Black Box LMC5100A Installation Manual

The H H i i g g h h D D e e n n s s i i t t y y M M e e d d i i a a C C o o n n v v e e r r t t e e r r S S y y s s t t e e m m I I I I
w w i i t t h h E E m m b b e e d d d d e e d d S S N N M M P P S S e e r r i i e e s s (hereafter
referred to as Media Converter System II)
features modular chassis designed for use
with Black Box S S N N M M P P M M a a n n a a g g e e a a b b l l e e M M o o d d u u l l e e s s
(SNMP Modules) including media conver-
sion, mode conversion, bandwidth manage-
ment and switching media conversion mod-
ules. Each chassis in the Media Converter
System II Series features an SNMP-manage-
ment agent embedded directly into the
backplane which eliminates the need to
purchase, install and configure a separate

management module.

The Media Converter System II Series includes 2, 8 and 18-slot chassis:
2 2 - - S S l l o o t t (LMC5100A and LMC5100A-DC) and 8 8 - - S S l l o o t t D D e e s s k k t t o o p p C C h h a a s s s s i i s s
(LMC5102A and LMC5102A-DC) feature two or eight slots, respective-
ly, for installing SNMP Modules and a fixed, internal 100-240 VAC or
-48 VDC power supply.
1 1 8 8 - - S S l l o o t t R R a a c c k k m m o o u u n n t t C C h h a a s s s s i i s s (LMC5104A, LMC5105A-DC and
LMC5164A [60 watt]) is a 3U high, rackmountable chassis that features
18 slots for installing SNMP Modules, one 100-240 VAC or -48 VDC
power module and an additional slot for a second, redundant power
supply.
Installing Media Converter System II
Before installing an SNMP Module into a Media Converter System II chas-
sis, install the chassis first.When installing the chassis, be sure to observe the
following precautions to prevent electrical or mechanical damage:
• Stay within the chassis power rating to prevent overload of supply
circuits or damage to overcurrent protection and supply wiring.
• Maintain reliable earth ground, especially when connecting to a
power strip instead of directly to a branch circuit.
• Protect your chassis from exposure to sunlight and electrical or
magnetic fields.
• Ensure that the equipment rack remains stable, even with the
addition of the chassis and its associated cabling.
High Density Media Converter
System II with Embedded SNMP

Installation Guide

LMC5100A — LMC5100A-DC — LMC5102A — LMC5102A-DC
LMC5104A — LMC5105A-DC — LMC5164A
1
Q U I C K
I n s t a l l a t i o n I n s t r u c t i o n s
C o n f i g u r a t i o n I n s t r u c t i o n s
D H C P C l i e n t
H U B C T R L 3 2
D B - 9 S e r i a l C o n n e c t o r
U s i n g / N o t U s i n g i V i e w
L E D I n d i c a t o r s
Fa n Re p l a c e m e n t
Te c h n i c a l S u p p o r t
S T A R T
1
3
4
4
5
8
1 0
1 1
9
