unit assembly Note: Please refer to Parts List for correct part identification and placement. FRONT WHEEL ASSEMBLY • Place Mounting Bracket against lower right corner of Blower Housing, aligning holes in bracket with threaded studs in housing. Secure with three 3/8-16 hex nuts, split lock washers and flat washers.

  • Page 6: Starting The Engine

    unit operation STARTING THE ENGINE IMPORTANT NOTE: The procedures outlined within this section are general guidelines, and are in no way meant to replace or supercede engine manufacturer’s operating instructions. In order to obtain optimum performance from your engine, refer to your engine manual. WARNING! IMPELLER IS MOUNTED DIRECTLY TO ENGINE SHAFT –...

  • Page 7: To Start Engine

    unit operation (cont.) TO START ENGINE: • Move choke control located on engine to the CHOKED closed “ON” position to start a cold engine. (Briggs engine shown – design and location may vary with engine. Refer to engine manual.) • Move engine speed control located on upper handle to the fast “Rabbit”...

  • Page 8: Blower Operation

    unit operation (cont.) BLOWER OPERATION DANGER! DO NOT PASS BY OR STAND ON THE AIR DISCHARGE SIDE OF ANY LEAF BLOWER WITH THE ENGINE RUNNING. HIGH VELOCITY DISCHARGE CAN EASILY TURN HARMLESS DEBRIS INTO FLYING PROJECTILES. DANGER! NEVER INSERT ANY BODY PART OR FOREIGN OBJECT INTO ANY OPENING WHILE UNIT IS RUNNING.
  • Page 9 unit operation (cont.) BLOWER OPERATION (cont.) TO BLOW DEBRIS OUT TOWARD FRONT OF UNIT: (all models except 13KH) • Open the forward air deflector door, mounted on the front of the discharge end of the blower, by pushing the control lever to the front of the machine.
  • Page 10 maintenance GENERAL: • Follow implicitly the engine manufacturer’s recommendations for maintenance. • Always keep your machine clean - especially the engine. Check all adjustments periodically. Also, periodically check that all fasteners are secure. • Never make any adjustments to the unit until the engine is off and the spark plug wire is disconnected. •...

  • Page 11: Troubleshooting

    maintenance (cont.) TROUBLESHOOTING: • UNIT WILL NOT START: • Check fuel and oil levels. • Check to make sure choke is set when engine is cold, off when hot. • Check throttle for proper operation. • Check intake baffle for jammed debris or accumulation of debris. •...

  • Page 12: Replacement Parts

    90° points of tire, then retightening bolts. alternate method is to place a level against the side of the caster bracket. 0° REPLACEMENT PARTS: • Replacement parts are available through your Giant-Vac dealer.
  • Page 13 - LBX10151BV (3085656)
  • Page 14 - LBX10151BV (3085656) Item No. Part No. Description 3010267 WELDMENT, Housing- Extreme Blower, LBX10151BV 33874 DECAL, Thrown Objects, Large 3039111 ENGINE, B&S 10HP Intek OHV Briggs Model 205412 Type 0121-E1 91540 SCREW, 5/16-18 x 1-1/2 Hex Head Cap, GR5...
  • Page 15 - LBX10151BV (3085656) Item No. Part No. Qty. Description 33753 HANDLE, Lower Folding- Wide- Blower 3032160 MOUNT, Vibration 91315 WASHER, 5/16" Split Lock 1717312 WASHER, 5/16" Curved 33866 DASH PANEL, Blower- Wide 3023276 ASSY, Upper Handle & Grip- Wide (p/n 33696 + grip) 74422 GRIP, 1.0 x 21-1/2"...
  • Page 16 illustrated parts list - LBX13151KH (3085657)
  • Page 17 - LBX13151KH (3085657) Item Part No. Qty. Description 3010269 WELDMENT, Housing- Extreme Blower, LBX10151BV 33874 DECAL, Thrown Objects, Large 3039109 ENGINE, Kohler 13HP Model CS12T 91540 SCREW, 5/16-18 x 1-1/2 Hex Head Cap, GR5 91601 NUT, 5/16-18 Hex Flange Lock, GR5...
  • Page 18 illustrated parts list - LBX13151KH (3085657) Item Part No. Qty. Description 3032160 MOUNT, Vibration 91315 WASHER, 5/16" Split Lock 1717312 WASHER, 5/16" Curved 33866 DASH PANEL, Blower- Wide 3023276 ASSY, Upper Handle & Grip- Wide (p/n 33696 + grip) 74422 GRIP, 1.0 x 21-1/2"...
  • Page 19 illustrated parts list - LBX85151KH (3085658)
  • Page 20 illustrated parts list - LBX85151KH (3085658) Item Part No. Qty. Description 3010268 WELDMENT, Housing- Extreme Blower 33874 DECAL, Thrown Objects, Large 3039078 ENGINE, Kohler 8.5HP PRO, Model CS8.5T 91540 SCREW, 5/16-18 x 1-1/2 Hex Head Cap, GR5 91601 NUT, 5/16-18 Hex Flange Lock, GR5 33686 DECAL, Warning- Leaf Blower 1921982...
  • Page 21 76978 NUT,1/4-20 Hex Nyloc 91298 NUT, 5/16-18 Hex Nyloc 3046583 DECAL, 8.5 HP Extreme 75893 DECAL, Personal Protection 13010 DECAL, Danger, Cut Finger 29445 DECAL, GIANT-VAC (Small) 75861 DECAL, GIANT VAC 3031813 SPACER, .375 I.D. x .750 O.D. x .5...
  • Page 22 illustrated parts list - LBX9151H (3085659)
  • Page 23 illustrated parts list - LBX9151H (3085659) Item No. Part No. Qty. Description 3010268 WELDMENT, Housing- Extreme Blower 33874 DECAL, Thrown Objects, Large 3039061 ENGINE, Honda 9HP, Model GX270QAW 91540 SCREW, 5/16-18 x 1-1/2 Hex Head Cap, GR5 91601 NUT, 5/16-18 Hex Flange Lock, GR5 33686 DECAL, Warning- Leaf Blower 91513...
  • Page 24 NUT,1/4-20 Hex Nyloc 91298 NUT, 5/16-18 Hex Nyloc 3046584 DECAL, 9 HP Extreme 75893 DECAL, Personal Protection 13010 DECAL, Danger, Cut Finger 29445 DECAL, GIANT-VAC (Small) 75861 DECAL, GIANT VAC 3031814 SPACER, .375 ID x .750 OD x .805 LG ZP...
  • Page 25 NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
  • Page 26 NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
  • Page 27 NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
  • Page 28 This warranty does not apply to engines, tires or other items that are purchased by Giant-Vac and warranted by the manufacturer of such items. Items such as bags, grass catchers, hoses and blades are not warranted, as these are considered expendable items.
