About PoE Compact Media Converters
The PoE Compact Media Converter func-
tions as a fiber-to-twisted pair media convert-
er, as well as a Power Sourcing Equipment
(PSE), delivering power to a Powered Device
(PD) by using the UTP data cable. Deploying
a PoE Compact Media Converter supporting
the Power Over Ethernet standard is the solu-
tion for both extending the access point from
the network core as well as powering the
end-device at the access point.
PoE Compact Media Converters are fully
compliant with IEEE 802.3u 100 Mbps Fast
Ethernet and IEEE 802.3af Power over
Ethernet standards, and perform a single
conversion between 100Base-TX twisted
pair and 100Base-FX multi-mode or single-
mode fiber.
The Hardened
Media Converter
Compact Media Converter
operating and storage temperatures.
This manual includes installation and opera-
tion information for the following media converters:
PoE Compact Media Converters
LMC5125A
LMC5126A
LMC5128A
LMC5129A
LMC5130A
LMC5131A
LMC5154A
LMC5155A
LMC5156A
LMC5142A
LMC5143A
LMC5146A
LMC5147A
LMC5150A
LMC5151A
LMC5125A - LMC5126A - LMC5128A - LMC5129A - LMC5130A
LMC5131A - LMC5154A - LMC5155A - LMC5156A - LMC5142A
LMC5143A - LMC5146A - LMC5147A - LMC5150A - LMC5151A
LMC5135A - LMC5136A - LMC5140A - LMC5141A - LMC5157A
PoE Compact
is the same as the
but allows higher
PoE, TX/FX-MM1300-ST
PoE, TX/FX-MM1300-SC
PoE, TX/SX-MM850-ST
PoE, TX/SX-MM850-SC
PoE, TX/FX-SM1310/PLUS-ST
PoE, TX/FX-SM1310/PLUS-SC
PoE, TX/FX-SM1310/LONG-ST
PoE, TX/FX-SM1310/LONG-SC
PoE, TX/FX-SM1550/LONG-SC
PoE, TX/SSFX-SM1310-SC (1310xmt/1550rcv)
PoE, TX/SSFX-SM1550-SC (1550xmt/1310rcv)
PoE, TX/SSFX-SM1310/PLUS-SC (1310xmt/1550rcv)
PoE, TX/SSFX-SM1550/PLUS-SC (1550xmt/1310rcv)
PoE, TX/SSFX-SM1310/LONG-SC (1310xmt/1550rcv)
PoE, TX/SSFX-SM1550/LONG-SC (1550xmt/1310rcv)
PoE Compact Media Converter

Installation Guide

LMC4144A - LMC5145A - LMC5148A - LMC5149A
Q U I C K
Introduction
All the PoE and Hardened PoE ver-
sions, including TX/FX, TX/SX and
TX/SSFX will be referred to as PoE
PoE
Compact Media Converter except
where differences need indication.
1
S T A R T
NOTE
1
2
3
3
5
6
6
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMC5125A and is the answer not in the manual?

Questions and answers

Summary of Contents for Black Box LMC5125A

  • Page 1: Table Of Contents

    PoE Compact Media Converter Installation Guide LMC5125A - LMC5126A - LMC5128A - LMC5129A - LMC5130A LMC5131A - LMC5154A - LMC5155A - LMC5156A - LMC5142A LMC5143A - LMC5146A - LMC5147A - LMC5150A - LMC5151A LMC5135A - LMC5136A - LMC5140A - LMC5141A - LMC5157A...
  • Page 2: Configuration Instructions

    PoE Hardened Compact Media Converters LMC5135A Hardened PoE, TX/FX-MM1300-ST LMC5136A Hardened PoE, TX/FX-MM1300-SC LMC5140A Hardened PoE, TX/FX-SM1310/PLUS-ST LMC5141A Hardened PoE, TX/FX-SM1310/PLUS-SC LMC5157A Hardened PoE, TX/FX-SM1310/LONG-ST LMC4144A Hardened PoE, TX/SSFX-SM1310-SC (1310xmt/1550rcv) LMC5145A Hardened PoE, TX/SSFX-SM1550-SC (1550xmt/1310rcv) LMC5148A Hardened PoE, TX/SSFX-SM1310/PLUS-SC (1310xmt/1550rcv) LMC5149A Hardened PoE, TX/SSFX-SM1550/PLUS-SC (1550xmt/1310rcv) Each PoE Compact Media Converter includes one RJ-45 connector for the twisted...
  • Page 3: About Poe And Pse

    6). PSE functionality is enabled as default; the PSE switch is set to ON. NOTE: Although the PoE Compact Media Converter auto-detects PDs, and only supplies power when connected to an 802.3af compliant PD, Black Box recommends setting the PSE switch to OFF when connecting to a non-802.3af compliant device.
  • Page 4 Cable Break strand of fiber. If a strand is Remote Site unavailable, the Black Box device at the receiver end notes the loss of link. The device will then stop LED OFF = Broken Link transmitting data and the link sig-...
  • Page 5: Auto-Negotiation

    NOTE: Pulsing FiberAlert may be useful when connecting PoE Compact Media Converter to another manufacturer’s product that has a similar feature to FiberAlert. NOTE: Please refer to the Installation Guide for the appropriate Black Box product for more information on LFD.
  • Page 6: Crossover/Pass-Through

    Auto-Negotiation ON Auto-Negotiation ON If you are unsure of how best to implement these features in your configuration, please contact Black Box technical support at 877-877-BBOX (outside U.S. call 724-746-5500) for more information/assistance. W I S T E D A I R...
  • Page 7: Installation Troubleshooting

    ZERO CRNT Glows red when there is no device connected to the PoE Compact Media Converter. Glows red when the device connected to the PoE Compact Media Converter is NOT a valid PD. The LED is OFF when the PoE Compact Media Converter detects a valid PD.
  • Page 8: Technical Support

    Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support, 24 hours a day, 7 days a week Call: 724-746-5500 or Fax: 724-746-0746 Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com E-mail: info@blackbox.com...
  • Page 9 2) Black Box installs dust caps to ensure factory-clean optical devices. These protective caps should not be removed until the moment of connecting the fiber cable to the device. Assure that the fiber is prop- erly terminated, polished and free as much dust or dirt, and that the location is as free from dust and dirt as possible.
  • Page 10 Electrical Equipment Designed for use within Certain Voltage Limits (73/23/EEC). Certified to Safety of Information Technology Equipment, Including Electrical Business Equipment. For further details, contact Black Box. Class 1 Laser product, Luokan 1 Laserlaite, Laser Klasse 1, Appareil A’Laser de Classe 1...
  • Page 11 NOTES:...
  • Page 12 © 2004-2005 Black Box Corporation. All rights reserved. The information in this document is subject to change without notice. Black Box Corporation assumes no responsibility for any errors that may appear in this document. Specific brands and product names may be trademarks and are the property of their respective companies.
