10/07/2006 COVERT PIR CAMERAS I N S T R U C T I O N M A N U A L CONTENTS Page Page 1. Description ....... 1 4. Specifications ......4 2. Installation ........ 2 5. PIR Detector board installation 3.
2. Installation STEP 1: Secure the bracket to the wall with screws. ( included as shown in Figure 1 ) STEP 2: Attach the Camera Case to the bracket as shown in Figure 2.
STEP 3: Adjust the vertical and horizontal angles by loosening screws (A&B) as in Figure 3 and by turning the bracket vertically and horizontally. 3. Wiring instructions STEP 1:Connect the coaxial cable between the camera and the monitor using a 75Ohm coaxial cable. STEP 2: Insert the AC plug into the AC power socket and the DC plug to the DC Jack.
4. Specifications Model B/W – PC810/PC810D Colour – PC811/PC811D Image Pick-up SONY 1/3” Super HAD CCD SONY 1/4” Super HAD CCD sensor sensor Device EIA/NTSC: 510x492 Picture Elements (HxV) CCIR/PAL: 500x582 Horizontal TV lines TV lines Resolution Minimum 0.3 LUX / F2.0 0.5 LUX / F2.0...
5. PIR Detector board installation and descriptions (for PCC810 & PC811 models only) 6 Output Terminals N.O. - + N.C. PULSE Pulse Count Led Selector Light Control Recording Control Time Adjustment Sensitivity Adjustment Options Description 1.LED Selector: A. Top + Center w/black cap: Upon Walk-testing: Light blinking (Disadvantages: Easy to identify as a security system.) B.
Page 6
Options Description 4.Alarm control, Light control or A. Top + Center w/black cap: Operate with “VR2” to adjust Recording control time. (To set the relay output of the Light control or (N.O or N.C) Recording control, the time is selected by individual preference or application.
