WATER HEATERS SINCE 1920
Intuitive · Reliable · Efficient
INSTALLATION &
OPERATION MANUAL
Hubbell Model
GX200 / GX200P
GX250 / G250P
nergy tar and
on
odels
To avoid product damage, personal injury, or even
possible death, carefully read, understand, and
follow all the instructions in the Installation and
the Operation manuals before installing this
product. Improper installation, adjustment, alteration, or
maintenance can cause injury, loss of life, and/or property
damage. This water heater should be installed and serviced
by a qualified technician. The lack of proper service can
result in a dangerous condition.
This manual contains safety information, installation instructions,
and maintenance procedures. It must be left with the homeowner
or placed near the water heater in a noncombustible place. The
homeowner should retain this manual for future reference.
WARNING
If the information in these instructions is not followed
exactly, a fire or explosion could result causing
property damage, personal injury, or death.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
D erti ed
o
/
AVERTISSEMENT
Assurez-vous de bien suivre les instructions données
dans cette notice pour réduire au minimum le
risque d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
— Ne pas entreposer ni utiliser d'essence ou
ni d'autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur; ne pas vous
servir
des
téléphones
se
le bâtiment.
Appelez immédiatement votre fournisseur de gaz
depuis
un
voisin.
Suivez
du fournisseur.
Si vous ne pouvez rejoindre le fournisseur,
appelez le service des incendies.
— L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualifié ou par le fournisseur de gaz.
Due
to
Hubbell's
improvement and technology, the design and/or technical
speci cations are sub ect to change
Serial Number: ___________________________________
Date of Installation: ___ / ___ / ______
trouvant
dans
les
instructions
policy
of
continuous
ithout notice
product
